INSTALLATION INSTRUCTIONS
PLUG-IN Digital Door Chime
Model No: CHM0155
Please install and operate this product according to the following instructions.
'Receiver' means the Indoor Chime unit.
CONTENTS
Receiver x1
NAMES FOR PARTS
Receiver front side
(1) LED Indicator
(2) Speaker
(3) Hanging Hook
Transmitter x1
1
4
5
6
2
(4) Auto Learn Button
(5) Melody Selector
(6) Volume Selector
'Transmitter' means the Exterior Door Press.
Belt Clip x1
A "screw-on"
belt clip for
portable use
Receiver back side
1
Battery x1
Type 23A12V
Transmitter
3
7
(7) Battery Cover
(8) Door Press
(9) New Plate & Cover
Instruction Manual x1
8
9
Advertisement
Related Manuals for SImx CHM0155
Summary of Contents for SImx CHM0155
- Page 1 INSTALLATION INSTRUCTIONS PLUG-IN Digital Door Chime Model No: CHM0155 Please install and operate this product according to the following instructions. ‘Receiver’ means the Indoor Chime unit. ‘Transmitter’ means the Exterior Door Press. CONTENTS Receiver x1 Transmitter x1 Belt Clip x1...
- Page 2 INSTALLING THE BATTERY Receiver Unit Insert 3 x AA Alkaline batteries into the compartment at rear of the Receiver. Transmitter Unit • To open the housing, firstly remove the name plate cover. Using a flat head screwdriver, insert this into the slot on the base of the unit. The rear should pop open. Lever the cover off. •...
- Page 3 AFFIXING THE PRODUCTS • The Receiver can be hung on a wall with a screw, table top mounted, or portable with the (included) belt clip. • Affix the door press to a smooth surface with double sided tape and screws as required. Before you drill any hole in the wall, please make sure there are not cables or pipes that may be accidentally damage.
- Page 4 ELECTRICAL COMPLIANCE This product complies to all relevant NZ/AU compliance standards. An SDOC (supplier compliance declaration) is available on www.simx.co.nz Type the product code into Search on the home page, this takes you to the item product page, a download link is located below the product details on that page.
