External enclosure Installation Manual
External Enclosure
RX343-S BLK/SLV
User's Manual
Hardware Assembly Guide
Please register your product at www.rosewill.com for complete
warranty information and future support.
If you have any question while using our products, please feel free to
contact us at
feedback@rosewill.com
We will do our best to help you.
Thank you for purchasing our product and we hope you will enjoy it.
External enclosure Installation Manual
STEP2 :
You will see the internal structure of the
Enclosure.
.
2
External enclosure Installation Manual
☆ Please follow the instructions and make sure
your hard drive is successfully installed to the
external enclosure!
STEP1 :
Take out the enclosure from Aluminum cover.
External enclosure Installation Manual
STEP3 :
Fit the 3.5" HDD SATA connector into
PCB's SATA connector.
Push the HDD toward the PCB and make
sure the connector is well connected.
1
3

Advertisement

loading
Need help?

Need help?

Do you have a question about the RX343-S BLK/SLV and is the answer not in the manual?

Questions and answers

Summary of Contents for Rosewill RX343-S BLK/SLV

  • Page 1 External enclosure Installation Manual External Enclosure RX343-S BLK/SLV User’s Manual Hardware Assembly Guide Please register your product at www.rosewill.com for complete warranty information and future support. If you have any question while using our products, please feel free to contact us at feedback@rosewill.com We will do our best to help you.
  • Page 2 External enclosure Installation Manual STEP4 : Screw the HDD on the enclosure tightly. External enclosure Installation Manual STEP6 : Screwed the two pieces together. External enclosure Installation Manual STEP5: Push the HDD prop into the Aluminum Cover. External enclosure Installation Manual STEP7 : Press the LED switch for power on/off.
