- Page 1 REFRIGERATOR OWNER'S MANUAL MODEL SR70F-G4-GL ST90F-G4-B SR48F-G4-WH STR100F-G4-B STF100F-G4-B...
-
Page 2: Table Of Contents
Thank you for purchasing an ENGEL refrigerator. Read this manual carefully before starting to use it. Keep this manual in a safe place for future reference. If the product is resold, this operating manual must accompany it. CONTENTS 1 . Explanation of symbols ............ -
Page 3: Explanation Of Symbols
1. Explanation of symbols The following symbols are used in this OWNER'S MANUAL or on the refrigerator. Failure to observe this instruction WARNING can cause fatal or serious injury. Failure to observe this instruction CAUTION can lead to injury. Failure to observe this instruction NOTICE can cause material damage and impair the function of the product. - Page 4 • If the cable is damaged, it must be replaced to prevent the possibility of electric shock. It must be replaced with a new cord (ENGEL genuine products). • Do not touch the inside and other metal parts of the cabinet with wet hands, as this may cause frostbit.
- Page 5 • When operating on AC, do not plug in to an extension cable or put too many plugs into one socket. Failure to comply will result in electric shock or a fire. • When operating on AC, be sure to plug in securely. Poor connection will result in electric shock or a fire.
- Page 6 refrigerator. The high voltages generated from the charger may damage the refrigerator and lead to a fire. • Do not damage or modify or bend hard or pull or twist or bundle the power cable. Do not have the power cable caught under or pinched with heavy objects.
- Page 7 Utilize an automatic voltage regulator for the refrigerator. Contact your ENGEL dealer if there is any question regarding the use of engine generator set to power the refrigerator.
- Page 8 of a refrigeration truck, where condensation easily occurs and water would drip onto the refrigerator and damage it. • Careful putting glass bottles in the refrigerator.This may result in breakage of bottles due to external shock or vibration. • Do not set the temperature setting knob at “5” except when storing frozen products such as frozen food, ice cream and ice.
-
Page 9: Intended Use
refrigerator. This refrigerator is not capable of cooling food and drink in a short time. It is also recommended to pre-cool inside the refrigerator cabinet before putting in any food. • When the refrigerator is in operation, do not touch food or its containers, especially those made of metal, stored there with a wet hand. -
Page 10: Installation - General Precaution
ST90F Temp setting knob Shelf Temperature setting Turn the temperature setting knob to change the air temperature inside the refrigerator. Inside temperature* Temp setting SR48F,SR70F position STF100F ST90F,STR100F OFF ( Stop ) Approx. 0℃ Approx. -5℃ Approx. -6℃ Approx. -15℃ *at an ambient temperature of 30℃... -
Page 11: Ventilation
Keep the refrigerator away from direct sunlight or a gas stove or heater or heat-generating refrigerator. Avoid installing your refrigerator close to hot water lines or warm air ducts. Adequate ventilation for the rear-mounted condenser and suitable distance from each wall specified at section 5.1 is necessary to enable optimized cooling performance and minimized power consumption. -
Page 12: Operation
SR70F, ST90F, STR100F, SR48F STF100F Typical Front Enclosure outlet Rear Fan* Typical Opening 3”×8.3” inlet (On 25 SQ IN) Rails Outlet Outlet Opening Opening ② 160cm 160cm ② 25in 25in ① ① Inlet Opening 190cm 25in ② ③ Opening 190cm ①... -
Page 13: Connection To 220V-240V Ac
AC and DC voltages may be connected simultaneously, when AC will be automatically selected if both voltages are applied. NOTICE Before starting to use your new refrigerator, its interior as well as exterior shall be thoroughly cleaned with a wet cloth to avoid hygienic issue. - Page 14 recommended cross section or wire gauge and the fuse amperage. Wire Gauge Distance to Fridge Wire Gauge Fuse Amperage (A) Less than 12 feet 16 AWG 12 to 20 feet 14 AWG Above 20 feet 12 AWG Connection inside power supply unit Follow the procedures below to connect the cables from the power source to the power supply unit of the refrigerator.
- Page 15 If you choose to connect the refrigerator to a battery together with a battery charger, they shall be connected in parallel as shown in the picture below. Do not connect a battery charger alone with the refrigerator. If you choose to connect a DC converter with the refrigerator, a 10000μF capacitor shall be connected in parallel with the converter as shown below.
-
Page 16: Wiring Diagram Of Dual Battery Hookup
6.3 Wiring diagram of dual battery hookup wiring diagram shown below is recommended for dual battery hookup. (See Fig 4) SHUT OFF THERMOSTAT WHEN BATTERIES ARE “QUICK CHARGED” Fig.4 CAUTION To avoid damage to the refrigerator in the event of reverse polarity or short circuit, install a 10A fuse in the wiring circuit nearer to the battery. -
Page 17: Maintenance Of Refrigerator
7. Maintenance of refrigerator 7.1 Cleaning interior and door Always disconnect the refrigerator from the power source before you clean or service it. • Clean the interior with a cloth moistened with warm water and wipe again with a dry cloth. •... -
Page 18: Trouble Shooting
(see 7.2 Defrosting) Condenser clogged Clean condenser. If the problem still persists after going through the chart above, consult an ENGEL service agent or dealer near you. Never disassemble the refrigerator by yourself. Inadequate repairs can lead to considerable hazards. -
Page 19: Disposal
If the refrigerator is found to be defective, contact either of the agents whose contact information is found on the last page of this manual or the ENGEL dealer near your location. For repair and warranty processing, have the following documents accompany the refrigerator. -
Page 20: Before Initial Use
11. Before initial use 11.1 Reversing door-swing direction – SR70F, SR48F 1. Remove the door from the refrigerator by removing the two bolts each from the bottom hinge and the upper hinge. Door hinge 2. Remove the bolts from the door latch plate. -
Page 21: Reversing Door-Swing Direction - St90F, Str100F, Stf100F
- Tighten the screw to the Hinge Latch pin handle insert. 5. Put the door back to the refrigerator and reinstall the bottom hinge by Latch pin tightening the two screws. 11.2 Reversing door-swing direction – ST90F, STR100F, STF100F 1. Remove the door from the refrig- Door hinge erator by removing the two bolts Bolts... -
Page 22: Changing Door Panel
faces the cabinet. Screw - Tighten the Screw to install the Latch handle. Latch handle 5. Put the door back to the refrigera- Latch pin tor and reinstall the bottom hinge Set screw by tightening the two screws. Coil spring Make sure the door gasket touch- Door es the cabinet flat and tight when... -
Page 23: Technical Data
12. Technical data Model SR70F-G4-GL SR48F-G4-WH ST90F-G4-B Input 12/24V and 220-240V〜 50/60Hz voltage: Rated 12V : 2.5A 12V : 2.6A current: 24V : 1.2A 24V : 1.3A 220-240V〜: 0.37A 220-240V〜: 0.37A Cooling +5℃ to -2℃ +5℃ to 0℃ capacity:... - Page 24 Model STR100F-G4-B STF100F-G4-B Input 12/24V and 220-240V〜 50/60Hz voltage: Rated 12V : 3.3A 12V : 4.2A current: 24V : 1.6A 24V : 2.1A 220-240V〜: 0.40A 220-240V〜: 0.74A Cooling +5℃ to -6℃ +5℃ to -15℃ capacity: Energy 264 kWh/annum 492 kWh/annum consumption: Gross volume:...
- Page 25 M E M O - 24 -...
- Page 26 <AGENT in AUSTRALIA and NEW ZEALAND> ENGEL DISTRIBUTION PTY LTD. P.O. Box155 25 SILICA ST CAROLE PARK QLD 4300, Australia : 1300 302 653 E-mail : admin@engelaustralia.com.au SAWAFUJI ELECTRIC CO.,LTD. 3, NITTAHAYAKAWA-CHO, OTA-CITY, GUNMA 370-0344, JAPAN TEL: +81(0)276-56-7139 FAX: +81(0)276-56-6075 (Cat.
- Page 28 Warrantor as being authorized service personnel. "Your attention is drawn to the fact that this warranty is authorized by ENGEL DISTRIBUTION PTY. LTD and cannot be varied by others. Please staple your purchase receipt to this card. For your nearest service agent.
Need help?
Do you have a question about the SR70F-G4-GL and is the answer not in the manual?
Questions and answers
How to fit the spring of the freezer door
To fit the spring of the Engel SR70F-G4-GL freezer door, follow these steps:
1. Unscrew the screw from the latch handle to take apart the latch pin and coil spring.
2. Insert the coil spring and latch pin onto the opposite side of the door.
3. Ensure the angled face of the latch pin faces the cabinet.
4. Tighten the screw to install the latch handle.
Make sure the door gasket touches the cabinet flat and tight when the door is closed.
This answer is automatically generated
