3. SOFTWARE

3.1. Getting Started

The board is factory configured with the U-boot loader and Ubuntu Linux programmed
into Flash memory. The software can be configured by using the console through the
JTAG serial port or over Ethernet using a Telnet session. Follow the
http://trac.gateworks.com/wiki/gettingstarted

3.2. Gateworks System Controller

The GSC Gateworks System Controller is a custom battery-backed micro-controller
designed by Gateworks to implement many of the embedded features found on the
board. A complete list of GSC features is shown in the table below. The GSC
communicates with the CPU over I2C and a GPIO signal configured as an interrupt.
Follow the http://trac.gateworks.com/wiki/gsc
information.

3.3. JTAG Programming

One method of programming the Flash with application
software is through the JTAG programming interface using
the GW16099 USB JTAG Programmer. The GW16099
USB JTAG Programming Adapter transfers the application
software from the developer's computer to the flash memory. Follow the
http://trac.gateworks.com
programmer is included in development kits of available
GATEWORKS.COM
Function
Real Time Clock
Voltage & Temperature Monitor
Configuration EEPROM
Fan Controller
System Specialized Functions
GPS Antenna Fault Monitoring
USB OTG System Boot
Panel LED
External Status LED
Panel Pushbutton Switch
External Pushbutton Switch
External Tamper Switch
Encryption Key Support
Programmable Sleep & Wake-up
GSC Flash CRC
GSC Revision
Gateworks System Controller Supported Functions
link for JTAG programmer instructions. The GW16099
3026 S. Higuera St San Luis Obispo, CA 93401
Venice Single Board Computer Operating Manual
link for additional software information.
link for complete GSC programming
Support
21 of 27
Yes
Yes
Yes
No
----
No
Yes
Yes
No
Yes
No
Yes
Yes
Yes
Yes
Yes
