SAFETY ISOLATING LOW VOLTAGE TRANSFORMERS
Read and follow the safety instructions listed below and other basic safety precautions before installation or
operation of this transformer and other associated equipment.
WARNING
Risk of Fire or Electrical Shock
• If installation involves running wire through a building structure, special wiring methods are needed.
• Do Not submerge transformer.
• Do Not exceed the maximum ratings of individual components, wiring devices, and current carrying capacity of conductors.
• Select cable for each secondary output in accordance with tables in this manual.
• Select power source by combining bulb wattage.
These Safety Transformers are specifically designed to supply 12 VAC to swimming pool and
spa luminaires.
Canada Only:
For pre-installed plugged versions LVX50P & LVX100P, please ensure transformer is connect to a
CLASS A type GFCI protected outlet
Installation must comply with provisions of the National Electrical Code, ANSI/NFPA 70, including those in
Article 680 - Swimming Pools, Spas, Fountains and Water Features.
The LVX transformer supports the use of 1/2" and 3/4" conduit connections on the under side of the
unit. When using 3/4" conduit connections, remove break away as shown.
1.
Remove port
caps from the
required ports
WWW.SPAELECTRICS.COM
SAFETY
REMOVING KNOCKOUT
2.
Using a pair of
side cutters cut
the internal ring
supports
1
INSTALLATION
OPERATION &
SERVICE MANUAL
3.
Remove the
internal ring
from the conduit
port.
