Dixell XR60CX Operating Manual
This manual contains: set-up instructions, unit specs, safety information,
IMPORTANT:
Your unit is preprogrammed
Place your unit in the desired location. Plug the unit in and allow it to cool and become stable for a minimum
of 24 hours before logging temperature or stocking products.
Be careful when setting or changing temperatures
WARNING: Changing some controller parameters can damage your unit and/or result in a loss of product. K2
will not be held responsible for losses due to unauthorized parameter changes.
Changing advanced parameters may damage the unit or void your warranty.
Please contact K2 before attempting to change advanced parameters.
Unfamiliar with the operation of a K2 controller?
Use the video tutorials on our website resources page or call us for assistance with special parameters.
Some K2 units can be changed from Celsius to Fahrenheit. We do not recommend changing your
unit to Fahrenheit. Your controller has operational parameters that rely on data in Celsius to
maintain proper function.
3.3.2022
Thank you for your purchase.
controller operation and maintenance steps.
K202, K204, K210, K220
Advertisement
Related Manuals for K2 Scientific Dixell XR60CX
Summary of Contents for K2 Scientific Dixell XR60CX
- Page 1 Dixell XR60CX Operating Manual Thank you for your purchase. This manual contains: set-up instructions, unit specs, safety information, controller operation and maintenance steps. K202, K204, K210, K220 IMPORTANT: Your unit is preprogrammed Place your unit in the desired location. Plug the unit in and allow it to cool and become stable for a minimum of 24 hours before logging temperature or stocking products.
- Page 2 Dixell Operating Manual POSITIONING • Incorrect positioning can cause damage to the equipment and generate hazardous conditions for personnel. The installer must therefore observe the following general regulations: Make sure you maintain a minimum of 2” (5 cm). clearance from the walls and 15” (40 cm) from the •...
- Page 3 Dixell Operating Manual CONTENTS Front Panel Commands How to Use the Hot Key Parameters Fans Alarm Signaling Temperature Logging Defrost Troubleshooting Default Setting Values 10. Routine Maintenance Front Panel Commands -QUICKGUIDE This key displays your target set point. When in programming mode, it confirms an operation.
- Page 4 Dixell Operating Manual Parameters - How to change a parameter value 1. Enter the programming mode by pressing keys for 3s. (°C or °F LED starts blinking) 2. Use the up and down keys to select the required parameter. Press the SET key to display its value. 3.
- Page 5 Dixell Operating Manual Alarm Signaling Code Alarm Recovery Probe alarms “P1” and “P2” start some seconds after the fault in the related probe; they automatically stop some seconds after the probe restarts normal operation. Check connections before replacing the probe. Temperature alarms “HA” and “LA” automatically stop as soon as the temperature returns to normal values.
- Page 6 Dixell Operating Manual Default Setting Values Refrigerator...
- Page 7 Dixell Operating Manual Dixell Operating Manual Default Setting Values Freezer...
- Page 8 Dixell Operating Manual Dixell Operating Manual How to Use the Hot Key Fans • FC=cn Will switch ON and OFF with the compressor 1. Program one controller with the front keypad. and not run during defrost. 2. When the controller is ON, insert the “Hot key” and •...
- Page 9 Dixell Operating Manual Dixell Operating Manual Troubleshooting...
- Page 10 Service K2 Scientific want to make sure you are happy with your purchase. There are several ways for you to contact us with questions or service needs. Be sure to include your four-digit order number or at least your model number handy to speed up the process.
