Your new trimmer has been engineered and manufactured to Ryobi's high standard for dependability, ease of operation, and
operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual before
using this product.
Thank you for buying a Ryobi trimmer.
SAVE THIS MANUAL FOR FUTURE REFERENCE
OPERATOR'S MANUAL
30cc String Trimmers and Brushcutter
RY30000 Series
CS30
(RY30000, RY30000A,
RY30021, RY30021A)
SS30
(RY30002, RY30002A,
RY30041, RY30041A)
(RY30004, RY30004A,
RY30061, RY30061A)
BC30
Advertisement
Table of Contents
Related Manuals for Ryobi Ry30000, Ry30000a, Ry30021, Ry30021a
Summary of Contents for Ryobi Ry30000, Ry30000a, Ry30021, Ry30021a
- Page 1 Your new trimmer has been engineered and manufactured to Ryobi’s high standard for dependability, ease of operation, and operator safety. Properly cared for, it will give you years of rugged, trouble-free performance. WARNING: To reduce the risk of injury, the user must read and understand the operator’s manual before using this product.
-
Page 2: Table Of Contents
■ ■ ■ ■ ■ Warranty ... 25 - 26 Trimming weeds and grass is an easy task using Ryobi Trimmers and Brushcutters. Safety, performance, and dependability have been given top priority in the design of this string trimmer making it easy to maintain and operate. -
Page 3: General Safety Rules
WARNING: Read and understand all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious personal injury. READ ALL INSTRUCTIONS ■ For safe operation, read and understand all instructions before using this product. Follow all safety instructions. Failure to follow all safety instructions listed below, can result in serious personal injury. -
Page 4: Specific Safety Rules
Do not use any other cutting attachment. To install any other brand of cutting head to this string trimmer can result in serious personal injury. ■ ■ ■ ■ ■ Never operate unit without the grass deflector in place and in good condition. -
Page 5: Symbols
Some of the following symbols may be used on this tool. Please study them and learn their meaning for safe operation of this product. SYMBOL NAME Safety Alert Symbol Read the Operator’s Manual Wear Eye and Hearing Protection Keep Bystanders Away 50' 15m Ricochet No Blade... -
Page 6: Symbols
The following signal words and meanings are intended to explain the levels of risk associated with this product. SYMBOL SIGNAL MEANING DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury. -
Page 7: Specifications
Failure to do so could result in possible serious personal injury. PACKING LIST - CS30 ■ ■ ■ ■ ■ Trimmer Assembly ■ ■ ■ ■ ■ Owner’s Kit ■ ■ ■ ■ ■ Front handle ■... -
Page 8: Features
FEATURES CS30 STARTER (RY30000, RY30000A, GRIP PRIMER RY30021, RY30021A) BULB REAR HANDLE CHOKE LEVER COUPLER THROTTLE TRIGGER DRIVE SHAFT HOUSING FRONT HANDLE KNOB CURVED SHAFT GRASS DEFLECTOR STRING HEAD Fig. 1a Page 8... - Page 9 Page 9...
-
Page 10: Assembly
Slightly rotate the cap from side to side until the button locks into place. ■ ■ ■ ■ ■ The secondary hole in the attachment shaft can be used for hanging purposes as well. ASSEMBLY GUIDE RECESS BUTTON TRIMMER ATTACHMENT HOLE SECONDARY HOLE BUTTON Page 10 STRING TRIMMER SHAFT... - Page 11 ATTACHING THE FRONT HANDLE - CS30 AND SS30 See Figure 4. 1. Remove the front handle, bolt, flat washer, lock washer, and wing nut from the Owner’s Kit. 2. Install the front handle onto the top side of the drive shaft housing and move it to a comfortable position.
- Page 12 Page 12...
- Page 13 2. Adjust the strap to a comfortable position. CONVERTING FROM BRUSHCUTTER TO STRING TRIMMER - BC30 To convert from the brushcutter to the string trimmer, remove the blade and brushcutter guard, attach the straight shaft grass deflector and install the string head.
-
Page 14: Assembly
CONVERTING FROM STRING TRIMMER TO BRUSHCUTTER - BC30 To convert from the string trimmer to the brushcutter, remove the string head assembly and straight shaft grass deflector, attach the brushcutter guard and install the blade. REMOVING THE STRAIGHT SHAFT GRASS DEFLEC- TOR AND STRING HEAD See Figures 10 and 13. -
Page 15: Operation
To avoid burns from hot surfaces, never operate unit with the bottom of the engine above waist level. Hold the trimmer with the right hand on the rear handle and the left hand on the front handle. Keep a firm grip with both hands while in operation. - Page 16 CUTTING TIPS See Figures 16 and 17. ■ Keep the trimmer tilted toward the area being cut; this is the best cutting area. ■ The curved shaft trimmer cuts when passing the unit from right to left. The straight shaft trimmer cuts when passing the unit from left to right.
- Page 17 Page 17...
- Page 18 STARTING AND STOPPING See Figures 21, 22, and 23. Trimmer should be on a flat, bare surface for starting. 1. Slowly press the primer bulb seven (7) times. 2. Set the choke lever to the FULL CHOKE position (A). 3. Squeeze the throttle trigger fully and pull starter handle sharply until engine attempts to run.
-
Page 19: Maintenance
Failure to do so can cause poor performance, possible injury and may void your warranty. You can often make adjustments and repairs described here. For other repairs, have the trimmer serviced by an authorized service dealer. SPOOL REPLACEMENT NEW PREWOUND SPOOL See Figures 24 and 25. -
Page 20: String Replacement
STRING REPLACEMENT See Figures 26, 27, and 28. Use only monofilament string. Use original manufacturer's replacement string for best performance. String Diameter: CS30 - .080 in. (2.0 mm) SS30 - .095 in. (2.4 mm) BC30 - .095 in. (2.4 mm) 1. - Page 21 CLEANING THE EXHAUST PORT AND MUFFLER Depending on the type of fuel used, the type and amount of oil used, and/or your operating conditions, the exhaust port and muffler may become blocked with carbon deposits. If you notice a power loss with your gas powered tool, a qualified service technician will need to remove these deposits to restore performance.
-
Page 22: Maintenance
1. Drain all fuel from tank into a container approved for gasoline. Run engine until it stops. 2. Clean all foreign material from the trimmer. Store it in a well-ventilated place that is inaccessible to children. Keep away from corrosive agents such as garden chemicals and de-icing salts. -
Page 23: Troubleshooting
Contact a servicing dealer. If primer bulb fills, engine may be flooded, proceed to next item. 3. Remove spark plug, turn trimmer so spark plug hole is aimed at the ground. Move choke lever to “RUN” and pull starter cord 10 to 15 times. - Page 24 Grass wraps around 1. Cutting tall grass at ground level. driveshaft housing and string head: 2. Operating trimmer at part throttle. Oil drips from muffler: 1. Operating trimmer at part throttle 2. Check oil/fuel mixture. 3. Air filter dirty.
-
Page 25: Warranty
U.S. EPA standards for the first two years of engine use from the date of sale to the ultimate purchaser. Ryobi Technologies Inc. must warrant the emission control system on your nonroad or small off-road engine for the period of time listed above provided there has been no abuse, neglect, or improper maintenance of your nonroad or small off-road engine. - Page 26 EMISSIONS MAINTENANCE SCHEDULE AND WARRANTED PARTS LIST Emissions Parts Inspect Before Each Use AIR FILTER ASSY INCLUDES: FILTER ... X... X SPARK SCREEN ... X CARBURETOR ASSY INCLUDES: HEAT DAM GASKETS FUEL TANK ASSY INCLUDES: FUEL LINES ... X FUEL CAP ... X FUEL FILTER IGNITION ASSY INCLUDES:...
- Page 27 NOTES Page 27...
- Page 28 Now that you have purchased your tool, should a need ever exist for repair parts or service, simply contact your nearest Ryobi Authorized Service Center. Be sure to provide all pertinent facts when you call or visit. Please call 1-800-860-4050 for your nearest Ryobi Authorized Service Center.
