Migrating A Persistent Memory Module Encrypted With Remote Key Management - Hewlett Packard Enterprise 200 Series User Manual

Migrating a persistent memory module Migrating a persistent memory module encrypted with remote key management
Use this process to migrate persistent memory modules encrypted with remote key management. If local key management is enabled,
see Migrating a persistent memory module encrypted with local key management .
Prerequisites Prerequisites
Before migrating an encrypted persistent memory module, review and observe the Persistent memory module relocation guidelines.
Procedure Procedure
1. Log in to HPE iLO.
2. Click Administration in the navigation tree, and then click the Key Manager tab.
3. Make note of the following Key Manager Server entries.
This information is required to complete migration:
Primary Key Server Address
Primary Key Server Port
Secondary Key Server Address (if entered)
Secondary Key Server Port (if entered)
4. Make note of the Group name under Key Manager Configuration
This information is required to complete migration.
5. Power down the server.
6. Be sure to note the slot locations in which each DIMM and persistent memory module are installed, and then remove the
components from the server.
7. Install the DIMMs and persistent memory modules in the new server or on the new system board.
Be sure to observe the relocation guidelines when installing the DIMMs and persistent memory modules.
8. Power up the server.
9. Log in to HPE iLO.
10. Click Administration in the navigation tree, and then click the Key Manager tab.
11. Make the following entries under Key Manager Server entries.
This information must match the information recorded from the old server:
Primary Key Server Address
Primary Key Server Port
Secondary Key Server Address (if entered)
Secondary Key Server Port (if entered)
12. Enter the Group name under Key Manager Configuration
This entry must match the Group name recorded from the old server.
13. Reboot the server.
14. During POST, press F9 to access System Utilities.
15. From the System Utilities screen, select System Configuration
Encryption Options. Encryption Options
16. Select Remote from the Key Management menu.
17. Press the F12 F12 key to save and exit.
encrypted with remote key management
Key Manager Configuration .
Key Manager Configuration .
System Configuration > BIOS/Platform Configuration (RBSU)

Migrating a persistent memory module encrypted with remote key management

BIOS/Platform Configuration (RBSU) > Server Security Server Security > Device Device
103
