LEVELING SHIM FOR FIBERGLASS SKIMMER
INSTALLATION INSTRUCTIONS
25160-000-007
IMPORTANT SAFETY INSTRUCTIONS. READ AND FOLLOW ALL INSTRUCTIONS
Follow all applicable local and national regulations (e.g. NEC, CEC whichever is applicable) during
CAUTION
installation of the skimmer.
Plug equalizer line with plug using NSF listed PVC cement.
DANGER
Do not stick hand into the skimmer pipe below the basket while the pump is running.
DANGER
Risk of hair or body entrapment, drowning or disembowelment. Equalizer fittings can trap hair or body
DANGER
parts causing severe injury or death.
Follow all necessary precautions when connecting a vacuum pump and cleaning the skimmer. Avoid
WARNING
using a cracked or damaged skimmer. Do not step on cracked skimmer plate. Max weight 300 lbs.
WARNING
Provide more than one suction source in pool system at all times.
®
C-M-P.COM
4-2850-01 RevA
