Cardinal SMARTCELL Manual

Dc digital load cell kit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DC Digital
Load Cell Kit
Technical Manual
0330-0653-0M Rev D • DC Load Cell Kit
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMARTCELL and is the answer not in the manual?

Questions and answers

Related Manuals for Cardinal SMARTCELL

Summary of Contents for Cardinal SMARTCELL

  • Page 1 DC Digital Load Cell Kit Technical Manual 0330-0653-0M Rev D • DC Load Cell Kit...
  • Page 2 0330-0653-0M Rev D • DC Load Cell Kit...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ........... . . LOAD CELL INSTALLATION .
  • Page 4 TABLE OF CONTENTS, CONT. DIGITAL SCALE DIAGNOSTICS ......... 225D DIGITAL SCALE DIAGNOSTICS .
  • Page 5 Copyright All rights reserved. Reproduction or use, without expressed written permission, of editorial or pictorial content, in any manner, is prohibited. No patent liability is assumed with respect to the use of the information contained herein. Disclaimer While every precaution has been taken in the preparation of this manual, the Seller assumes no responsibility for errors or omissions.
  • Page 6 0330-0653-0M Rev D • DC Load Cell Kit...

  • Page 7: Introduction

    The DC Load Cell Kit utilizes Cardinal Scale’s SmartCell DC digital load cells and 225DLC or 825-DLC Digital Load Cell Controller to provide in-depth diagnostics, easy maintenance, and a simplified calibration. Braided cabling is available for enhanced rodent protection throughout the scale.

  • Page 8: Load Cell Installation

    LOAD CELL INSTALLATION NOTE: Cardinal Scale Mfg. Co. recommends that the customer install protective conduit/cover for the load cell cables whenever the condition is present that can result in damage or abrasion to the load cell cables. CAUTION! Be sure all restraint systems are loosened before jacking up the scale.

  • Page 9: Lateral And Longitudinal Checking

    IMPORTANT! Cardinal Scale Mfg. Co. recommends that lateral and longitudinal checking limits be adjusted to ± 1/8-inch (3.2 mm) clearance. 0330-0653-0M Rev D • DC Load Cell Kit...

  • Page 10: Installing Load Cell Cables

    INSTALLING LOAD CELL CABLES All digital scales using Cardinal Scale’s SmartCell DC digital load cells are connected with a daisy-chained CAN (Controller Area Network) cable. The load cell connection loop can begin at any load cell and may continue clockwise as shown or counter-clockwise if preferred. Note that in the tank/hopper example below there is not a connection between cells 1 and 2 and in the truck scale example, there is not a connection between cells 4 and 6.
  • Page 11 Run the load cell cable through the conduit installed in the weighbridges between load cells. Install the load cell cable connectors on the load cell fittings, and hand-tighten the connectors. Insert load cell cable into the Install load cell cable connectors on weighbridge conduit.

  • Page 12: Homerun Cable Installation

    HOMERUN CABLE INSTALLATION The Homerun Cable is installed between the 225D or 825D indicator and the first load cell in the loop (Start Node). Consult the chart below to determine the maximum Homerun Cable length. Note that the number of load cells in the scale determines the maximum length. Maximum Homerun Cable Length (Determined by Number of Load Cells in Scale) 0330-0653-0M Rev D •...
  • Page 13 5-pin spring cage connector, from the Home Run Cable Connector Pack. Refer to the table below for cable and connector information. Cable and Connector Information ITEM and DESCRIPTION CARDINAL PART NO. HOMERUN CABLE, 5 CONDUCTOR, SHIELDED PVC 6980-1092 (CONTAINS 2 x 18AWG, 2 x 22AWG, AND 1 x 22AWG)

  • Page 14: Indicator Connection

    225D Indicator Connection The homerun cable should be routed through the metallic gland connector installed in the 225D rear panel (lower right). Optional 2XX-USBA (Serial, Connectors Isolated Inputs or Outputs) AC Power 100-240 VAC (Serial, Isolated 0.4 Amp Max. Fiber Inputs or Optic Outputs)
  • Page 15 4. Route the homerun cable through the nut and plastic insert and into the enclosure. 5. With the homerun cable routed into the enclosure, remove approximately 51 mm of the cables’ outer jacket, exposing the internal wires. 6. Next, remove approximately 6 mm of insulation from each of the five wires. 7.

  • Page 16: Re-Installing The 225D Indicator Rear Panel

    Re-Installing the 225D Indicator Rear Panel 1. After all terminations have been made, remove the excess cable from the indicator enclosure, and finger-tighten each of the cable gland connectors. 2. Ensure any unused gland connectors are plugged and replace the rear panel. 3.
  • Page 17 LED 1-4 The LEDs are used for diagnostic purposes. For a complete explanation of their function, refer to the DIGITAL SCALE DIAGNOSTICS, Hardware Diagnostics section of this manual. Ethernet Port This port is used to connect the 225D to your network to send information to the cloud for iSite. Micro SD Card Slot The Micro SD card slot is not used at this time.

  • Page 18: Indicator Connection

    825D Indicator Connection The homerun cable should be routed through the metallic gland connector installed in the 825D rear panel (lower right). Ground AC Power 10/100 LAN I/O (Serial, Isolated 90-264 VAC and USB Inputs/Outputs) or 0.4 Amp Access Cover Additional Scales Digital Scale ATTENTION!

  • Page 19: Re-Installing The 825D Indicator Rear Panel

    4. Route the homerun cable through the nut and plastic insert and into the enclosure. 5. With the homerun cable routed into the enclosure, remove approximately 51 mm of the cables’ outer jacket, exposing the internal wires. 6. Next, remove approximately 6 mm of insulation from each of the five wires. 7.

  • Page 20: 825Dlc Controller Card

    825-DLC Controller Card Micro J3, J1 ICAN Ethernet D1, D2, D3, D4 Jumpers Port for iSite Homerun Cable Mounting Edge Card P7, RS232 Bracket Serial Port End Node PWR End Connector J2, End Node Jumper Jumper J2 is the CAN bus END NODE jumper and should be ON (installed). NOTE: The 825D is one end of the CAN bus connections and must be installed for the 825D communications to the scale to operate.
  • Page 21 P1, CAN Connection to Scale (Homerun Cable) The P1 terminal block is used to connect the homerun cable between the 825D indicator and the first load cell in the loop (Start Node in the scale). Refer to the table below for terminal connections.

  • Page 22: Load Cell Connection

    5-pin spring cage connector from the Homerun Cable Connector Pack. Refer to the table below for cable and connector information. Cable and Connector Information ITEM and DESCRIPTION CARDINAL PART NO. HOMERUN CABLE, 5 CONDUCTOR, SHIELDED PVC 6980-1092 (CONTAINS 2 x 18AWG, 2 x 22AWG, AND 1 x 22AWG)
  • Page 23 Refer to the Homerun Connector Wiring Color Code Table below when performing steps 4 through 7. Homerun Connector Wiring Color Code Table Connector Homerun Cable Wire Color if using a Signal Wire Color Load Cell Cable Pin Number Lever Color BROWN SHLD GRAY...
  • Page 24 8. After all connections have been made, slide the black plastic and metal connector parts together, and then screw them together by hand-tightening. Slide both connector parts together and hand-tighten. 9. To complete the assembly, hold the black and metal parts of the connector housing, and then hand-tighten the cable clamp to the black plastic part of the connector housing.

  • Page 25: Grounding Installation Instructions

    GROUNDING INSTALLATION INSTRUCTIONS The ground rod shall be copper plated 0.5 in. (1.27 cm.) minimum diameter, with clean exterior surfaces, and shall not be covered with paint, enamel, or other materials, which are poor conductors. The ground rod shall be embedded below permanent moisture level at least 8 ft. (2.44 m.) where practicable.

  • Page 26: Setup And Configuration

    SETUP AND CONFIGURATION Digital Scale Setup and Configuration All digital scales using Cardinal Scale’s SmartCell DC digital load cells are connected with a daisy-chained CAN (Controller Area Network) cable. The load cell connection loop can begin at any load cell and may continue clockwise as shown or counter-clockwise if preferred. Note that in the tank/hopper example below there is not a connection between cells 1 and 2 and in the truck scale example, there is not a connection between cells 4 and 6.

  • Page 27: To Begin 225D Setup And Configuration

    To Begin 225D Setup and Configuration Addressing Cells Each cell has a serial number (S/N) marked on the cell. This is an 8-digit hexadecimal number. It is also known as the Cell ID. Each Cell ID must be matched with a cell address. In the tank/hopper example, the addresses would be 1-4.

  • Page 28: End Nodes

    End Nodes The 225D indicator also needs to know where the scale starts and ends. The START NODE is the cell that connects to the 225D. The END node is the last cell in the daisy chain. In the tank/hopper example, the START node is #1 and the END node is #2. In the truck scale example, the START node is #4 and the END node is #6.

  • Page 29: Smart Calibration

    Center the weight over scale X and press ENTER to take a weight sample. Repeat steps 5, 6 for each cell in the order that the 225D prompts for. (This is the same order as other Cardinal scales e.g. 1, 3, 5, 7, 8, 6, 4, 2). ZERO CALIBRATION Zero Calibration does not affect the trimming of the cells or affect span.

  • Page 30: Trim Cells

    TRIM CELLS Individual cells or pairs of cells may be trimmed. This requires a test load weight. Press 3 and ENTER. The 225D will prompt for “Cell Number(s): “. To trim a single cell, enter the cell number, and press ENTER. To trim a pair of cells, enter both cells in the form “X + Y”, and press ENTER.

  • Page 31: To Begin 825D Setup And Configuration

    To Begin 825D Setup and Configuration 1. Press the ON/OFF key to turn on the 825D. The display will perform a short self-test and then change to the Startup screen showing the software versions and status of the mainboard and option cards. MnBd DLC IMPORTANT! The shown under Item indicates the mainboard is...

  • Page 32: Login

    Login Login 1. With the screen and prompt displayed, use the alphanumeric keys to enter the login, and then press the  Down Arrow to advance to the password prompt 2. Enter the password using the alphanumeric keys, and then press the ENTER key to proceed with Setup and Configuration.

  • Page 33: Setup Scale Number

    Setup Scale Number Setup Scale Number With the Setup Scale Number screen displayed, press the D key, or use the Navigation Keys D. Configure DLC , and then press the ENTER key. The display will to select (highlight) Setup DLC Card 1 change to show the screen.

  • Page 34: Setup Dlc Card 1

    Setup DLC Card 1 Scales: – Set the number of scales. Cells: – Set the total number of cells. First Cell: – Set the cell number that is connected to the 825D indicator. Last Cell: – Set the cell number of the end of the chain of load cells. iSITE SO: –...

  • Page 35: Dlc Card 1 Cell Assignment

    DLC Card 1 Cell Assignment The left side of the column shows the existing programmed IDs and scale number assigned for each cell. If any cells are detected on the bus that is not assigned, they will show on the right column Unassigned ID under the heading.
  • Page 36 DLC Card 1 Cell Assignment, Cont. The right navigation key may be used to select the unassigned column. The left navigation key may be used to select the existing cell IDs. The up/down navigation keys may be used to select a specific cell. Assign Cell Select the next cell to assign on the right column and press the A key to assign it to the next unassigned cell (cell ID 00000000).
  • Page 37 DLC Card 1 Cell Assignment, Cont. Cell IDs may also be entered manually and the scale to associate with the cell by selecting an item in the left column pressing the SPACE key. 0330-0653-0M Rev D • DC Load Cell Kit...
  • Page 38 DLC Card 1 Cell Assignment, Cont. Cell ID Type the if it is to be changed, press the down navigation key to select the Scale: prompt, and then enter the scale number. When finished press and release the SHIFT key, then press the ESC/← key. The display will return to the Setup Scale Number screen.

  • Page 39: Smart Calibration

    IMPORTANT! Before calibrating the scale, it is very important that the dead load of the weighbridge is evenly distributed between the pair of cells in a section. Refer to the Balancing Weighbridge Dead Load section on page 54 of this manual for more instructions. Smart Calibration 2.
  • Page 40 Smart Calibration, Cont. Scale 1 – Smart Calibration With the screen displayed, enter the weight value of the test weight to be used. 0330-0653-0M Rev D • DC Load Cell Kit...
  • Page 41 Smart Calibration, Cont. With an empty scale, press ENTER. This will capture the calibrated dead load weight of the scale. 0330-0653-0M Rev D • DC Load Cell Kit...
  • Page 42 Smart Calibration, Cont. The 825D display will change to show that it is calibrating. 0330-0653-0M Rev D • DC Load Cell Kit...
  • Page 43 Smart Calibration, Cont. Center the weight over load cell 1, and press ENTER. 0330-0653-0M Rev D • DC Load Cell Kit...
  • Page 44 Smart Calibration, Cont. The 825D display will change to show that it is calibrating the weight on load cell 1. 0330-0653-0M Rev D • DC Load Cell Kit...
  • Page 45 Smart Calibration, Cont. Move the test weight and center it over load cell 2, and press ENTER. The 825D display will change to show that it is calibrating the weight on load cell 2. 0330-0653-0M Rev D • DC Load Cell Kit...
  • Page 46 Smart Calibration, Cont. Move the test weight and center it over load cell 3, and press ENTER. The 825D display will change to show that it is calibrating the weight on load cell 3. 0330-0653-0M Rev D • DC Load Cell Kit...
  • Page 47 Smart Calibration, Cont. Move the test weight and center it over load cell 4, and press ENTER. The 825D display will change to show that it is calibrating the weight on the load cell. If more than four cells and the number of cells is even a number (such as for an eight-cell scale), the calibration pattern will be the odd number cells, then the even number cells in reverse to facilitate easy weight cart movement: 1, 3, 5, 7, 8, 6, 4, 2...

  • Page 48: Zero Calibration

    Zero Calibration 3. Zero Calibration Scale 1 – Calibration Options With the screen displayed, press the 3 key or 3. Zero Calibration use the Navigation Keys to select (highlight) , and then press the ENTER key. Scale 1 – Zero Calibration The display will change to show the screen.
  • Page 49 Zero Calibration, Cont. With an empty scale, press ENTER. Zero Calibration does not affect the trimming of the cells or affect span; it simply sets the dead load weight of the scale. 0330-0653-0M Rev D • DC Load Cell Kit...
  • Page 50 Zero Calibration, Cont. The 825D display will change to show that it is calibrating zero. 0330-0653-0M Rev D • DC Load Cell Kit...

  • Page 51: Trim Cells

    Trim Cells 4. Trim Load Cells Scale 1 – Calibration Options With the screen displayed, press the 3 key or 4. Trim Load Cells use the Navigation Keys to select (highlight) , and then press the ENTER key. Scale 1 – Trim Cells The display will change to show the screen.
  • Page 52 Trim Cells, Cont. Section Trim Mode Individual cells or a section (pairs of cells) may be trimmed. This requires a test load weight. M)ode – Press the M key to toggle between Section or Single Cell trim. Default is Section. Use the Navigation Keys to select (highlight) the section to trim.
  • Page 53 Trim Cells, Cont. Single Cell Mode Press the M key to select Single Cell trim. Use the Navigation Keys to select (highlight) the cell to trim. 0330-0653-0M Rev D • DC Load Cell Kit...
  • Page 54 Trim Cells, Cont. Single Cell Mode, Cont. With the desired cell selected, enter the Trim Value, and press the ENTER key to set the weight to adjust trim. 0330-0653-0M Rev D • DC Load Cell Kit...
  • Page 55 Trim Cells, Cont. Single Cell Mode, Cont. The 825D will automatically trim the cell to match the entered weight. 0330-0653-0M Rev D • DC Load Cell Kit...
  • Page 56 Trim Cells, Cont. Single Cell Mode, Cont. NOTE: If in the Single Cell mode, manually enter a trim value by pressing the FUNCT key, then press the (•) period key. This can be used to enter a slight adjustment, such as change 0.98411 to 0.98421.

  • Page 57: Span Adjust

    Span Adjust 5. Span Adjust Scale 1 – Calibration Options With the screen displayed, press the 3 key or 5. Span Adjust use the Navigation Keys to select (highlight) , and then press the ENTER key. Scale 1 – Span Adjust The display will change to show the screen.
  • Page 58 Span Adjust Span adjust allows you to tweak the span of the entire scale at once. The 825D will display the current live scale weight. Place the test weight at any location on the scale. Enter the value of the test weight and press the ENTER key. 0330-0653-0M Rev D •...
  • Page 59 Span Adjust After a brief delay, the span will be adjusted (trim will be adjusted for all cells of the scale) and Scale 1 – Calibration Options the 825D display will return to the screen. 0330-0653-0M Rev D • DC Load Cell Kit...

  • Page 60: Balancing Weighbridge Dead Load

    BALANCING WEIGHBRIDGE DEAD LOAD IMPORTANT! Before calibration, make sure the dead load of the weighbridge is evenly distributed between the pair of cells in a section. Begin by powering up the indicator and proceeding to the Diagnostics Menu to the LOADCELL WEIGHTS screen on the 225D or the LIVE LOAD CELL WEIGHTS on the 825D.

  • Page 61: Digital Scale Diagnostics

    DIGITAL SCALE DIAGNOSTICS There are three main components to the 225D and 825D Digital Scale Diagnostics: • On Screen Diagnostics – Critical errors that alert operators from the main screen of setup issues or hardware problems. • Diagnostic Menu – A set of diagnostic tools that give a technician more information about each load cell.
  • Page 62 COMMUNICATION ERROR BETWEEN LOAD CELLS X AND Y NO WEIGHT  -------    COMMUNICATION ERROR BETWEEN LOAD CELLS 1 AND 3 COUNT Probable Cause Items to Check There is a loss of • Check that cable is connected correctly. communication between load •...
  • Page 63 LOAD CELL X HAS BEEN REPLACED NO WEIGHT  -------   LOAD CELL 2 HAS BEEN REPLACED. SCALE NOT LEGAL FOR TRADE UNTIL CALIBRATED. PRESS ENTER TO CONTINUE Probable Cause Items to Check A load cell has been replaced. Replaced load cells are automatically detected as long as only one load cell was replaced.
  • Page 64 LOAD CELL ID 8F07E8F HAS NO ADDRESS NO WEIGHT  -------    LOAD CELL ID 8F07E8F HAS NO ADDRESS COUNT Probable Cause Items to Check A load cell is responding, but Go to the addressing menu and assign the load cell ID to it is not addressed in the an address.
  • Page 65 DIGITAL SCALE BOARD NOT DETECTED NO WEIGHT  -------   DIGITAL SCALE CARD NOT DETECTED COUNT Probable Cause Items to Check The 225D cannot • Check that the card is seated properly and fastened communicate with the option correctly. card or the option card is not •...

  • Page 66: Diagnostic Menu

    Diagnostic Menu To enter the diagnostic menu press SHIFT + CELL_DIAG soft key. All diagnostic information except software version update once per second. LIVE LOAD CELL WEIGHTS (This can be zeroed as needed.) LOAD CELL WEIGHTS -106 -120 PREVIOUS NEXT EXIT MINIMUM AND MAXIMUM WEIGHTS (This can be zeroed as needed.) MAXIMUM / MINIMUM WEIGHTS...
  • Page 67 SOFTWARE VERSION OF CELL LOADCELL SOFTWARE VERSIONS 1. 1.0.14 6. 1.0.14 2. 1.0.14 7. 1.0.14 3. 1.0.14 8. 1.0.14 4. 1.0.14 5. 1.0.14 PREVIOUS NEXT EXIT NOTE: The controller’s version number, in contrast, is displayed upon startup of the 225D indicator.
  • Page 68 WEIGHT ERROR COUNTS WEIGHT ERROR COUNTS 1. 0 6. 0 2. 0 7. 0 3. 0 8. 0 4. 0 5. 0 PREVIOUS NEXT EXIT CELL POWER SUPPLY VOLTAGES CELL POWER SUPPLY VOLTAGES *Approx. 14.355 14.191 13.950 14.530 14.334 14.260 14.211 14.267 * 0.184 Amps...
  • Page 69 SNAP COMMUNICATIONS DIAGNOSTICS When the SNAP SmartMedia Box communications are enabled, an additional page of the Digital Scale Diagnostics is available. This will scan and list the IDs of any SmartMedia boxes that it finds on the same channel that the indicator is set to.

  • Page 70: Hardware Diagnostics

    Hardware Diagnostics The 225DLC (Digital Load cell Controller) option card has four LEDs for diagnostic purposes. LED1 LED2 LED3 LED4 LED1 (RED) – MAIN BOARD TX/RX: Toggles each time the DLC controller and the 225D Mainboard exchange messages. LED2 (RED) – TX TO LOAD CELL: Toggles each time a message is sent from the DLC controller to the load cells.

  • Page 71: Detecting 225D Board Replacements

    NEW card to the existing scale. 225DLC DIGITAL CONTROLLER CARD REPLACEMENT If an option card is replaced, the 225D will boot up to this screen: BY CARDINAL Revision 0.1.04 NEW CARD FOUND! WAS DIGITAL SCALE CARD REPLACED? NO The 225D indicator will check whether the option card has been replaced in order to reconfigure the new option card to the existing scale.

  • Page 72: 225Dlc Digital Controller Card Replacement

    225DLC DIGITAL CONTROLLER CARD REPLACEMENT Remove this screw, washer, and the ground wire Remove the remaining three screws and lock washers Align pins on 225DLC card with holes in 0330-0653-0M Rev D • DC Load Cell Kit...
  • Page 73 12. Re-insert the 225D power cord into the wall outlet. 13. Press the ON/OFF key on the 225D keypad to turn on the indicator. 14. The 225D will boot up to this screen: BY CARDINAL Revision 0.1.04 NEW CARD FOUND! WAS DIGITAL SCALE CARD REPLACED? NO 15.

  • Page 74: Digital Scale Diagnostics

    825D DIGITAL SCALE DIAGNOSTICS On Screen Diagnostics The On Screen Diagnostics messages are critical errors that alert operators from the main screen of setup issues or hardware problems. These messages will be shown to the operator on the main weight screen in real-time when the error happens. COMMUNICATION ERROR BETWEEN INDICATOR AND SCALE Probable Cause Items to Check...
  • Page 75 COMMUNICATION ERROR BETWEEN LOAD CELLS X AND Y Probable Cause Items to Check There is a loss of • Check that cable is connected correctly. communication between load • Check cable for damage. cells. • Verify that connector is clear of debris. •...
  • Page 76 LOAD CELL X, Y, Z NOT RESPONDING Probable Cause Items to Check The 825D cannot detect the • Check that cable is connected correctly. exact communication problem • Check cable for damage. with the unresponsive load • Verify that connector is clear of debris. cell.
  • Page 77 LOW VOLTAGE DETECTED ON LOAD CELL X, Y, Z Probable Cause Items to Check Low power on a load cell. • Too many load cells on the chain. Load cells at the end of the • Check that cable is connected correctly. CAN daisy chain are most •...

  • Page 78: Diagnostic Menu

    Diagnostic Menu The Diagnostic Menu is a set of diagnostic tools that give a technician more information about each load cell. 6. DLC Diagnostics Scale 1 – Calibration Options With the screen displayed, press the 6 key or 6. DLC Diagnostics use the Navigation Keys to select (highlight) , and then press the ENTER key.
  • Page 79 LIVE LOAD CELL WEIGHTS Use the Navigation Keys to scroll the display to show all cells. Load Cell Weights Press the W key to jump to the screen from the other diagnostic screens. 0330-0653-0M Rev D • DC Load Cell Kit...
  • Page 80 ZERO LIVE LOAD CELL WEIGHTS The Z key (for Zero) may be used to zero the diagnostics display while in the diagnostics screen. It does not affect scale zero. Use the Navigation Keys to scroll the display to show all cells. Load Cell Weights Press the W key to jump to the screen from the other diagnostic...
  • Page 81 MINIMUM AND MAXIMUM WEIGHTS Use the Navigation Keys to scroll the display to show all cells. Maximum / Minimum Weights Press the X key to jump to the screen from the other diagnostic screens. 0330-0653-0M Rev D • DC Load Cell Kit...
  • Page 82 DEADLOAD SHIFT This shows the live shift from the originally calibrated deadload. An asterisk () indicates that the deadload shift has been exceeded. The scale must empty for this to be valid. Use the Navigation Keys to scroll the display to show all cells. Deadload Shift Press the D key to jump to the screen from the other diagnostic...
  • Page 83 LOAD CELL IDS / SOFTWARE VERSIONS Use the Navigation Keys to scroll the display to show all cells. Load Cell IDs / Software Versions Press the R key to jump to the screen from the other diagnostic screens. 0330-0653-0M Rev D • DC Load Cell Kit...
  • Page 84 LOAD CELL COMMUNICATION ERROR COUNTS Use the Navigation Keys to scroll the display to show all cells. Load Cell Communication Error Counts Press the E key to jump to the screen from the other diagnostic screens. 0330-0653-0M Rev D • DC Load Cell Kit...
  • Page 85 ZERO LOAD CELL COMMUNICATION ERROR COUNTS Use the Navigation Keys to scroll the display to show all cells. Press the C key to clear the Communication Error Counts. Load Cell Communication Error Counts Press the E key to jump to the screen from the other diagnostic screens.
  • Page 86 WEIGHT ERROR COUNTS Weight Error Counts are analog errors that would normally indicate a bad cell. Use the Navigation Keys to scroll the display to show all cells. Press the C key to clear the Weight Error Counts. Weight Error Counts Press the G key to jump to the screen from the other diagnostic screens.
  • Page 87 LOAD CELL TEMPERATURES This is the temperature of the cells in Celsius. Use the Navigation Keys to scroll the display to show all cells. Load Cell Temperatures Press the T key to jump to the screen from the other diagnostic screens. 0330-0653-0M Rev D •...
  • Page 88 LOAD CELL MINIMUM / MAXIMUM TEMPS Use the Navigation Keys to scroll the display to show all cells. Load Cell Maximum / Minimum Temps Press the Q key to jump to the screen from the other diagnostic screens. 0330-0653-0M Rev D • DC Load Cell Kit...
  • Page 89 LOAD CELL MILLIVOLTS Use the Navigation Keys to scroll the display to show all cells. Load Cell Millivolts Press the M key to jump to the screen from the other diagnostic screens. 0330-0653-0M Rev D • DC Load Cell Kit...
  • Page 90 LOAD CELL ABSOLUTE MAXIMUM WEIGHTS Use the Navigation Keys to scroll the display to show all cells. Load Cell Absolute Maximum Weights Press the O key to jump to the screen from the other diagnostic screens. 0330-0653-0M Rev D • DC Load Cell Kit...
  • Page 91 SUPPLY VOLTAGE – RAW COUNT / VOLTAGE NOTE: An asterisk () indicates voltage determination is approximated based on the raw count value. Use the Navigation Keys to scroll the display to show all cells. Supply Voltage – Raw Count / Voltage Press the V key to jump to the screen from the other diagnostic screens.
  • Page 92 LOAD CELL RAW COUNTS Use the Navigation Keys to scroll the display to show all cells. Load Cell Raw Counts Press the R key to jump to the screen from the other diagnostic screens. 0330-0653-0M Rev D • DC Load Cell Kit...

  • Page 93: Hardware Diagnostics

    Hardware Diagnostics The 825-DLC (Digital Load cell Controller) option card has four LEDs for diagnostic purposes. D1 – Blinking = Indicates the 825-DLC card is communicating with the 825D mainboard. D2 – Blinking = Indicates the 825-DLC card is transmitting messages is to the load cells. D3 –...

  • Page 94: Detecting 825D Board Replacements

    DETECTING 825D BOARD REPLACEMENTS The 825D will detect when a DLC controller or 825D mainboard has been replaced using checksums and unique board identification numbers. Based on several parameters, it can detect whether the option card was replaced, or the mainboard was replaced and then reconfigure the NEW card to the existing scale.
  • Page 95 825D MAIN PCB REPLACEMENT If an 825D main board is replaced, the 825D will boot up to this screen: The system will also check whether the 825D’s mainboard has been replaced, so the scale configuration can be downloaded from the controller to the mainboard. If the operator selects YES, then the scale configuration will be downloaded from the controller to the mainboard.

  • Page 96: 825Dlc Digital Controller Card Replacement

    825DLC DIGITAL CONTROLLER CARD REPLACEMENT CAUTION! OBSERVE THE PRECAUTIONS FOR HANDLING STATIC SENSITIVE DEVICES 1. Remove the 825D power cord from the wall outlet. 2. Remove the fourteen acorn nuts securing the rear panel to the main housing. 3. Lift the rear panel from the main housing, taking care not to stretch the cables and wires between the panel and main housing.
  • Page 97 12. The 825D will boot up to this screen: 13. The 825D will check whether the option card has been replaced, in order to reconfigure the new option card to the existing scale. 14. If the operator selects Y, then the 825D mainboard will upload the scale configuration to the new 825-DLC card, and the 825D will immediately be able to make weight again.

  • Page 98: Troubleshooting Guide

    Before calling Cardinal Scale for assistance, there are a few things to check first that can be done to get the system back up and running. Remember, that there is a logical explanation for all problems, and for troubleshooting to be successful, it must be approached in a logical and rational manner.
  • Page 99 LOW VOLTAGE DETECTED CELL X, Cont. SOLUTION: I. If the system voltage is below 9 VDC, proceed as follows: J. First, remove the White (V+ Bus) and Blue (V- Bus) wires from the Homerun cable on the DLC Card, and using a DVM, read the voltage on the connector. This should be a minimum of 14 VDC on the 225DLC (11.5 VDC on the 825-DLC).

  • Page 100: Current Draw More Than 150% Of Capacity

    CURRENT DRAW MORE THAN 150% OF CAPACITY SOLUTION: A. Cut the end off of an extra load cell cable and strip back the wires to make a test cable. B. Ensure the scale is powered up. C. Remove the End Node (terminator) from the last load cell in the loop, and connect the test cable to the port on the load cell where the End Node (terminator) was.

  • Page 101: Load Cell X Not Responding

    IDs and their corresponding scale locations (NOT the location in the data loop). C. If a Cardinal Digital Load Cell Simulator is available, remove the Homerun cable from the first load cell in the loop and attach it to the simulator.
  • Page 102 COMMUNICATIONS ERROR BETWEEN INDICATOR AND SCALE, Cont. SOLUTION: H. If a NEST is not available, proceed with the following instructions to check the Homerun cable for shorts: 1. Disconnect the Homerun cable from the load cell (Start Node). 2. Starting with one wire, check the resistance between it and each of the other wires one at a time.

  • Page 103: Load Cell X Has No Address

    LOAD CELL X HAS NO ADDRESS SOLUTION: A. Go to the Scale Setup screen and enter the load cell ID in the correct scale location. COMMUNICATION ERROR BETWEEN LOADCELLS X AND Y SOLUTION: A. Use the NEST to test the suspect load cell cable for defects. B.

  • Page 104: Load Cell Or Scale Communication Problems

    LOAD CELL OR SCALE COMMUNICATIONS PROBLEMS SOLUTION: A. Go to the Diagnostics screen LOAD CELL COMMUNICATIONS ERRORS and observe the historical error counters for each load cell. B. Record these numbers. C. Press EXIT(?) to zero the counters on the 225D. For the 825D, press C)lear to zero the counters.

  • Page 105: Parts Identification

    PARTS IDENTIFICATION Load Cell not included DC-50K / DC-100K 0146-B020-08 RC3-KIT 50K or 100K Digital, Load Cell Cup Retainer Two Load Cell Cups and Stainless Steel, Plate (non-painted) Mounting Hardware to Compression, Load Cell adapt DC Load Cell into existing RC3 installation 0330-0065-08 0330-0066-08 0330-0443-08...
  • Page 106 PARTS IDENTIFICATION, CONT. 225-DLC 825-DLC 225DLC Digital Load Cell Controller 825DLC Digital Load Cell Controller 0330-0653-0M Rev D • DC Load Cell Kit...
  • Page 107 STATEMENT OF LIMITED WARRANTY WARRANTY TERMS Cardinal Scale Manufacturing Company warrants the equipment we manufacture against defects in material and workmanship. The length and terms and conditions of these warranties vary with the type of product and are summarized below:...
  • Page 108 This warranty sets forth the extent of our liability for breach of any warranty or deficiency in connection with the sale or use of our product. Cardinal will not be liable for consequential damages of any nature, including but not limited to loss of profit, delays or expenses, whether based on tort or contract.
  • Page 109 0330-0153-0M Rev A • Digital Truck Scale...
  • Page 110 Cardinal Scale Mfg. Co. 102 E. Daugherty, Webb City, MO 64870 USA Ph: 417-673-4631 or 1-800-641-2008 Fax: 417-673-2153 www.cardinalscale.com Technical Support: 1-866-254-8261 E-mail: tech@cardet.com Printed in USA 0330-0653-0M Rev D 11/20 0330-0153-0M Rev A • Digital Truck Scale...
