Miola Touch Panel 10"
EAE KNX Touch Panel 10" Quick Start Guide
2. Connect cables to related connectors
Switch o mains voltage
before connecting cables
3. Adjust Magnets for perfect fit
4. Mount Touch Panel
EAE Teknoloji Araştırma ve Geliştirme A.Ş.
kitelli O.S.B. Ziya Gökalp Mh. Eski Turgut Özal Cd. No:20 Başakşehir stanbul Türkiye
Mounting Magnet
panel
box
wall
TO U C H PA N E L
Miola Touch Panel 10"
EAE KNX Touch Panel 10" Quick Start Guide
www.eaetechnology.com
Advertisement
Table of Contents
Related Manuals for EAE Miola Touch Panel 10
Summary of Contents for EAE Miola Touch Panel 10
- Page 1 Miola Touch Panel 10” EAE KNX Touch Panel 10” Quick Start Guide 2. Connect cables to related connectors Switch o mains voltage before connecting cables TO U C H PA N E L Miola Touch Panel 10” 3. Adjust Magnets for perfect fit EAE KNX Touch Panel 10”...
- Page 2 If you need support in further steps, visit www.eaetechnology.com and check Miola Product Manual. touch panel INSTALLATION speaker 1. Insert Miola Touch Panel 10” Mounting Box 264.00 Mounting Box should be aligned vertically TOP VIEW Mounting Box sold separately. Mounting Box dimensions:...
