USE OF ELECTRIC SCOOTERS
LEGAL WARNING:
• United Kingdom law – This e-scooter is not to be used on public roads, cycle paths or
pavements.
• Only to be used on private land and with the landowner's permission.
IMPORTANT!
Read these instructions carefully and keep for future reference
Do not use the e-scooter when under the influence of medication or alcohol.
The user should check the limits of use in accordance with the local regulations (e.g. use in
pedestrian areas, on-road).
Watch for pedestrians and others in your vicinity when riding.
Always wear a helmet and suitable footwear when riding this e-scooter.
Ensure your battery is fully charged before use.
This product is not a toy, and is intended for riders aged 16+ years.
PLEV Class 2 - Designed to carry a single rider.
Do not use this e-scooter in rain, snow or icy conditions.
Read this manual and all warning labels on the product before using this product.
HORNET
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for busbi HORNET
Summary of Contents for busbi HORNET
- Page 1 HORNET USE OF ELECTRIC SCOOTERS LEGAL WARNING: • United Kingdom law – This e-scooter is not to be used on public roads, cycle paths or pavements. • Only to be used on private land and with the landowner’s permission. IMPORTANT! Read these instructions carefully and keep for future reference Do not use the e-scooter when under the influence of medication or alcohol.
- Page 2 Additional Information For more guidance and support videos to help you get started, please visit: busbistore.com/videos or, simply open the camera app on your mobile phone, and point the camera at the QR code below: Warnings The following symbols and words are used in this user manual to signal and warn against personal injury or damage to property.
-
Page 3: Table Of Contents
6.5. Changing the brake pads. 3.1 Assembly. 7. Cleaning and Storage. 3.2 Brake Cables – Fitment. 8. Further Guidance for safe use. 3.3 Folding and Unfolding the Busbi 8.1. Weight limits. Hornet. 3.4 Charging. 8.2. Maximum travel distance. 3.4.1 Connect the Charger. -
Page 4: General Information
1. General Information: This instruction manual will provide you with the information you need to use and maintain your Busbi Hornet e-scooter . Please read and retain these instructions for future use. This manual contains important instructions for safety and care. - Page 5 • Wear appropriate footwear when using this e-scooter. • Your Busbi Hornet has a waterproof rating of IPX4, this means your Busbi Hornet is protected against splashes of water. • This e-scooter must be properly maintained according to these instructions.
-
Page 6: Getting Started
Attention: Please fully charge your Busbi Hornet before first use. Your Busbi Hornet e-scooter is a two wheeled electric scooter, powered by a Lithium-ion battery located inside the frame of the foot deck, and a hub motor incorporated in the rear wheel. - Page 7 Front Brake Handle Rear Brake Handle (with bell) Rubber foot deck. Locking Hook (Used when folded) Display LH Handle Bar Grip RH Handle Bar Grip Handlebar Stem Throttle Function Switch Stem Clasp Side Reflector Rear Mud Guard Locking Buckle (Used when folded) Front mud guard Rear light Disc Brake...
-
Page 8: Preparing For First Use
3. Preparing for first use: 3.1 Assembly. Open the box and carefully take out all the parts, taking care to support the handlebars as you lift the scooter from the packaging. Please retain the packaging, this will allow return of the product in the event of any problems. -
Page 9: Folding And Unfolding The Busbi
3.3 Folding and Unfolding the Busbi Hornet. Unfold the handlebar stem: • Press the side of the locking hook to open and release it from its locking buckle. • Pull the hook out of the locking buckle. • Lift the Handlebar Stem into a vertical position. -
Page 10: Riding Your Busbi Hornet
Altered balance and handling characteristics due to additional weight. Risk of serious injury. Do not hang bags or items on the locking hook. 4. Riding your Busbi Hornet. Step 1: Before each use of the e-scooter carry out the Pre-Use Inspection Schedule that can be found in Table 1, Annex A at the end of this manual. - Page 11 Keep your body balanced when turning to avoid falling over due to high speeds or a shifting centre of gravity. Step 6: Once you have finished riding your Busbi Hornet, press and hold the On/Off button for 3 seconds to turn the scooter off.
-
Page 12: Braking
4.1. Braking • To slow down, simply release the throttle. • To brake, do not pull the brake levers too hard or abruptly. • The left brake lever activates the rear brake, the right lever activates the front brake . •... -
Page 13: Display Screen
Risk of loss of property. The Pin Lock does not prevent theft of the e-scooter. Owners are advised to buy additional security device such as a bike lock. 4.2.2. Unlocking the Busbi Hornet (Pin Code - factory default: 000) •... -
Page 14: Pin Lock Function
4.2.3 Pin Lock Function - Activating/Deactivating. Press the “On/Off” button for 3 seconds to switch on the scooter. Simultaneously press and hold the “On/Off” and “+” buttons for 5 seconds to activate/deactivate the code lock feature. 4.2.4. Changing the Pin Lock Code •... -
Page 15: Battery Charging
Do not short-circuit the charger pins using a metal object. • Disconnect the charger from the mains power source before connecting and disconnecting from the Busbi Hornet e-scooter. • The external flexible cable of this product cannot be replaced; If the cord is... -
Page 16: Charging Procedure
Allow the battery to cool for 30 minutes after riding your Busbi hornet. • If your Busbi Hornet stops working due to overheating, place it in a cool, dry place and wait for the battery and hub motor to cool before using it again. -
Page 17: Battery Service Life
NOTE Do not use the Busbi Hornet when the battery is low or the system requires a safe shutdown. Battery service life will be shortened if you continue to use the Busbi Hornet while the battery voltage is low. -
Page 18: General Maintenance
Contact your nearest dealer. 6.2. Brake Adjustment and Maintenance: Wear and tear of the braking system is normal after frequent use of the Busbi Hornet. Some adjustment of the braking system will be required to maintain effective braking. The following procedures should be followed: 6.3. -
Page 19: Brake Discs
Do not wash your Busbi Hornet with alcohol, petroleum, acetone, or other corrosive solvents. These substances may damage the appearance and internal structure of your Busbi Hornet. Do not wash your Busbi Hornet with a power washer or hose. WARNING Ensure your Busbi Hornet is powered OFF and the charging cable is unplugged before cleaning;... -
Page 20: Further Guidance For Safe Use
Do not modify your Busbi Hornet, this will invalidate any warranty and may reduce performance, cause damage and potentially cause serious injury. • Do not fit accessories or additional items to Busbi Hornet that are not approved by the manufacturer. •... -
Page 21: Weight Limits
• Exceeding the maximum weight or not meeting the minimum load weight of 20kg may cause the user to fall or be injured and may damage the Busbi Hornet. • Failure to comply with the recommendations may result in the Busbi Hornet losing its ability to safely decelerate or stop while going downhill. -
Page 22: Safety Features
9. Safety Features. Lighting. The LED lighting fitted to your Busbi e-scooter is powered by the scooter battery and consists of two lighting and reflector assemblies; a white headlight and red rear light assembly performing as a tail and brake light. -
Page 23: Busbi - Reducing Waste
10. Busbi - Reducing Waste: Here at Busbi we do everything we can to use little or no plastic in the packaging of our products. The packaging that your Busbi Hornet has been protected by, and delivered in, has been designed to be minimalistic and plastic free. In addition, there are no coloured inks or varnishes used on the cardboard packaging, allowing ease of recycling. -
Page 24: Annex A
Annex A Before each and every use, carry out the inspection schedule described below: Table 1 - Inspection Schedule Check and confirm all screws and fasteners are tightened All parts. correctly. • Ensure folding system is free from debris and obstructions. •... - Page 25 Table 2 – Hornet Specifications Battery 36 V 7.8AH Hub Motor 350W Average 500 W Maximum. Range Up to 28 km Charging Charge port Splash Resistant IP X4 (Can withstand splashing of water) Lights Front LED, automatic rear LED Braking...
- Page 26 Table 5 - Battery specifications Type Lithium-ion Nominal Voltage Capacity 7.8 Ah Number of cycles (≥70% capacity) 500 cycles Maximum input 42V DC 2 Amp...
-
Page 27: Declaration Of Conformity
A copy of the Technical File for this equipment is available from the address above. DESCRIPTION OF EQUIPMENT: Model: TT-EL-H101 Marketed as: Busbi Hornet. Designated as a Personal Light Electric Vehicle. (PLEV) Class 2. An adult electric kick scooter, designed for recreational use. EAN: 5051868 188497 451870 Serial Number: BH/101/XX/202X/XXXX... - Page 28 Rating Plate: found on the underside of the foot deck of your Busbi Hornet: Sequential serial number Brand: Busbi BH/101/XX/202X/XXXX Designation: PLEV (Class 2) EN 17128 Model: HORNET (TT-EL- WARNING: H101) Read the instruction manual and all warning DOM: March 2022 labels on the product before using this product.
- Page 29 For more guidance and support including videos to help you get started, please visit: busbistore.com/scooters/ or, simply open the camera app on your mobile phone, and point the camera at the QR code below: HORNET...
