Page 2: Safety Precautions And Warnings
Do not use with incompatible components or alter this product in any way outside of the instructions provided by VolantexRC Co.,Ltd.. This manual contains instructions for safety, operation and maintenance. It is essential to read and follow all the instructions and warnings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid damage or serious injury. -
Page 3: Box Contents
Battery and Charging Warnings CAUTION: All instructions and warnings must be followed exactly. Mishandling of Li-Po/Li-Ion/Ni-Mh Li-Ion/Ni-Mh battery. - By handling, charging or using the included battery, you shall assume all risks associated with Li-Po/Li- Ion/Ni-Mh battery. - If at any time the battery begins to balloon or swell, discontinue use immediately. If charging or discharging, you should discontinue and disconnect. -
Page 4: Getting Started
Boat Batteries Installation 1. Rotate the hatch of the hull cover by clockwise to unlock the hatch. 2. Open the hull cover. 3. Adhere included hook tape to the battery. 4. Secure the battery to the hook tape in the boat. Check Radio System CAUTION: Always keep all body parts, hair and dangling or loose items away from a spinning propeller, as these can be entangled. - Page 5 WARNING: DO NOT TURN OFF THE TRANSMITTER BEFORE UNCONNECTING BATTERY OF RECEIVER, OR THE RECEIVER MAY PICK UP STRAY SIGNALS AND RUN OUT OF CONTROL TO CAUSE ACCIDENT! NOTICE: Always store the boat with hatch removed to prevent mold and mildew growth inside the hull. Test Your Boat in Water 1.
-
Page 6: Maintenance
Maintenance Always replace the shaft when it is damaged or shows visible wear or injury and property damage may result. Lubricating the shaft is vital to the life of the drivetrain. The lubricant also acts as a water seal, keeping Lubricate the shaft, propeller shaft and all moving parts after every 2-3 hours of operation. -
Page 7: Charging Instruction
After Boating - Always power off the receiver before powering off the transmitter to maintain control of the boat and to retain transmitter binding. - Disconnect the battery from the receiver and remove the batteries from the boat. - Fully dry the inside and outside of the boat, including the water cooling lines and jackets around the motor and ESC. - Page 8 Problem Possible Cause Solution Loosen coupling at shaft and move away Drive dog is too close shaft a small amount Reduced runtime or Too little lubrication on shaft Fully lubricate shaft boat underpowered Vegetation or other obstacles block Remove boat from the water and obstacles the rudder or propeller Move powered transmi tter a few feet from Transmitter is too near boat during...
- Page 9 Troubleshooting Guide Antenna Steering Trim Dual Rate Function Throttle Reverse Steering Reverse ON/OFF Switch Indicator LED Steering Wheel Throttle Trigger 9 / 12...
- Page 10 ON / OFF Switch Battery LED Monitor Solid red: Slide the switch Battery is in good up for on and condition (above down for off 4.3V) Flashing red: Battery is at low voltage Replace batteries (below 4.3V) Dual Function S w i t c h u p f o r l a r g e r Switch down for smaller servo angle servo angle...
- Page 11 Steering Trim Steering Trim The steering trim dial is used to adjust the steering trim when the wheel is centered. Rotating the dial changes the steering trim (the steering at rest position). Normally, the steering trim is adjusted until the vehicle tracks straight. Receiver Connection and Binding code of a single specific transmitter.
- Page 12 Rotate the steering wheel clockwise while holding the trigger to turn right. If the steering is not tight enough, switch up the Dual Function knob to gain larger servo angle. Rotate the steering wheel counter-clockwise while holding the trigger to turn left. If the steering is not tight enough, If the steering is not tight enough, switch up the Dual function knob to gain larger servo angle.
