Milkcan Ascot Pillar 790 Installation Instructions

Ascot Pillar
Tools
Required
- Hammer Drill
- 10mm Masonry Drill Bit
- Spirit Level
Choosing a Suitable Location
You will need to install it in a location that is easily accessible to Australia Post and couriers.
Installation onto an existing concrete oor
1. Place your letterbox in
the chosen location and
mark the mounting hole
with a pencil.
2. Drill a hole (10mm diameter x
70mm deep) into the concrete
oor for the mounting bolt.
3. Place the letterbox back over the concrete hole just drilled.
To bolt the letterbox to the concrete oor, refer to the
steps below.
Installation using the expansion bolt
1. Check the nut on the expansion bolt has not been tightened, it needs to be loose.
2. Insert the expansion bolt into the concrete through the hole in the base of the letterbox.
3. Tap the expansion bolt fully down. If you encounter some resistance, you may need
a hammer to tap the bolt further into the concrete.
4. Tighten the nut with the tube spanner provided.
56 Northgate Drive,
Thomastown VIC 3043
www.milkcan.com.au
support@milkcan.com.au
(03) 9464 6964
790
Installation onto ground
You will need to install a small concrete slab that is suitable for your
parcel letterbox to be bolted onto.
1. Dig a hole approximately
45cm x 35cm x 10cm deep.
2. Fill hole with concrete.
3. Use a spirit level to level the
concrete and then leave it to
fully dry.
4. Place your letterbox onto the
concrete slab and mark the
mounting hole with a pencil.
5. Drill a hole (10mm diameter x
70mm deep) into the concrete
slab for the mounting bolt.
6. Place the letterbox back over the concrete hole just drilled. To
bolt the letterbox to the concrete oor, refer to the steps below.
