Minoston MP23W Quick Manual

Wi-Fi Outdoor Plug
( 2 Outlets )
Meet your new smart Plug !
+
A
B
C
For outdoor use
IP65 Rated
Note:
Do not plug an extension cord in this smart plug.
Note:
Your device may need to be within 100 feet of the controller to be
included. If so, include the device to the network within 10 feet of
the controller and relocate it to the desired position in your home.
Be sure to refresh the network if the device is included in this
manner.

APP Connection

QR code Smart Life
Note:
Your device needs to be installed in the network coverage of your home router.
1. Please scan the QR code to download the application "Smart Life".
2. If you cannot download Smart Life app, please search "Smart Life"
on Google Play (for Android phone) or Apple Store (for iOS phone) to
download.
After you download the Smart Life App and register a new account,
please follow the instructions below to set up your smart switch.
3. The smart switch can be also used with Amazon Echo and Google
Home. Please scan the QR code below and follow the instructions if
you have any trouble pairing with them.
• MP23W •
Plug x 1
Screw x 1
Plastic Anchor x 1
(A) Manual / Program button
Single press: manually turn on/off your
device simultaneously.
Hold 5s: initiate App-configured Mode
(B) Smart Outlet * 2
This is your smart outlets that will be
included in your smart home.
(C) Protector
Insert in connector when not in use.
100 feet
Amazon-Echo Google-Home

Introduction

The Minoston MP23W is an enabled 15A outdoor smart plug
designed for use for most residential lighting and motor applica-
tions. It's compatible with LED, halogen, incandescent, xenon,
fluorescent and compact fluorescent bulbs. Works with Amoazon
Alexa, Google Assistant.
One smart outlet, you can use free App, or voice control by Alexa
and Google Assistant to operate your devices in your home.

Specifications

Power: 120V AC, 60Hz
Total(Both Outlets):15 Amp Max
Wireless Frequency: 2.4GHz
Wireless Standard: IEEE802.11b/g/n
Operating Temp of -4° F~122° F
Please vertical hang on the wall.
The plug is designed to be angled 45 degrees,
allowing you to make the most of your home wall
outlet.
Use our screws and anchor to lock it in
the wall.(optional)
When the white LED is flash slowly (AP mode),
please hold the button 5 seconds until the LED
change to blinks rapidly--Back to EASY MODE.
Note:
1) Our products supports Bluetooth quick-fit and 2.4GHz Wi-Fi network.
2) 3 connection network modes: Bluetooth quick-fit Mode, Easy Mode, AP Mode.
Choose the most suitable mode to configure the network.
3) Please operate quickly when the white LED indicator blinks rapidly.
4) When indicator flash enters the network, complete standard operation
within the 3 minutes.
5) If you failed to connect with Wi-Fi network, please try to operate several
times more.
▶ Bluetooth quick-fit Mode ◀
1
1: Plug-in the device directly to the wall outlet.
Once pluged in, it will enter into the
Buletooth auto-connection mode.
The auto-connection comes with white LED
blinks. The LED will blinks 3 minutes.
If it stopped, please hold the button 5
seconds until the LED blinks again.
2
Always-On Dimmer
Outlet Outlet
2. Turn on your Phone bluetooth. 3: Tap '+' to add this plug
www.minoston.com
3
in the "Smart Life" APP.
