Instruction
manual
To learn more about Porter-Cable
visit our website at:
http://www.porter-cable.com
Copyright © 2003 Porter-Cable Corporation
ESPAÑOL: PÁGINA 13
FRANÇAISE : PAGE
Double Insulated Random
Orbit 5" Sander/6" Polisher
Please make certain that the person who is
to use this equipment carefully reads and
understands these instructions before
starting operations.
The Model and Serial No. plate is located on the main
housing of the tool. Record these numbers in the
spaces below and retain for future reference.
Model No. ______________________________________
Type ___________________________________________
Serial No. _______________________________________
MODELS
7335
7336
7336SP
7355
7366
7424
IMPORTANT
Part No. 904034 - 12-02-03
27
Advertisement
Table of Contents
Related Manuals for Porter-Cable 7336
Summary of Contents for Porter-Cable 7336
- Page 1 Instruction manual To learn more about Porter-Cable visit our website at: http://www.porter-cable.com Copyright © 2003 Porter-Cable Corporation ESPAÑOL: PÁGINA 13 FRANÇAISE : PAGE Double Insulated Random Orbit 5" Sander/6" Polisher IMPORTANT Please make certain that the person who is to use this equipment carefully reads and understands these instructions before starting operations.
-
Page 2: Safety Guidelines - Definitions
SAFETY GUIDELINES - DEFINITIONS This manual contains information that is important for you to know and under- stand. This information relates to protecting YOUR SAFETY and PREVENTING EQUIPMENT PROBLEMS. To help you recognize this information, we use the symbols below. Please read the manual and pay attention to these sections. indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. -
Page 3: Personal Safety
When operating a power tool outside, use an outdoor extension cord marked “W-A” or “W”. These cords are rated for outdoor use and reduce the risk of electric shock. PERSONAL SAFETY Stay alert, watch what you are doing, and use common sense when operating a power tool. - Page 4 Labor regulations. There are certain applications for which this tool was designed. Porter-Cable strongly recommends that this tool NOT be modified and/or used for any application other than for which it was designed. If you have any questions relative to its application DO NOT use the tool until you have written Porter-Cable and we have advised you.
-
Page 5: Additional Safety Rules For Paint Removal
ADDITIONAL SAFETY RULES FOR PAINT REMOVAL Extreme care should be taken when removing paint. The peelings, residue, and vapors of paint may contain lead, which is poisonous. Exposure to even low levels of lead can cause irreversible brain and nervous system damage; young and unborn children are particularly vulnerable. -
Page 6: Replacement Parts
MOTOR Many Porter-Cable tools will operate on either D.C., or single phase 25 to 60 cycle A.C. current and voltage within plus or minus 5 percent of that shown on the specification plate on the tool. Several models, however, are designed for A.C. -
Page 7: Functional Description
18-20 FUNCTIONAL DESCRIPTION FOREWORD The Porter-Cable Random Orbit Polisher performs various tasks including polishing, rubbing, and general cleaning jobs. Used as a Random Orbit Sander the tool provides rapid stock removal with 80 to 100 grit paper and swirl-free finishing with 120 to 150 grit paper. - Page 8 TO START AND STOP TOOL Make certain the switch is in the “OFF” position, and the power source is the same as that specified on the tool’s nameplate. 2. Connect the tool to the power source. 3. Slide the switch button (A), Fig. 2, forward to start motor. Slide switch button to the rear to stop motor.
-
Page 9: Using The Sander
2. Place machine on workbench with pad up (See Fig. 4). 3. Clean dust from pad face. 4. Tear a new abrasive disc from roll and position disc to the sander pad. 5. Press disc firmly onto pad. 6. Position machine with abrasive contacting scrap material. Start machine and operate momentarily while exerting firm pressure to seat disc to pad. -
Page 10: Changing Back-Up Pad
Wear ANSI Z87.1 safety glasses and dust mask. 3. Place sander to work (see Fig. 5) with abrasive disc resting FLAT on the work. NOTE: The Random Orbit mechanism allows the sander to be started and stopped with the pad in contact with the work or clear of the work. -
Page 11: Maintenance
FACTORY SERVICE CENTER. At approximately 100 hours of use, take or send your tool to your nearest authorized Porter-Cable Service Station to be thoroughly cleaned and inspected. Have worn parts replaced and lubricate with fresh lubricant. Have new brushes installed, and test the tool for performance. -
Page 12: Service And Repairs
PORTER-CABLE LIMITED Porter-Cable warrants its Professional Power Tools for a period of one year from the date of original purchase. We will repair or replace at our option, any part or parts of the product and accessories covered under this warranty which, after examination, proves to be defective in workmanship or material during the warranty period. - Page 13 Porter-Cable • Delta products should be obtained by contacting any Porter-Cable • Delta Distributor, Authorized Service Center, or Porter-Cable • Delta Factory Service Center. If you do not have access to any of these, call 888-848-5175 and you will be directed to the nearest Porter-Cable •...
