- Page 1 ® ® YAMAHA FRONT SPEAKER ENCLOSURES RFYXZ-FSE Serial Number: Date of Purchase: Installation & Operation...
- Page 2 8 Warranty ©2016 Rockford Corporation. All Rights Reserved. ROCKFORD FOSGATE and associated logos where applicable are registered trademarks of Rockford Corporation in the United States and/or other countries. All other trademarks are the property of their respective owners. Specifications subject to change without notice.
- Page 3 Models may differ from year to year depending on factory options and aftermarket accessories added. • This wiring kit is specifically designed to work with Rockford Fosgate’s PM and RM series of mini wake cans. • With the addition of an amplifier or source unit, be sure that your current charging system is in proper working order.
- Page 4 Installation Applicable Models: 2016 & Up YXZ1000R/YXZ1000R SS These front speaker enclosures are designed to work with Rockford Fosgate’s RFYXZ-K8 amplifier kit and RFYXZ-PMXDK dash kit. NOTE: Some additional interior pieces were removed to make photography easier for documenting the installation process. The installation process is the same for both the passenger and driver’s side of the vehicle.
- Page 5 Installation Step 3 - Prepare Speaker Enclosures and Mounting Area Remove the pod and drill (2) holes in the firewall using a 5/16” and 1/2” drill bit. Temporarily install the speaker pod into the foot well area to mark the holes that will need to be drilled Next prep the speaker pods by drilling the holes in pods.
- Page 6 Installation Install using the supplied bolt through the top of the enclosure. The bolt Feed the speaker wire harness through the 1/2” hole. will go through the drilled 5/16” hole. Secure with the supplied nut. Apply the supplied foam sealing tape to the inside of the speaker enclosure Finish securing the speaker pod in place with the (2) bolts used earlier.
- Page 7 Installation Load the speaker into the enclosure and secure using the hardware Once the connections are made, test the system to verify functionality. supplied with the speaker. After testing, secure the wire harnesses with plastic wire ties and reassemble NOTE: After the speaker is secured repeat the installation process for the the vehicle.
- Page 8 What is Covered This warranty applies only to Rockford Fosgate products sold to consumers by authorized Rockford Fosgate dealers in the United States of America. Prod- ucts purchased by consumers from an Authorized Rockford Fosgate Dealer in another country are covered only by that country’s Distributor and not by Rockford Corporation.
- Page 9 Installation assistance available at: www.rockfordfosgate.com/rftech 600 South Rockford Drive • Tempe, Arizona 85281 United States Direct: (480) 967-3565 • Toll Free: (800) 669-9899 R O C K F O R D F O S G A T E . C O M...
