Milkcan Zurich 251 Assembly Instructions

Zurich Fence Letterbox
Tools Contents
Required
Your carton should contain the
- Drill following parts:
- Timber Drill Bits 1 x Front Panel
- Tape Measure 1 x Back Box
1 x Accessories Bag
- Jigsaw

Choosing a Suitable Location

The letterbox can be either mounted into a timber fence,
or built into a brick or block wall.
it in a location that is easily accessible to Australia Post
and couriers. The recommended height for the mail slot
is 90 to 120cm from the ground.

Removing the Front Panel for Installation

Firstly, remove the front panel by unscrewing the 6 x mounting nuts
1. Open the front parcel door
2. Open the rear door and unscrew the 4 x mounting nuts
3. Reach through the front parcel door and unscrew the 2 x top mounting nuts
4. Gently pull the front panel to remove it from the back box

Timber Fence Installation

1. Measure the back box, mark and cut
a slightly larger hole into the fence
using a jigsaw.
2. Slide the back box through the front
of the fence. Screw it to the fence with
the screws provided (for hardwood
fences, it is easier to pre-drill the
screw holes).
You will need to install
Front
Front
Panel
Parcel
Door
Centre
Mounting
Stud
Bottom
Mounting
Stud
3. Attach the front panel by inserting the 4 x mounting studs
through the corresponding holes in the back box.
Reach through the back door and secure with the nuts provided.
Reach through the front parcel door
and secure the 2 x top mounting nuts.
56 Northgate Drive,
Thomastown VIC 3043
www.milkcan.com.au
support@milkcan.com.au
(03) 9464 6964
251
Top
Mounting
Stud
Back
Box
Front
Flange
1.0
