- Page 1 Additional operating instructions according to ATEX 2014/34/EU Particle Filter Box Model FKF SCHAKO KG Steigstraße 25-27 D-78600 Kolbingen Telephone +49 (0) 74 63 - 980 - 0 Fax +49 (0) 74 63 - 980 - 200 info@schako.de schako.com...
-
Page 2: Table Of Contents
Additional operating instructions according to ATEX 2014/34/EU for FKF particle filter box Contents General conditions ..........................3 General description and instructions ............................3 Personnel qualification and training ............................3 Safety-conscious work ................................3 Designated use ..................................3 Delivery and storage .................................. 3 Mounting information ................................ -
Page 3: General Conditions
Additional operating instructions according to ATEX 2014/34/EU for FKF particle filter box General conditions General description and instructions Delivery and storage Upon receipt, the devices must be checked for completeness and transport damage. If delivered incompletely or damaged, the forwarding company and the SCHAKO KG have to be in- formed immediately. -
Page 4: Description
Additional operating instructions according to ATEX 2014/34/EU for FKF particle filter box Description Sealing on the particle filter The FKF particle filter box with fluid seal on the filter cell has been specially developed for use in cleanrooms as required by Fluid... - Page 5 Additional operating instructions according to ATEX 2014/34/EU for FKF particle filter box Special conditions - It must be ensured that all metal components, in particular the filter frame, are properly and permanently connected to the equipotential bonding. Note on operation - In the case of a manually operated shut-off damper, care must be taken to operate the cable slowly.
-
Page 6: Models And Dimensions
Additional operating instructions according to ATEX 2014/34/EU for FKF particle filter box Models and dimensions Dimensions FKF-H-...-M000-D1-... Mounting bracket with long hole ø 10 x 20 external approx. Connection to earth external FKF-H-...-M001-D1-... approx. Connection to earth Available sizes NW Filter dimen- øD... - Page 7 Additional operating instructions according to ATEX 2014/34/EU for FKF particle filter box FKF-V-...-M000-D1-... external Connection to earth FKF-V-...-M001-D1-... external Connection to earth Available sizes FDQJ-Z / FDQJ-A FPIL-A / FDAV-A FPIL-Z / FDAV-Z (Supply air / return air) (return air)
- Page 8 Additional operating instructions according to ATEX 2014/34/EU for FKF particle filter box FKF-Q-...-D1-... approx. Connection to earth Detail Y Connection flange suitable for Metu systems HM 20 and HM 30 Available sizes FDQJ-Z / FDQJ-A FPIL-A / FDAV-A FPIL-Z / FDAV-Z...
- Page 9 Additional operating instructions according to ATEX 2014/34/EU for FKF particle filter box Differential pressure device / aerosol monitoring FKF-...-D4 (at an extra charge) With measuring spigot inside the box, for hose connection with device an outer diameter of 10 mm. Additionally with aerosol feeding applies to models -H and -V device in the spigot of the box inside.
- Page 10 Additional operating instructions according to ATEX 2014/34/EU for FKF particle filter box Differential pressure device / aerosol monitoring FKF-...-D4 (at an extra charge) With measuring spigot inside the box, for hose connection with device an outer diameter of 10 mm. Additionally with aerosol feeding applies to model -Q device in the spigot of the box inside.
-
Page 11: Installation And Maintenance
Additional operating instructions according to ATEX 2014/34/EU for FKF particle filter box Accessories - dimensions (at an extra charge) Rubber lip seal (-GD1) Detail X Not for model FKF-Q-...! Installation and maintenance Attention: Please note that the O-rings (seals) of the bulkhead stuffing box may dry out over the months. - Page 12 Additional operating instructions according to ATEX 2014/34/EU for FKF particle filter box Installation (filter installation Instructions) Installation description Diffusers with magnetic fastening (-MB) Loosen filter clamp (pos. 4) and re- Detail Z move it along with shipping brace. NW 400-650 (NW 800 not available) Press the particle filter unit (pos.
-
Page 13: Information Regarding Assembly And Commissioning
Additional operating instructions according to ATEX 2014/34/EU for FKF particle filter box Information regarding assembly and commission- The following inspection criteria must be observed - Visual inspection of the device - Check the fastening of the device Prior to being installed in the ventilation system, the particle fil- - Check the grounding connection for tight fit and good contact ter box must be checked for damage. -
Page 14: Type Plate
Additional operating instructions according to ATEX 2014/34/EU for FKF particle filter box Type plate Version: 06.12.2021 07/06 - 14 Construction subject to change. No return possible! -
Page 15: Certificate Of Conformity
Additional operating instructions according to ATEX 2014/34/EU for FKF particle filter box Certificate of conformity Version: 06.12.2021 07/06 - 15 Construction subject to change. No return possible! - Page 16 Additional operating instructions according to ATEX 2014/34/EU for FKF particle filter box Version: 06.12.2021 07/06 - 16 Construction subject to change. No return possible!
