PLAYBACK
PLAYBACK
You can use the camera's built-in monitor screen to view
images after you record them.
Basic Playback Operation
Use the following procedure to scroll through files stored in
the camera's memory.
1.
Press the power
button to turn on the
camera.
• This causes an image
or a message to appear
on the monitor screen.
2.
Align the mode
selector with "PLAY".
• This enters the PLAY
mode.
Power button
ON/OFF
Mode selector
PLAY
REC
MENU
88
3.
Use [ ] (forward) or [ ] (back) to scroll
through files on the monitor screen.
NOTES
• Holding down [ ] or [ ] scrolls images at high
speed.
• In order to allow for faster playback image scrolling,
the image that initially appears on the monitor screen
is a preview image, which is of somewhat lower
quality than the actual display image. The actual
display image appears a short while after the preview
image. This does not apply to images copied from
another digital camera.

Advertisement

Table of Contents
loading

Related Manuals for Casio EXILIM EX-Z4

Summary of Contents for Casio EXILIM EX-Z4

  • Page 1 ON/OFF quality than the actual display image. The actual display image appears a short while after the preview image. This does not apply to images copied from another digital camera. PLAY MENU...

  • Page 2: Playing An Audio Snapshot

    PLAYBACK Playing an Audio Snapshot Perform the steps below to display an audio snapshot (indicated by a indicator) and play its audio. In the PLAY mode, use [ ] and [ ] until the image you want is displayed. Press [SET]. •...

  • Page 3: Flipping The Display

    PLAYBACK Flipping the Display The following procedure flips the image 180 degrees. This comes in handy when you want to show someone standing in front of you an image on the monitor screen. [SET] Shutter release button In the PLAY mode, use [ ] and [ ] to scroll through images on the monitor screen and display the one you want.

  • Page 4: Zooming The Display Image

    PLAYBACK Zooming the Display Image Perform the following procedure to zoom the image currently on the monitor screen up to four times its normal size. In the PLAY mode, use [ ] and [ ] to display the image you want. Press the zoom button ( ) to enlarge...

  • Page 5: Resizing An Image

    PLAYBACK Resizing an Image You can use the following procedure to change a snapshot image to either SXGA size (1280 x 960 pixels) or VGA size (640 x 480 pixels). • VGA is the optimum image size for attachment to e-mail messages or incorporation into Web pages.

  • Page 6: Cropping An Image

    PLAYBACK Cropping an Image Use the following procedure when you want to crop a portion of an enlarged image and use the remaining part of the image as an e-mail attachment, Web page image, etc. In the PLAY mode, use [ ] and [ ] to scroll through images and display the one you want to crop.

  • Page 7: Playing A Movie

    PLAYBACK Playing a Movie Use the following procedure to play back a movie that was recorded in the movie mode. In the PLAY mode, press [ ] and [ ] to scroll through images until the movie you want to play is displayed.

  • Page 8: Displaying The 9-Image View

    PLAYBACK Displaying the 9-image View The following procedure displays nine images on the monitor screen at the same time. In the PLAY mode, press the zoom button • This displays the 9-image screen with the image that was on the monitor screen in step 2 in the center, with a selection boundary around it.

  • Page 9: Selecting A Specific Image In The 9- Image View

    PLAYBACK Selecting a Specific Image in the 9- image View Display the 9-image view. Use [ ], [ ], [ ], and [ ] to move the selection boundary up, down, left, or right until it is located at the image you want to view.

  • Page 10: Playing A Slide Show

    PLAYBACK • Pressing [ ] while the date selection cursor is located anywhere in the top line of the calendar causes the previous month to appear. • Pressing [ ] while the date selection cursor is located anywhere in the bottom line of the calendar causes the next month to appear.
  • Page 11 • While audio is playing, you can use [ ] and [ ] to adjust the volume level. • Images copied from another digital camera or a computer may take longer time to appear than the slideshow interval time you specify.

  • Page 12: To Specify The Slideshow Images

    PLAYBACK To specify the slideshow images Use [ ] and [ ] to select “Images”, and then press [ ]. Use [ ] and [ ] to select the setting you want, and then press [SET]. To do this: Include all files in file memory in the slideshow Display a single file Include all files in the FAVORITE...

  • Page 13: To Specify The Slideshow Time

    PLAYBACK To specify the slideshow time Use [ ] and [ ] to select “Time”. Use [ ] and [ ] to specify the time setting you want, and then press [SET]. • You can specify a time in the range of 1 to 60 minutes.

  • Page 14: Using The Photo Stand Feature

    PLAYBACK Using the Photo Stand Feature The “Photo Stand” feature lets you specify what should appear on the camera’s monitor screen while the camera is on its USB cradle. You can play a Photo Stand slideshow without worrying about remaining battery power, or you can specify display of a particular image.

  • Page 15: Rotating The Display Image

    • You cannot rotate an image that is protected. To rotate such an image, first unprotect it. • You may not be able to rotate a digital image that was recorded with another type of digital camera. • You cannot rotate movie or voice record images.

  • Page 16: Using Image Roulette

    PLAYBACK Using Image Roulette Image Roulette cycles images like a slot machine on the display, before stopping at one of them. When you start an Image Roulette operation, images scroll randomly on the screen. At first, images scroll at high speed. Then the scrolling gradually slows down until a single image is stopped on the screen.

  • Page 17: Adding Audio To A Snapshot

    PLAYBACK Adding Audio to a Snapshot The “after-recording” feature lets you add audio to snapshots after they are recorded. You can also re-record an audio image (one with a icon on it). • Audio Format: WAVE/ADPCM recording format This is the Windows standard format for audio recording. The file extension of a WAVE/ADPCM file is “.WAV”.

  • Page 18: To Re-Record Audio

    PLAYBACK To re-record audio In the PLAY mode, use [ ] and [ ] to scroll through snapshots until the one whose audio you want to re-record is displayed. Select the “PLAY” tab, select “Dubbing”, and then press [ ]. Use [ ] and [ ] to select “Delete”, and then press [SET].

  • Page 19: Playing Back A Voice Recording File

    PLAYBACK Playing Back a Voice Recording File Perform the following steps to play back a voice recording file. In the PLAY mode, use [ ] and [ ] to display the voice file (a file with on it) you want to play.
