ElectriFied Mobile EM-Cruiser Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OWNERS MANUAL
V1.1 | 2021
EM-Cruiser
EM-Mountain
Electrified Mobile would like to thank you for the purchase of your new EM Series
E-Bike and hope you enjoy your new riding experience in the great outdoors!
Please feel free to contact us with any questions, concerns and comments regarding
your new bike.
Email:
info@electrifiedmobile.ca
Website: electrifiedmobile.ca
Phone: 780 974 5279
Please Thoroughly Read Manual Before Using Your New E-Bike
Page | 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EM-Cruiser and is the answer not in the manual?

Questions and answers

Related Manuals for ElectriFied Mobile EM-Cruiser

Summary of Contents for ElectriFied Mobile EM-Cruiser

  • Page 1: Em-Cruiser Em-Mountain

    EM-Cruiser EM-Mountain Electrified Mobile would like to thank you for the purchase of your new EM Series E-Bike and hope you enjoy your new riding experience in the great outdoors! Please feel free to contact us with any questions, concerns and comments regarding your new bike.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS OWNERS MANUAL V1.1 | 2021 Table of Contents EM-Cruiser EM-Mountain ......................1 Charging .............................. 6 Power On E-Bike ..........................7 Battery Gauge ............................. 8 NOTE: Battery / Voltage indicator ...................... 8 General Setup ............................. 9 ................................9 Backlight setting Speed limit setting .....................
  • Page 3 TABLE OF CONTENTS OWNERS MANUAL V1.1 | 2021 1. Brakes ..........................12 2. Wheels and Tires ......................12 3. Steering ........................12 4. Chain ..........................13 5. Bearing ........................13 6. Cranks and Pedals ....................... 13 7. Derailleur ........................13 8.
  • Page 4 TABLE OF CONTENTS OWNERS MANUAL V1.1 | 2021 11. Battery Pack ......................14 Helmets ............................14 Components ........................... 15 Thumb Throttle/PAS ........................15 Taking Care of Your Batteries ......................16 Seat Adjustment/Removal ........................ 17 Battery Installation ........................... 18 Battery Removal..........................18 Charging ............................
  • Page 5 If you notice abnormalities in any component on the bike, take it to a licensed bicycle mechanic to be repaired or replaced immediately. Electrified Mobile Inc. assumes no liability for harm, injury, or death of the rider. This manual is not intended to function as a detailed service manual.

  • Page 6: Charging

    Charging: Charging Finished: When installing the battery on the EM-Cruiser, please make sure that the lead rail on frame is in the slot on the battery and make sure the battery is placed completely on the conductive contact on the bottom.

  • Page 7: Power On E-Bike

    QUICK START OWNERS MANUAL V1.1 | 2021 Power On E-Bike: ❖ Twist the key clockwise to “ON” position (EM-Cruiser Only): ❖ Turn on Colour Display by holding power on/off button for 3-5sec: Page | 7...

  • Page 8: Battery Gauge

    DISPLAY SETTINGS OWNERS MANUAL V1.1 | 2021 Battery/Voltage indicator Displays remaining battery power & voltage Backlight/Headlight With the power on, click the power ON/OFF to turn indicator on the backlight and headlight. USB mode Hold the SET and UP button together for 5 seconds to get into USB mode.

  • Page 9: General Setup

    BATTERY CARE OWNERS MANUAL V1.1 | 2021 General Setup Click and hold SET button for 2 seconds. This will allow you to enter the general setup interface. Backlight setting: Speed limit setting: Wheel diameter setting: Units setting: Page | 9...

  • Page 10: Battery Setting Ride Mode Setting

    BATTERY CARE OWNERS MANUAL V1.1 | 2021 Battery setting: Ride mode setting: ECO: Normal: Power: Current Limiting Setting: Throttle 6Km/h (Range 3-18) Y represents YES in 6km/h pushing mode N represents NO, not in 6km/h mode Throttle Level Assist Levels Y means YES throttle with different levels PAS levels can be changed to 3,5,6 or 9 N means NO throttle with one level.

  • Page 11: Password Save & Exit

    BATTERY CARE OWNERS MANUAL V1.1 | 2021 Password: Save & Exit: Change Password Saves changes and exits to main screen Wire order and definition: Wire sequence Wire colour Function Battery + (pos) Blue Weak lock Black Battery – (neg) UART-RECEIVE Green (RXD) Yellow...

  • Page 12: Brakes

    SAFETY CHECKLIST OWNERS MANUAL V1.1 | 2021 1. Brakes Before using your E-Bike, it is important to carry out the following safety checks: • Ensure front and rear brakes work properly • Ensure brake shoe pads are not worn out and are correctly positioned in relation to the rims.

  • Page 13: Chain

    SAFETY CHECKLIST OWNERS MANUAL V1.1 | 2021 4. Chain • Ensure chain is oiled, clean and runs smoothly. • Extra care is required in wet or dusty conditions. • Ensure pedals are securely tightened to the cranks. 5. Bearing • Check headset, wheel bearings, pedal bearings and bottom bracket bearings.

  • Page 14: Accessories

    SAFETY CHECKLIST OWNERS MANUAL V1.1 | 2021 9. Accessories • Ensure that all reflectors are properly fitted. • Ensure all other fittings on the bike are properly and securely fastened and functioning. • Ensure the rider is wearing a helmet. 10.

  • Page 15: Components

    COMPONENTS OWNERS MANUAL V1.1 | 2021 Components Thumb Throttle/PAS Once you mount and before you begin riding your E-Bike, turn the main power switch on. You will then default to PAS 1 (Pedal Assist 1) as seen in the display settings section.

  • Page 16: Taking Care Of Your Batteries

    BATTERY CARE OWNERS MANUAL V1.1 | 2021 Taking Care of Your Batteries • Proper maintenance of the batteries will maximize lifespan and available ride time. • We use Li-ion (Lithium Ion) batteries in all our electric bicycles. These are user friendly batteries when cared for properly. •...

  • Page 17: Seat Adjustment/Removal

    BATTERY CARE OWNERS MANUAL V1.1 | 2021 • Be mindful of the environment! Be sure to recycle your old batteries at your local eco station. Do not dispose of them in the garbage. • Frequent starts and stops will drain a battery more quickly than sustained long use.

  • Page 18: Battery Installation

    OWNERS MANUAL V1.1 | 2021 Battery Installation (EM-Cruiser Only) In the left unlock position, push the battery box into the compartment along the rail, then turn the key right to lock the box then a second turn to power on.

  • Page 19: How To Use The Li-Ion Battery Charger

    BATTERY CARE OWNERS MANUAL V1.1 | 2021 The charger may get warm to the touch, so make sure you charge in an open area and do not lay anything on the charger unit while charging. Although you cannot over charge the batteries using the “Smart Charger”, we recommend that you do not leave the charger plugged in for more than 24 hours.
  • Page 20 BATTERY CARE OWNERS MANUAL V1.1 | 2021 1. Red light means charging 2. Green light means battery fully charged 3. Input: AC100-240V～, 1.6A (Max) 50/60Hz 4. Output: 42.00V—3.0A 5. Plug the charger into the outlet and turn the charger “ON” via the switch. 6.

  • Page 21: Battery Care And Battery Storage

    BATTERY CARE OWNERS MANUAL V1.1 | 2021 Battery Care and Battery Storage How to store your battery for an extended time Charge the battery every 3 months to avoid capacity loss. Batteries slowly self- discharge when left unused for a long time. If battery cells are allowed to reach a critically low voltage, their lifespan and capacity will be permanently reduced.
  • Page 22 *Only use Electrified Mobile supplied chargers. Q: Is it normal that the batteries get warm when recharging? A: Yes, it is normal that the batteries will become warm to the touch during the recharging process.

  • Page 23: Braking Adjustment

    MAINTENANCE OWNERS MANUAL V1.1 | 2021 Braking Adjustment Depress the brake lever about 10 times as far as the grip to check that everything is operating correctly and that the shoe clearance is corrected before riding the bike. Chain Inspection The chain must be kept clean, rust free and frequently lubricated to extend its life as long as possible.

  • Page 24: Lubrication

    MAINTENANCE OWNERS MANUAL V1.1 | 2021 Lubrication The chain should be lubricated with light oil at least every month, or more often in wet, muddy, or dusty conditions. Be sure to wipe off excess oil, and not get oil on the tires or rim braking surfaces.

  • Page 25: Fuse

    V1.1 | 2021 Fuse All Electrified Mobile E-Bikes are equipped with a fuse. The fuse may be located, depending on the model of the bike, in the following location: In the event of an overload, the fuse will pop and need to be replaced. Replace only with an approved part.

  • Page 26: Troubleshooting

    MAINTENANCE OWNERS MANUAL V1.1 | 2021 Troubleshooting Failure symptoms Cause of Problem Solution Battery voltage is too low Immediately charge Battery is not providing proper The battery indicator Replace the battery light on the meter is power off, and the motor does The battery lock does not not work work, preventing battery from...

  • Page 27: Limited Warranty

    Your E-Bike is warranted to be free of manufacturing defects in material, workmanship, or shipping damages for a period of 14 days. During the warranty period, and depending on circumstances, Electrified Mobile will repair, provide replacement parts, or replace your E-bike at no charge. This warranty does not cover normal wear and tear, or damage caused by water, neglect, or misuse of the product.

This manual is also suitable for:

Em-mountain
