- Page 1 SMEVA MARKET Self-service cabinet Remote / Plug-in version User Manual www.smeva.com...
- Page 2 January 2022 Version 22.04 This manual is published by Smeva BV Valkenswaard Nederland. No reproduction (including translation) is permitted in whole or in part, e.g. photocopy, microfilming, or storage in electronic data processing equipment, without the expressively written consent of the publisher.
-
Page 3: Table Of Contents
1.3 Conventions used in this manual 1.4 Explanation of safety signs 1.5 Safety information 1.6 Documentation and information 1.7 Product identification 2. ABOUT THE SMEVA MARKET 2.1 Intended use and reasonably foreseeable misuse 2.2 Process overview 2.3 Technical data 2.4 Product compliance 2.5 Product elements... - Page 4 4.4 Control panel settings 4.5 Emergency situations 5. CLEANING AND MAINTENANCE 5.1 General advice 5.2 Cleaning 5.3 Defrosting 5.4 Planned cleaning and maintenance 5.5 Planned inspection 6. TROUBLESHOOTING & REPAIR 6.1 Troubleshooting 6.2 Service & contact User Manual...
-
Page 5: About This Manual
► Cleaning and maintenance personnel ► Installation and dismantling personnel All use of the Smeva Market shall only be carried out by an authorised, properly qualified, and skilled person of 16 years or older, who: ► Has read and understood this manual ►... -
Page 6: Conventions Used In This Manual
1.3 CONVENTIONS USED IN THIS MANUAL The following style conventions are used in this document: ► Bold Names of product elements ► Italic Cross-references 1.4 EXPLANATION OF SAFETY SIGNS The following safety signs are used on the packaging, product and in this document: Symbol Meaning Danger indicates a hazard with a high level of risk which, if not avoided,... -
Page 7: Safety Information
► All connections to the cabinet, such as electricity, drainage and coolant pipes, must be carried out by qualified engineers. Commissioning should also be done by qualified engineers. Do not remove any labels attached to the Smeva Market to avoid hazardous situations. To guarantee optimum performance, personal safety and maximum product shelf life: ►... -
Page 8: Documentation And Information
1.6 DOCUMENTATION AND INFORMATION The latest version of this User Manual, as well as the Installation & Service Manual, is available at http://www.smeva.nl. For service-related questions, information, technical assistance, ordering user instructions or spare parts, please contact us: Smeva BV J.F. -
Page 9: About The Smeva Market
2.1 INTENDED USE AND REASONABLY FORESEEABLE MISUSE The Market is intended to be used as a display of cold pre-packed goods. The Market is not designed to cool down goods. The Market is intended for indoor use only and shall only be used with the original accessories and components. -
Page 10: Technical Data
Condenser vertical Schrader Filter / Drier Compressor 2.3 TECHNICAL DATA Model Market Version Remote / Plug-in Weight 190 - 630 kg Product temperature (3M1) 25°C - 60% RH -1 ↓ T ↑ +5°C Evaporation temperature -10°C (at 20°C ambient temperature) -
Page 11: Product Compliance
► HPL ► Tempered glass Energy label 2.4 PRODUCT COMPLIANCE This product complies with all relevant European Directives. The Declaration of Conformity can be found in the Installation & Service Manual of the Smeva Market. 2.5 PRODUCT ELEMENTS SMEVA MARKET... - Page 12 1. Supports cylindrical 16. Gable-end 2. Supports rectangular 17. Gable-end glass 3. Adjustable feet 18. Glass holder 4. Pipe cover (optional) 19. Air-outlet grille 5. Drainage passage 20. Honeycomb outlet grill User Manual...
-
Page 13: The Temperature Readout
30. Cable passage 2.6 THE TEMPERATURE READOUT Depending on the version and its requirements, The Smeva Market is equipped with a specific controller and user display for each configuration. Full documentation on the specific controller, sensors, and user display can be provided upon request. -
Page 14: Safety Instructions
3. SAFETY INSTRUCTIONS Read and understand this manual and its safety instructions before installing, servicing, or using the cabinet. Failure to do so can result in serious injury or death. While transporting, storing, installing, operating, servicing and disposing of the cabinet, the cabinet should be located in a well-ventilated area or a room with a minimum volume as indicated in the table below by referring to the amount of charge as stated on the product identification label ㉘. -
Page 15: Potential Health Consequences
► Only engineers who have been trained in the safe handling and use of hydrocarbon refrigerants shall work on this cabinet. ► Smeva units are designed and manufactured for use with refrigerant R433A, a propane – propylene mixture. This refrigerant is flammable and can be hazardous in the event of a leak. -
Page 16: Repair And Modification Safety Information
3.5 REPAIR AND MODIFICATION SAFETY INFORMATION ► Repairs shall only be carried out by trained and qualified service personnel. ► Use only original shelves, accessories and spare parts. ► Alterations to the cabinet and technical modifications are not permitted without the written permission of the manufacturer. -
Page 17: Operating Instructions
► Make sure you know where the emergency stop switches are located before operating the cabinet. ► Make sure that the power is turned off before arranging the shelves. ► Check the cabinet and shelves for damage before arranging the shelves. If there is any visible damage, contact Smeva for further instructions. SMEVA MARKET... - Page 18 On delivery, shelves ㉓ are always hung in a horizontal position. The user can adjust the shelves to the desired angle and height. No tools are required. To guarantee an ideal product temperature, shelves should not be positioned in front of the holes of the air-outlet grille ⑲.
-
Page 19: Load Arrangement
Before loading products into the cabinet, make sure to ► Fully clean and dry the cabinet and all its elements ► Let the cabinet reach the correct temperature Make sure air circulation is optimal by leaving a sufficient amount of space between products. SMEVA MARKET... - Page 20 Before loading products into the cabinet, make sure to ► Only put pre-packed goods into the cabinet ► Only put pre-cooled goods into the cabinet Respect the maximum load level. Stacking up products too high will affect air circulation. User Manual...
-
Page 21: Control Panel Settings
► The air-inlet grille is not blocked (by e.g. products, doilies, etc.) 4.4 CONTROL PANEL SETTINGS Depending on its version and requirements, The Smeva Market is equipped with a specific control panel ㉙ for each configuration. For detailed information and operation instructions of the control panel, please refer to its user manual. -
Page 22: Emergency Situations
4.5 EMERGENCY SITUATIONS Make sure you know where the emergency stop switches are located before operating the cabinet. Not all versions of the Smeva Market are equipped with an ON/OFF button and must be switched off via the Central Cooling System, or by unplugging the cabinet from the power supply. -
Page 23: Cleaning And Maintenance
5. CLEANING AND MAINTENANCE 5.1 GENERAL ADVICE The Smeva Market cabinet meets the highest market requirements. To make sure the cabinet keeps functioning accordingly, it should be treated, cleaned, and maintained properly. HACCP and local regulations may require mandatory inspections and maintenance frequently. - Page 24 Following the principles of good practice, it is advised to carry out simple cleaning routines as much as necessary. For example, remove stains, finger marks, or dust once detected. Always clean the cabinet with a soft cloth and mild cleaning agent. Do not use abrasive and aggressive cleaning agents, such as hydrofluoric acid and chlorine, as they shorten the life of components considerably.
-
Page 25: Defrosting
5.3 DEFROSTING For low-temperature applications (< +2°C), the evaporator coil ⑮ can be fitted with an electric defrosting element for defrosting the coil. The ice will cycle off by the fans for higher temperatures only (under normal store conditions). SMEVA MARKET... -
Page 26: Planned Cleaning And Maintenance
The cabinet automatically runs six defrosting cycles every 24 hours (factory settings) to defrost the ice on the evaporator coil ⑮. An electrical defrost cycle is 30 minutes with a +8°C defrost termination temperature. A defrosting cycle is 45 minutes with a +6°C defrost termination temperature. - Page 27 Inspection tasks shall be done according to the following plan: Task Frequency Action Check if the temperature is set Daily If needed, contact Smeva or an correctly. authorised mechanic for assistance. Check if the exterior is clean and Daily Clean if needed. If damaged, undamaged.
-
Page 28: Troubleshooting & Repair
6. TROUBLESHOOTING & REPAIR Do not open the control panel. It is live even when the main switch is in the OFF position. Make sure the cabinet is switched off before performing an inspection or any cleaning or maintenance activities. This will avoid fire, explosions, electric shocks, or other hazards that may result in property damage and severe or fatal injuries. -
Page 29: Service & Contact
6.2 SERVICE & CONTACT For questions or malfunctions, please contact the Smeva installation partner who supplied your Market counter. No maintenance contract? No problem. We’re always here to help. For more information about our service, visit ... - Page 30 Dedicated to freshness www.smeva.com...
