Pahlen Maxi-Heat Titanium Quick Start Manual

Heat exchanger Maxi-Heat Titanium
It is important to read this manual carefully in order to ensure smooth functioning and long service life of the pool equipment.
Pahlén AB is not responsible for the product warranty in case of any damage due to improper installation, mishandling or
maintenance.
Product description
Maxi-Flo Titan is a type of tubular heat exchanger with spiral-shaped tubes for the optimal heat transfer. It is made of titanium
to be used in the systems with a high corrosion risk.
Titanium is advantageously used in the pool systems where salt water or chlorinator is used.
Maxi-Flo Titan must be connected to a heat source, such as boiler, heat pump or storage tank for the solar energy collecting
facility.
Maxi-Flo Titan is available in two versions: 75kW and 200kW.
Technical data
Capacity
(at 60°C temperature difference)
Primary side
Flow
Secondary side
Primary side
Pressure drop
Secondary side
Max. temperature
Primary side
Max. pressure
Secondary side
Dimensions
MFT260
Item no. 11377
G
C
G G
C C
B
A
Model A
11377 - 139 mm Ø129 mm
MFT260
11380 - B B 222 mm Ø196 mm
MFT680
A A
MFT260 MFT680
Item no. 11377 Item no. 11380
75kW 200kW
35 l/min 95 l/min
300 l/min 600 l/min
0.9 mVp 0.1 mVp
1.8 mVp 3 mVp
120°C 120°C
10bar 10bar
5bar 4bar
G
MFT680
Item no. 11380
G G
B
A
B C D
1" 597 mm 84 mm
B B 2" 626 mm 143 mm
A A
The product is intended for the following water
values:
Total chlorine content: max 3.5 mg/liter (ppm)*
Chlorine (salt) total:
pH-value:
Alkalinity:
Calcium hardness:
Iron:
Copper:
Manganese:
Phosphorus:
Nitrate:
Outside these values the product warranty does not
apply
G
C
G G
C C
B
A
E F G
2" 168 mm
Ø75 (DN65) 294 mm B B
A A
5
ENGLISH
max 35 0 00 mg/liter
7.2 - 7.6
60-120 mg/liter (ppm)
100-300 mg/liter (ppm)
max 0.1 mg/liter *
max 0.2 mg/liter *
max 0.05 mg/liter *
max 0.01 mg/liter *
max 50 mg/liter *
* Complies to EN 16713-3
G
C
G G
C C
B
A
H I J
250 mm 429 mm 82 mm
340 mm 340 mm B B 109 mm
A A
Weight
empty/filled
3/10 kg
8/24 kg
