- Page 1 User Manual Electric Vertical Broilers 11/2021 Models: 177VBE101A • 20 lb. Capacity 177VBE102M • 65 lb. Capacity Please read and save these instructions for future reference. Indoor use only.
-
Page 2: Table Of Contents
User Manual Please read and keep these instructions. For commercial use only. Index Important Safeguards .................... 3 Specifications ......................4 Installation ....................... 5 Operation ......................... 6 Daily Checking ......................7 Transportation & Storage ..................7 Cleaning & Maintenance ..................8 Circuit Diagram ......................10 Parts Diagram ...................... -
Page 3: Important Safeguards
User Manual Important Safeguards WARNING • DO NOT store gasoline or other flammable liquids in the vicinity of this or any other appliance. • Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the installation, operation and maintenance instructions thoroughly before installing or servicing this equipment. -
Page 4: Specifications
User Manual Specifications Meat Spit Model Voltage Power Plug Width Depth Height Capacity Height NEMA 177VBE101A 120V 1750W 2.5 RPM 20 lb. 12" 121/2" " " 5-15P NEMA 2.5 RPM 65 lb. 23" 19" " 177VBE102M 208/240V 4170/5550W 1/2" 6-30P... -
Page 5: Installation
Electrical Connection • Connect this unit to a grounded power socket with the appropriate voltage • 177VBE101A (NEMA 5-15P • 120V • 60 Hz) • 177VBE102M (NEMA 6-30P • 208/240V • 60 Hz) • The air switch for the power cord should be above 15A. -
Page 6: Operation
User Manual Operation Start Up Connect the right POWER SUPPLY according to the rating label on the machine. 2. Push or flip the MOTOR ON/OFF switch on, then the main meat-spit will rotate. 3. Flip the SWITCH on, the element will work. NOTE: 177VBE102M has (3) independently controlled elements. -
Page 7: Daily Checking
User Manual Operation (Continued) Cooking Meat Cones Turn the motor and elements on and let cook until browned outside. • MAKE SURE THE MEAT YOU SERVE IS FULLY COOKED! (Minimum Internal Temperature of 158° or higher for Beef & 170° for poultry or pork). We suggest that you further cook any poultry or pork product on a hot grill to ensure a 170°... -
Page 8: Cleaning & Maintenance
User Manual Cleaning & Maintenance Before Cleaning & Maintenance Cut the power off when cleaning is carried out. 2. Leave the unit until it cools down completely to avoid accidental burns. NOTICE: • DO NOT clean the heating elements. • DO NOT use a water jet to clean the appliance. - Page 9 User Manual Cleaning & Maintenance (Continued) Heavy/Baked-on Dirt, Grease, Residue Accumulation Apply cleanser to a damp cloth or sponge and rub cleanser on the metal in the direction of the polishing lines on the metal. 2. Rubbing cleanser, as gently as possible, in the direction of the polished lines will not mar the finish of the stainless steel.
-
Page 10: Circuit Diagram
User Manual Circuit Diagram 177VBE101A 177VBE102M www.AvantcoEquipment.com... -
Page 11: Parts Diagram
User Manual Parts Diagram 177VBE101A Name Name Name Heater Switch Motor Fixer Board Meat Seat Indicator Back Cover Meat Collector Base Terminal Block Oil Collector Clip Power Cord Fixer Connector of the Motor & Shaft Feet Power Cord & Plug... - Page 12 User Manual Parts Diagram 177VBE102M Name Name Name Oil Collector Oil Spillage Guard Back Board Switch Meat Pole Body Motor Top Beam Feet Motor & Meat Pole Terminal Block Base Board Connector Power Cord Fixer Meat Seat Power Cord Heater (NEMA 6-30P) www.AvantcoEquipment.com...
-
Page 13: Warranty
Avantco reserves the right to approve or deny the repair or replacement of any part or repair request. The warranty is not transferable. Avantco Equipment installed in/on a food truck or trailer will be limited to a period of 30 days from the original date of purchase.
