ZB Bridge-P
User manual V1.0
New Zigbee Bridge
· 中
文 -----------1-5
· FCC Warning--------11
· English----------6-10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZB Bridge-P and is the answer not in the manual?

Questions and answers

Related Manuals for Sonoff ZB Bridge-P

Summary of Contents for Sonoff ZB Bridge-P

  • Page 1 ZB Bridge-P User manual V1.0 New Zigbee Bridge · 中 文 -----------1-5 · FCC Warning--------11 · English----------6-10...
  • Page 2 中⽂ Shenzhen Sonoff Technologies Co., Ltd. 产品介绍 Zigbee信号指⽰灯(绿⾊) Wi-Fi信号指⽰灯(蓝⾊) 输⼊接⼝ 配对按钮 设备重量＜1Kg， 建议安装⾼度＜2⽶。 信号指⽰灯状态说明 状态说明 状态 Zigbee配⽹模式 蓝灯两短⼀⻓闪烁 蓝灯快闪 兼容模式(AP) 蓝灯常亮 设备在线 蓝灯快闪⼀下 未连接路由 蓝灯快闪⼆下 已连接上路由器， 但未连接到云端 蓝灯快闪三下 固件升级中 绿灯慢闪 搜索添加⼦设备中 产品特点 本设备是⼀款Zigbee多功能⽹关， ⽹关通过Wi-Fi转Zigbee的⽅式进⾏连接控制多种Zigbee 设备， 实现远程控制该设备的开和关、 设置智能定时和分享给您的家⼈⼀起控制等等。 使⽤说明 1.下载“易微联”APP 易 微 联 eWeLink Android™...
  • Page 3 中⽂ Shenzhen Sonoff Technologies Co., Ltd. 2.上电 使⽤MicroUSB线给设备通电。通电后，设备⾸次使⽤，默认进⼊Zigbee配⽹模式,  Wi-Fi指 ⽰灯 呈“两短⼀⻓闪烁”。 三分钟内没有进⾏配⽹，设备将退出Zigbee配⽹模式。如需再次进⼊，⻓按配对按钮5秒直 到 Wi-Fi指⽰灯呈两短⼀⻓闪烁即可。 3.添加Zigbee⽹关 添加设备 所有设备 快速添加 适用于大部分易微联生态设备 扫码添加 声波添加 GSM 类设备和附带 适用于摄像头等支持 二维码的设备 声波配对设备 Zigbee配网 适用于Zigbee配网 点击“+”，选择“Zigbee配对”，再根据App提⽰进⾏操作。...
  • Page 4 如使⽤Zigbee配对模式配⽹失败，请使⽤“兼容模式(AP)”进⾏配对。 ⻓按配对按钮5秒直到Wi-Fi指⽰灯呈 “两短⼀⻓闪烁” 状态， 松开。 再次⻓按配对按钮5秒 直到Wi-Fi指⽰灯呈 “快闪” 状态， 此时设备进⼊兼容模式。 在app界⾯，点击“+”，选择“兼容模式”。 先把移动设备连接上Wi-Fi账号为： ITEAD-******， 密码为： 12345678， 然后回到 “易微联” app， 点击 “下⼀步” ， 等待配对完成。 产品参数 型号 ZB Bridge-P 输⼊ ⽆线连接 Wi-Fi IEEE 802.11 b/g/n 2.4GHz，Zigbee 3.0 App⽀持系统 Android & iOS ⼯作温度 -10℃~40℃...
  • Page 5 中⽂ Shenzhen Sonoff Technologies Co., Ltd. 取消报警声 通过场景联动触发⽹关声⾳报警， 可通过以下任意⽅法静⾳： 1.⽤卡针短按⽹关配对按钮。 2.在eWelinkApp⽹关⻚⾯点击红⾊喇叭图标。 3.通过场景联动设置使⽹关静⾳。 设备当前⽀持的Zigbee⼦设备 品牌 SONOFF eWeLink BASICZBR3 SNZB-01 SNZB-01P SA-003-UK SA-003-US ZBMINI SNZB-02 SNZB-02P ZBMINI-L SNZB-03 SNZB-03P 产品型号 S31 Lite zb SNZB-04 SNZB-04P S40ZBTPA Lite S40ZBTPB Lite S26R2ZB (TPE/TPG/TPF) 后续持续增加⽀持的Zigbee⼦设备。...
  • Page 6 中⽂ Shenzhen Sonoff Technologies Co., Ltd. 恢复出⼚设置 在eWeLinkApp端“删除设备”，设备即恢复出⼚设置。 常⻅问题 Wi-Fi设备与eWeLinkAPP配对失败。 1.确保设备处于配对模式。 三分钟内没进⾏配⽹， 设备将⾃动退出配对模式。 2.请开启定位服务并允许定位权限。 在选择Wi-Fi 络之前， 请开启定位服务并允许定位权限。 位置信息权限⽤于获取Wi-Fi列 。 果单击禁⽤， 您将⽆法添加设备。 3.确保您的Wi-Fi 络为2.4GHz频段。 4.确保您输⼊了正确的Wi-FiSSID和 码， 没有包含特殊字符。 密码错误是配对失败的⼀个 ⾮常常⻅的原因。 5.配对时设备应靠近路由器， 以保证良好的传输信号条件。 Wi-Fi设备 “离线” 问题， 请通过Wi-FiLED指⽰灯状态检查以下问题： LED指⽰灯每2 闪烁⼀次， 表⽰您⽆法连接到路由器。 1.可 您输⼊了错误的Wi-FiSSID和 码。 2.确保您的Wi-FiSSID和...

  • Page 7: Product Introduction

    Shenzhen Sonoff Technologies Co., Ltd. English Product Introduction Zigbee LED indicator(Green) Wi-Fi LED indicator(Blue) Input Pairing button The device weight is less than 1 kg. The installation height of less than 2 m is recommended. LED indicator status instruction LED indicator status Status instruction Zigbee LED Pairing Mode Blue LED flashes (one long and two short)
  • Page 8 Shenzhen Sonoff Technologies Co., Ltd. English 2. Power on Power the device through Micro USB cable. After powering on, the device will enter the Zigbee Pairing Mode during the first use. The Wi-Fi LED indicator changes in a cycle of two short and one long flash and release.

  • Page 9: Specifications

    Tap “+” and select “Compatible Pairing Mode ” on APP. Select Wi-Fi SSID with ITEAD-****** and enter the password 12345678, and then go back to eWeLink APP and tap “Next”. Be patient until pairing completes. Specifications ZB Bridge-P Model Input Wi-Fi IEEE 802.11 b/g/n 2.4GHz，Zigbee 3.0...

  • Page 10: Factory Reset

    1. Press the gateway pairing button with a SIM Pick. 2. Click the red “speaker” icon on the gateway interface of eWeLink App. 3. Mute the gateway through scene control settings. Currently supported Zigbee sub-devices Brands SONOFF eWeLink BASICZBR3 SNZB-01 SNZB-01P...

  • Page 11: Common Problems

    Shenzhen Sonoff Technologies Co., Ltd. English Common Problems Fail to pair Wi-Fi devices to eWeLink APP 1. Make sure the device is in pairing mode. After three minutes of unsuccessful pairing, the device will automatically exit pairing mode. 2. Please turn on location services and allow location permission. Before choosing the Wi-Fi network, location services should be turned on and location permission should be allowed.

  • Page 12: Fcc Warning

    FCC Warning Shenzhen Sonoff Technologies Co., Ltd. FCC Warning Changes or modifications not expressly approved by the party responsible for compliance could avoid the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 13 Hereby, Shenzhen Sonoff Technologies Co., Ltd. declares that the radio equipment type ZB Bridge-P is in compliance with Directive 2014/53/EU.The full text of the EU declaration of conformity is available at the following internet address: https://sonoff.tech/usermanuals The FCC IDs of ZigBee sub devices supported by the current device are as follows：...
