PROBES CONNECTION

4.6.1 pH & REDOX PROBE CONNECTION
4.6.2

CONDUCTIVITY PROBE CONNECTION

4.6.3

CHLORINE PROBE CONNECTION

(Note: please, check the label connections with chlorine probes polarity connection)
0000138319
pH probe connector
Redox probe connector
Figure 13 pH and Redox connectors
Conductivity probe connector
(optional probe)
Figure 14 Conductivity connector
Figure 15 Chlorine connectors
Rev. 3.2
Astralpool multiparameter
Free and Total Chlorine
probe connectors
USER MANUAL
