XK X130-T Quick Start Manual

XK X130 - T 2.4GHz 4CH RC Racing Drone
Description:
XK X130 - T 130mm RC racing drone is an extraordinary indoor racer with 6-axis
gyroscope, 1020 coreless motors and impact-resistant 1.5mm thick carbon fiber
chassis. You are allowed to choose different flight mode, 3D / 6D Mode. 3D Mode
makes it possible to carry out aerobatics; while the 6D Mode is for much more stable
flight. In addition, the transmitter has an LCD screen which indicates the real-time flight
status for you.
Main Features:
●600TVL CMOS camera with 120-degree FOV. 5.8G real-time FPV within 250m range
● High-performance flight with powerful 1020 coreless motors and 66mm propellers
●2.4GHz 4CH LCD transmitter for real-time flight status, compatible with BS - FHSS
protocol
● Powered by 3.7V 700mAh 25C LiPo battery, it can fly continuously for about 8
minutes
Specifications:
Wheelbase: 130mm
Frame material: carbon fiber
Frame thickness: 1.5mm
Motor: 1020 coreless
Propeller: 66mm ( diameter )
6-axis gyroscope: yes
Video transmitter: 5.8G 32CH 25mW
Image transmission distance: 250m
Sensor: 1/4 inch CMOS
Video resolution: 600TVL
TV system: NTSC ( 640 x 480 )
Lens: H: 120 degree; V: 100 degree
Specification
General
Motor
Remote
Controller
Specification
s
Brand: XK
Type: Frame Kit
Version: RTF
Model: 1020
Motor Type: Brushed Motor
Channel: 4-Channels
Remote Control: 2.4GHz Wireless Radio Control
Mode: Mode 2 (Left Hand Throttle)
Control Distance: 100-300m
Detailed Control Distance: About 200m
FPV Distance: 250m
Transmitter Power: 4 x 1.5V AA (not included)
