- Page 1 USER’S MANUAL MARKET Smeva BV Address: J.F. Kennedylaan 27 5555 XC Valkenswaard Telephone: 040-2073200 Internet: www.smeva.nl Specifications of the manual: Version: 10-2013...
-
Page 2: Copyright
Copyright. (GB) Imprint This manual is published by Smeva BV Valkenswaard Nederland. No reproduction (including translation) is permitted in whole or in part e.g. photocopy, microfilming or storage in electronic data processing equipment, without the express written consent of the publisher. -
Page 3: Warnings
Warnings!!! STAFF AND SERVICE PERSONNEL HAVE TO READ THIS MANUAL BEFORE USING THE COUNTER. All dangerous parts are located outside the service area. Acces to this area is only allowed for staff and qualified engineers. Warning Labels: It is not allowed to remove any labels attached to the counter for instruction or safety. The following labels are used: Moving parts: Fan assemblies below bottom shelves. - Page 4 Cleaning: Before you start to clean the counter make sure that the power supply is switched off. Based on the product order specification a service switch is located underneath each counter section. If there is no service switch, switch off the electrical current by using the switch located in the central fuse box in the shop.
-
Page 5: Table Of Contents
Contents. Copyright Warnings!!! Contents 1 Introduction 2 Putting the Counter into service 2.1 External Influences 2.2 Load Arrangement and Use 2.3 Control Panel / Thermostat 3 Cleaning Instructions 4 General Maintenance Instructions. 5 End of lifecycle: Disassembly, Disposal. 6 Minor Malfunction List 6.1 General Failure 6.2 Partial Failure 6.3 Ice-Blocked Evaporator... -
Page 6: Introduction
Congratulations on your decision to purchase the Market serve-over counter from Smeva. The name Smeva is your guarantee of quality and reliability. The Market is a chilled, serve-over counter with open service access, characterises by a variety of versions. The counter is designed to display cold pre packed goods. And is not designed to cool down goods. -
Page 7: Putting The Counter Into Service
2 Putting the Counter into Service. For correct operation of the counter, the following instructions should be followed. 2.1 External Influences. - Avoid placing the counter in direct sunlight. Thermal radiation can raise the product temperature to an unacceptable level even when the air temperature display in the counter shows the required value. -
Page 8: Load Arrangement And Use
2.2 Load Arrangement. Before start to load the counter it must be carefully cleaned and have reached the required temperature. The serve-over counter is only mentioned for pre-packed goods. - Make sure that the display is loaded in the right way. Because it can affect the air circulation and temperature. -
Page 9: Control Panel / Thermostat
2.3 Control panel / Thermostat. Based on the product order, the counter is equipped with a various range of control units, types and fabrics. Like the service switch, the control unit is located underneath each counter section. For a detailed description and the operation of these control units, see the separate user’s manual for the control unit fitted in your counter. -
Page 10: Cleaning Instructions
Technical cleaning and removal of dust in the evaporator coil and air circulation system. Cleaning and inspection of the drainage system. Consult your Smeva dealer regarding maintenance inspections. 5 End of lifecycle, Disassembly, Disposal. By the development and material choice of the counter, a 15 year lifecycle is considered, depending on use and circumstances. -
Page 11: Minor Malfunction List
6 Minor Malfunction List. This list has been drawn up on the assumption that the counter has been functioning normally and that, while being used normally, malfunctions suddenly occur. 6.1 General Failure. If all of the functions have failed, check the power supply. Further check the fuses in the group box and in particular the group to which the counter is connected. -
Page 12: Product Identification
7 Product Identification. To provide you with rapid assistance in the event of questions or defects, your counter is equipped with a product identification label. Based on the product order specification, the product identification label is always situated at the bottom left side of the air discharge panel at the back. Should information be required concerning a particular component or if a component is defective, copy the information shown on this label and pass it on to your installer. -
Page 13: Technical Specifications
Each section based on 230VAC – 16 Amp. Max. connected as per corresponding circuit diagrams. The junction boxes display the necessary stickers for connecting. All technical specifications can be found in the corresponding datasheet. Which can be requested by your Smeva dealer. _________________________________________________________________12...
