The Handy THTD Instruction Manual

Towed dethatcher

Advertisement

Quick Links

www.thehandy.co.uk
INSTRUCTION MANUAL
40" (101CM)
TOWED DETHATCHER
MODEL NO: THTD -- PRODUCT NO: 1938118001
EN - ORIGINAL INSTRUCTIONS
ASSEMBLY REQUIRED
SAVE THESE INSTRUCTIONS
SPARES & SUPPORT: 01793 333212
FOR YOUR SAFETY
Please read & understand this manual, paying attention to the safety instructions, before use.
Incorrect use of the product could put the operator or machine in danger.
Whilst every effort has been made to ensure the accuracy of information contained in this manual, our
policy of continuous improvement determines the right to make modifications without prior warning.
Images used are for illustration purposes only
23/03/2022 v4

Advertisement

loading
Need help?

Need help?

Do you have a question about the THTD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for The Handy THTD

  • Page 1 INSTRUCTION MANUAL 40” (101CM) TOWED DETHATCHER MODEL NO: THTD -- PRODUCT NO: 1938118001 EN - ORIGINAL INSTRUCTIONS ASSEMBLY REQUIRED SAVE THESE INSTRUCTIONS SPARES & SUPPORT: 01793 333212 FOR YOUR SAFETY Please read & understand this manual, paying attention to the safety instructions, before use.
  • Page 2 Copyright Notice Copyright © Handy Distribution Permission is granted to reproduce this publication for personal & educational use only. Commercial copying, redistribution, hiring or lending is prohibited. No part of this publication may be stored in a retrieval system or transmitted in any other form or means without written permission from Handy Distribution.
  • Page 3: Table Of Contents

    CONTENTS SPECIFICATIONS IMPORTANT INFORMATION GENERAL SAFETY INSTRUCTIONS SET UP & PREPARATION FOR OPERATION ASSEMBLY OPERATION & ADJUSTMENT MAINTENANCE PARTS DIAGRAM & LIST WARRANTY NOTES WARNING Read this instruction manual carefully before operating this machine. Make sure that you are familiar with the controls and properly operate the machine.
  • Page 4: Specifications

    Spring Loaded Steel Tines 10 x 100mm Consistent with our policy of continuous improvement, The Handy reserves the right to change the design and configuration of any of its products without notice or obligation. Therefore, please treat the text and images in this manual for illustrative purposes only.
  • Page 5: General Safety Instructions

    GENERAL SAFETY INSTRUCTIONS It is important that you read and understand the owner’s manual and labels affixed to the machine. Learn its application and limitations as well as the specific potential hazards. Retain these instructions for future reference. The operator is responsible for following the warnings & instructions in this manual and on the product.
  • Page 6 e) Do not overreach. Always keep proper footing and balance. This enables better control in unexpected situations. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing, and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts. TOOL USE AND CARE a) Do not force the tool.
  • Page 7 ADDITIONAL SAFETY WARNINGS PERSONAL SAFETY DANGER RISK OF SUFFOCATION Small parts can be easily swallowed. There is also a risk that a polybag can suffocate toddlers. Keep toddlers away when you assemble the product. Dispose of all polybags responsibly. Know how to stop the product quickly in an emergency. Only work in the daylight or when visibility is good. Check your product before each use.
  • Page 8: Set Up & Preparation For Operation

    SET UP & PREPARATION FOR OPERATION This product must be assembled correctly before use. Carefully remove the product and any accessories from the carton. Inspect the product carefully to make sure there are no breakages or missing items during shipping. Do not discard the packing material and carton until you have carefully inspected and satisfactorily operated the product.
  • Page 9: Assembly

    ASSEMBLY Remove the machine and contents from the carton. Be sure the carton is empty before discarding. If you require any assistance with regards to the contents or operation of your machine, please contact us: Tel: 01793 333212, option 2 Email: customerservice@handydistribution.co.uk Opening Hours Weekdays: (CLOSED WEEKENDS &...
  • Page 10 STEP 5 Fasten the hitch mount arms to the outside of the angle brackets at the front of the tine shield. Use two M8x20 hex bolts and M8 hex lock nuts. Tighten and then loosen the nuts slightly. See Figure 3. STEP 6 Fasten the hitch mount arms to the outside of the hitch arm mount brackets at the rear of the tine shield.
  • Page 11 STEP 10 Tighten the bolts and nuts assembled in step 8. Tighten the bolts and nuts assembled in step 7. Tighten the bolts and nuts assembled in step 3. Tighten the bolts and nuts assembled in step 4. Tighten and then loosen slightly the bolts and nuts assembled in step 5. Tighten the bolts and nuts assembled in step 6.
  • Page 12 STEP 13 Fasten the ten spring tines to the square holes in the bottom of the tine shield. Use a M8x25 carriage bolt, Ф8 big flat washer, Ø8 lock washer and M8 hex nut for each spring tine. Tighten. See Figure 7. NOTE: Spring tines must sit between dimples.
  • Page 13 STEP 17 Position the hitch arm mount bracket so that some resistance is felt through the lift handle when it is locked in the up position. Tighten the nuts. See Figure 9. GRIP LIFT HANDLE M8X25 CARRIAGE BOLT M8X20 HEX BOLT M8 HEX LOCK NUT...
  • Page 14: Operation & Adjustment

    OPERATION / ADJUSTMENT DANGER The product must only be put into operation if no defects are found. It is crucial that defective parts are replaced before the product is used again. Check the safety equipment and the safe condition of the product: Check all parts to make sure that they fit tightly.
  • Page 15: Maintenance

    MAINTENANCE LUBRICATE Maintenance spray or multi-purpose grease can be applied to the wheel axle prior to long-term storage. CLEANING After each use thoroughly wash the machine with a stiff brush. STORING Before storing, ensure that the machine is clean and dry. Store in a dry or protected area and coat exposed metal with light oil when not in use.
  • Page 16: Parts Diagram & List

    PARTS DIAGRAM & LIST Part No. Description QTY No. Part No. Description TH153-1 Hitch Arm Mount Bracket 13 TH153-13 Hex Lock Nut M10 TH153-2GM Hitch Bracket 14 TH153-14 Flat Washer TH153-3 Spring Tine 15 TH153-15 Hex Bolt M8x20 TH153-4 Spring Alignment Wire 16 TH153-16 Lock Washer TH153-5...
  • Page 17 Period of Warranty The Handy (Petrol & Electric only), Webb (excludes Dynamic, Heritage, Legacy), a) 2 years from the original date of sale to the first domestic user. b) 90 days from the original date of sale to the professional/commercial user.
  • Page 18 Disclaimer a) This warranty is only a remedy for defect of products. GJ Handy (Trading) Ltd will never warranty in terms of the merchantability or the fitness for a particular purpose. b) No person is authorised to make any warranties, representations or promises, expressed or implied, on behalf of GJ Handy (Trading) Ltd, or to modify the terms conditions or limitation of this warranty policy in any way.
  • Page 20 For spares or support of your handy product, please contact us: Tel: 01793 333212 Email: customerservice@handydistribution.co.uk Opening Hours Weekdays: February to October 8:30am - 5:30pm November to January 8:30am - 5:00pm (CLOSED WEEKENDS & BANK HOLIDAYS) To see our range of garden machinery & equipment visit: www.thehandy.co.uk Making gardening easier &...
