RILEVATORE DI VEICOLI A SPIRE
VEHICLE LOOP DETECTOR
DETECTEUR DE VÉHICULES A BOUCLE INDUCTIVE
INDUKTIONSSCHLEIFEN-DETEKTOR ZUR DETEKTION VON FAHRZEUgEN
DETECTOR DE VEHÍCULOS DE LAZO INDUCTIVO
LUSDETECTOR VOERTUIgEN
LAÇO DETECTOR DE VEÍCULOS
ΑΝΙΧΝΕΥΤΗΣ ΟΧΗΜΑΤΩΝ ΜΕ ΒΡΟΧΟΥΣ
INDUKCYJNY DETEKTOR POJAZDÓW
ПЕТЛЕВОЙ ДЕТЕКТОР ТРАНСПОРТНЫХ СРЕДСТВ
DETEKTOR VOZIDEL S INDUKČNÍ SMYČKOU
ARAÇLAR İÇİN DÖNgÜ DEDEKTÖRÜ
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for BFT RME1
Summary of Contents for BFT RME1
- Page 1 0 2 7 9 0 8 3 3 9 1 1 9 RILEVATORE DI VEICOLI A SPIRE VEHICLE LOOP DETECTOR DETECTEUR DE VÉHICULES A BOUCLE INDUCTIVE INDUKTIONSSCHLEIFEN-DETEKTOR ZUR DETEKTION VON FAHRZEUgEN DETECTOR DE VEHÍCULOS DE LAZO INDUCTIVO LUSDETECTOR VOERTUIgEN LAÇO DETECTOR DE VEÍCULOS ΑΝΙΧΝΕΥΤΗΣ...
- Page 2 RRME 1 and RME1 BT are two single-channel inductive loop detectors. By using microprocessor and surface-mount technology, a great many features can be integrated into a small space. RME 1 and RME1 BT are compatible with most commercially available single-channel detectors and are easy to set and install.
-
Page 3: Wiring Diagram
ENGLISH INSTALLATION MANUAL DIAGNOSTICS: SYMPTOM POSSIBLE CAUSE SOLUTION The POWER LED is not on. No power supply voltage on the Check that the power supply is correctly wired input. to the detector. (PINS 1 and 2) The DETECT LED lashes There may be a poor connection Check all wiring. - Page 4 INSTALLATION MANUAL ENGLISH TECHNICAL DATA 200 - 260VAC 50Hz 1,5VA POWER REQUIREMENT: RME 1 11 - 26VAC/DC 50/60Hz 95mA max. RME 1 BT 0.5A/220VAC. PRESENCE/PULSE RELAY : Approximately 120ms after vehicle enters loop. RESPONSE TIME: LED indicators show: Power ,Detect state and Loop Fault. INDICATOR: 15 - 1500 uH.
- Page 5 ENGLISH INSTALLATION MANUAL RELAY FUNCTIONALITY: RELAYS VEHICLE PRESENT NO VEHICLE LOOP FAULTY NO POWER CLOSED OPEN CLOSED CLOSED PRESENCE RELAY OPEN CLOSED OPEN OPEN PULSE CLOSED OPEN OPEN OPEN PULSE RELAY PULSE OPEN CLOSED CLOSED CLOSED INSTALLATION GUIDE: 1. The detector should be installed in a waterproof housing as close to the loop as possible. 2.
