OWNER'S OPERATION AND INSTALLATION MANUAL
AL500HYLA
50,000 BTU/Hr
Manually Controlled
WARNING: If the information in this manual is
not followed exactly, a fire or explosion may result
causing property damage, personal injury, or loss
of life.
FOR YOUR SAFETY:
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
Do not touch any electrical switches; do not use
any phones in your building.
Immediately call your gas supplier from a
neighbor's phone, follow the gas supplier's
instructions.
If you cannot reach your gas supplier, call the fire
department.
Installation and service must be performed by a
qualified installer, service agency or the gas supplier.
Save this manual for future reference.
Installer: Leave this manual with customer.
OUTDOOR GAS
FIREPLACE
IMPORTANT:
owner's manual carefully and
completely
before
assemble, operate, or service
this heater.
WARNING:
installation,
alteration,
service,
maintenance can cause injury
or property damage. Read the
installation,
operating
maintenance
thoroughly before installing or
servicing this equipment
WARNING: F
OR
Only.
Read
this
trying
to
Improper
adjustment,
or
and
instructions
Outdoor Use
