Joy-it Talking Pi Case Manual

Joystick remote control

Joystick Remote Control

Manual

Ausgabe 12.11.2018

Table of Contents

Need help?

Do you have a question about the Talking Pi Case and is the answer not in the manual?

Page 2 Talking Pi Case Dear customer, thank you for purchasing our product. In the following we have listed, what to consider during commissio- ning: Content • Case • 2x Joystick • Button • • Cableset Ausgabe 12.11.2018 Copyright by Joy-IT...
Page 3 Talking Pi Case 2. safety instructions Please observe the following safety instructions for protection against electric shocks and injuries. • Keep operating- and safety instructions! When passing the device to a other person, they must be handed with it. •...
Page 4 Talking Pi Case Assembly - remote control Open the case Remove the cover Equip the LED with the 4 individual cables and screw them with a screw in the case. Please mark the cables, so that you know later which contacts these have.
Page 5 Talking Pi Case Assembly - remote control Fit the push-button with the 4-pole (crossed, marked with cable tie) cable and attach it with two screws in the case. The second joystick with the 4-pin. Fit and install the cable. Now all cables lead through the existing opening to the outside and then the case can be closed.
Page 6 Talking Pi Case Service & Contact We are also there for you after your purchase. Should any questions remain unanswered or problems arise, we will also assist you by e-mail, telephone and ticket-support-system. E-Mail: service@joy-it.net Ticket-System: http://support.joy-it.net Telephone: +49 (0)2845 98469 – 66 (11- 18 a Clock on weekdays) For more information visit our website www.joy-it.net...
