RM350 GAS CONTROLLERS
OPERATING
INSTRUCTIONS
RM350
OPERATING INSTRUCTIONS
AUG 15
RM350
1 of 13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RM350 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for MAXIMATOR RM350

  • Page 1: Table Of Contents

    Calibration Screen ..........................11 What are the requirements of a calibration gauge? ................11 How to carry out a valve calibration: ....................12 Hydraulics Screen ..........................12 How to start the machine ........................13 RM350 GAS CONTROLLERS AUG 15 1 of 13...
  • Page 2: Safety

    NEVER adjust a pipefitting that is under pressure. NEVER adjust a safety valve to achieve a lifting pressure higher than that set at the Maximator factory. A safety valve is provided to prevent over pressurisation of the system and overloading of the compressor.
  • Page 3: Home Screen

    Touch to select language Status Changes colour to indicate fault. Yellow = normal, red = fault. Touch to go to status screen Current time and date Touch to change system time and date RM350 GAS CONTROLLERS AUG 15 3 of 13...
  • Page 4: Valve Screen

    Touch the valve number to show the valve screen for that valve. If 4 valves are fitted, V3 and V4 buttons will be visible also. All valve screens have their own colour. RM350 GAS CONTROLLERS AUG 15 4 of 13...
  • Page 5: How To Set Pressure And Time Profiles

    Total cycle time (calculated)  Phase time [3] can be the same Copy all settings as ramp time, but cannot be less Paste all settings than ramp time Copy phase settings to next phase RM350 GAS CONTROLLERS AUG 15 5 of 13...
  • Page 6: Purge And Clean Function

    This valve is connected to interface 2 and will start when the unit is in automatic mode and a start signal is received at interface 2 Purge Touch to purge from this valve at the set clean pressure. RM350 GAS CONTROLLERS AUG 15 6 of 13...
  • Page 7: Valves View Screen

    Actual pressure value and bargraph display Preset pressure value and bargraph display Current cycle progress bargraph Total cycle count for this valve. Not-resettable Cycle count for this valve (can be reset by user) Current phase number. RM350 GAS CONTROLLERS AUG 15 7 of 13...
  • Page 8: Data Storage Screen

    Finish button. Touch to load all data in green panels to the machine settings Clear panels button. Touch to clear clipboard data from panels and turn them white. RM350 GAS CONTROLLERS AUG 15 8 of 13...
  • Page 9: Status Screen

    Note: red flags do not signify a problem. If modules are not fitted because an option is not included, their positions will show red. I/O status information. Shows the current values of digital and analogue I/O RM350 GAS CONTROLLERS AUG 15 9 of 13...
  • Page 10: Setup Screen

    This value cannot be set below the gas inlet pressure alarm + 20 Bar (290 psi) RM350 GAS CONTROLLERS AUG 15 10 of 13...
  • Page 11: Calibration Screen

    The better the pressure gauge, the better the calibration. Gauges that may be fitted to an RM350 unit are for indication only and it is not advised that these are used for calibration. However, if there is no alternative and the unit has gauges fitted, you can use these by fitting a blanking plug to close off the valve outlet.
  • Page 12: How To Carry Out A Valve Calibration

    6. Repeat for all valves fitted, making sure each time that the gauge is correctly fitted before starting the procedure. When a hydraulic power pack or signal controls option is fitted to an RM350 unit, use the hydraulics screen to control the hydraulic core movements.
  • Page 13: How To Start The Machine

    7. Enter required process parameters. (Refer to operating instructions) 8. Select automatic mode 9. Select the appropriate interface 10. Operate the moulding machine and the controller will run accordingly RM350 GAS CONTROLLERS AUG 15 13 of 13...
