Installation
9. Finally, insert the installed bracket into the case and fix it with
M4 thumbscrews. Then stick the footpads to the bottom panel.
The installation is complete.
CONTACT US
If any problem, feel free to contact us.
Website: www.uctronics.com
Email: support@uctronics.com
SKU: U6243
