Optimec Document No D20150-00
User Manual & Operating Instructions
Diameter
BCOR
Centre Thickness
Surface/Edge Inspection
Optimec JCF/F
Soft contact lens metrology
Highly Accurate
Bright, High Contrast Image
Quick & Easy to Operate
In built Saline Filtration
总代理：上海朗善光学仪器有限公司 www.lenser17.com
R
c
Optimec Limited 2016
Advertisement
Related Manuals for Optimec JCF/F
Summary of Contents for Optimec JCF/F
- Page 1 Optimec JCF/F Soft contact lens metrology Optimec Limited 2016 Optimec Document No D20150-00 User Manual & Operating Instructions Diameter Highly Accurate BCOR Bright, High Contrast Image Centre Thickness Quick & Easy to Operate In built Saline Filtration Surface/Edge Inspection 总代理：上海朗善光学仪器有限公司 www.lenser17.com...
- Page 2 User Manual & Operating Instructions CONTENTS Contents Front Cover - Photograph of JCF/F Instrument Page 1 - Contents Page 2 - Instrument Set-Up Details: Mirror Plate Page 3 - Cell Details: Cell Front View Page 4 - Cell Details: Cell Side View...
- Page 3 JCF/F Set Up Details Fitting the Mirror Plate THE MIRROR IS FRAGILE AND MUST BE TREATED CAREFULLY. CLEAN AS FOR ANY OPTICAL COMPONENT USING A GOOD QUALITY LENS CLOTH. THE UPPER MIRROR PLATE HAS BEEN DETACHED FROM ITS CABINET MOUNTS TO PROTECT IT DURING TRANSIT.
- Page 4 JCF/F Cell Details Cell Front View Focus and Centring Knob Drainage Tube Drainage Tube DO NOT Retaining REMOVE Clip Cell DO NOT Fixing REMOVE Screw Radius Radius Scale Wheel Mark Radius Radius Wheel Wheel Clamping Scale Screw IT IS IMPORTANT THAT THE TWO SCREW COVERS...
- Page 5 JCF/F Cell Details Cell Side View Focus and Centring Knob Drainage Tube Drainage Tube Retaining Clip Cell Fixing Radius Screw Scale Mark Radius Wheel Scale Radius Wheel Radius Clamping Wheel Screw 总代理：上海朗善光学仪器有限公司 www.lenser17.com Page 4...
- Page 6 JCF/F Cell Details Cell Top View Focus and Centring Knob LEFT: Surface Inspection Cell Probe ‘V’ Cylinder Centring Platform ‘V’Graticule RIGHT: Radius Cell Radius Wheel 总代理：上海朗善光学仪器有限公司 www.lenser17.com Page 5...
- Page 7 JCF/F Operating Instructions Fitting the Cell THE UPPER SCREWS ON THE SIDE MOUNTING BLOCKS ARE COVERED AND MUST UNDER NO CIRCUMSTANCES BE REMOVED. TO DO SO WILL RESULT IN BREAKAGE OF THE CELL. TO FIT THE CELL: 1. Carefully unpack the cell onto a scratch proof surface.
- Page 8 JCF/F Set-up Details Pump and Filter Tubing Peristaltic Pump Pump Inlet Pump Outlet Filter Filter Inlet Filter Outlet Power Switch (Green) Pump from Switch Pump Filter (Blue) Outlet Inlet 总代理：上海朗善光学仪器有限公司 www.lenser17.com Page 7...
- Page 9 JCF/F Set Up Details Cell Positioning Centre Thickness EQUAL Scale Probe Cylinder PARALLEL Screen Fixing Strip Viewing Mode Switch Power Pump Switch Switch (Green) (Blue) 1. When the cell is correctly positioned the view above will be seen. 2. The top face of the Cylinder should be parallel to the top of the Screen Fixing Strip.
- Page 10 JCF/F Operating Instructions Right: Radius Cell 1. Check that the Viewing Mode Switch is to the right. 2. Rotate the Radius Wheel clockwise to retract the probe in the Radius Cell until the BCOR reading is 9.5mm on the Radius Wheel Scale.
- Page 11 JCF/F Operating Instructions Left: Surface Inspection Cell 1. The contact lens is placed convex side up on a ‘V’ Graticule which slopes 10 degrees allowing the contact lens to slide into position against the ‘V’, and a plan view image of the whole contact lens is projected on to the screen.
-
Page 12: Best Practice
2. At end of day empty the cells through the drain tubes, rinse thoroughly with DI (distilled water) before drying the instrument. 3. When the JCF/F is not in use, always turn off the power and fit the dust cover. 4. Use lens cloths only for cleaning JCF/F optics. -
Page 13: Technical Specification
(+/-) 0.02 0.05mm Divisions 0.1mm Divisions The JCF/F is an electrical driven instrument and as such, if not used correctly, can be a source of electric shock and therefore could be hazardous to life if the following precautions IMPORTANT are not observed. -
Page 14: Guarantee Conditions
SETTING UP Guarantee Conditions The conditions and performance of Optimec instruments are guaranteed for a period of one year. The guarantee period commences from the date of sale. We guarantee the elimination of all faults arising from materials or manufacture. The guarantee will be fulfilled either by repair or replacement of faulty parts at our option. - Page 15 EC Declaration of Conformity 总代理：上海朗善光学仪器有限公司 www.lenser17.com Page 14...
- Page 16 Telephone +44 (0)1684 892859 Fax +44 (0)1684 893037 E-mail: enquiries@optimec.com www.optimec.com Optimec is accredited to BS EN ISO 9001:2008 For the provision of lens measuring and lens inspection instruments Certificate No. GB2002543 OPTIMEC is a Registered Trade Mark Internationally No. 2646632, 1159230, 102007762 总代理：上海朗善光学仪器有限公司 www.lenser17.com...
