- Page 1 INSTRUCTION PLD7000 9000BL LS8000 SERIES...
-
Page 2: For Safety
FOR SAFETY Followings are the safety instructions & rules. Prior to using the safe, please read the instructions carefully. Cautions when placing the safe. The safe is so heavy that it is to be handled very carefully. Never move the safe in door open. Be cautious not to be bumped against corners of safe. - Page 3 Overview Components 1.5V Alkaline Alarm 9V Battery Instruction Shelf Shelf Clips AA Batteries (Optional) for Alarm (Optional) PLD7000BL : 2pcs / 8pcs 8pcs PLD9000BL : 3pcs / 12pcs Nomenclature Front Interior Door back Battery Case LED Light Optional Finger-print Alarm sensor Memory Button...
-
Page 4: Replace Batteries
1. Batteries Prior to using safe, 1) Push the front of the battery case to expose battery case. 2) Load batteries. PUSH PULL Replace Batteries 1 ) Push the front of 2 ) Pull out Battery Case 3) Replace eight batteries the battery case. - Page 5 3. Set User Code Keep door open. New Code 3) Touch # 1 ) Press M Button on door back. 2 ) Enter New Code ( g ood on FND ) ( 4 ~16 digits ) * NOTE : 1) Prior to closing the door, please confirm with 2. Open with Code if the New Code registered correctly.
- Page 6 5. Open with Finger-print Touch Pad Finger-print Finger-print 1 ) Touch Pad 2) Put Finger-print on 3) Open the door sensor ( OPEnd on FND ) * NOTE : If a unregistered finger-print entered, “bi-bi-bi” sound and ErrOr on FND. * Paralysis : If unregistered finger-prints entered 5 times, the lock gets paralyzed 5 minutes.
-
Page 7: Multi Mode
8. Multi mode ㆍ Two users can independently open safe with each other’s own user code. * Multi mode and dual mode can not be used simultaneously. 1 ) Press M Button on 2) Touch 2 3 ) Touch # 4) Enter 2nd Code 5) Touch # ( g ood on FND ) - Page 8 9. Dual mode (Finger-print + Code) ㆍ Code and finger-print should be entered in a row for opening. * Dual mode and multi mode can not be used simultaneously. 1 ) Press M Button on 2) Touch 5 3 ) Touch # 4) If there is no registered fingerprint door back.
- Page 9 10. Dual mode (Code + Code) ㆍ Two different codes should be entered in a row for opening. * Dual mode and multi mode can not be used simultaneously. * While using Dual locking function (Code + Code), finger-print function doesn’t work. 1 ) Press M Button on 2) Touch 9 4) Enter 2nd Code...
-
Page 10: Alarm Setting
11. Alarm Setting ㆍ Once alarm system is affected by shock or tilt, it makes horn immediately. ㆍ When Alarm system is set on, some impacts to the safe may cause alarm horning. ㆍ Motion sensor may respond to all kinds of movements. Curfew Mode 1 ) Press M Button 2 ) Touch 8... -
Page 11: Volume Control
12. Code and Sound Hide 1 ) Press M Button 2 ) Touch 7 3 ) Touch # ( HldE on FND ) on door back. Unset 1 ) Press M Button 2 ) Touch # 3 ) Touch 7 4) Touch # ( CLEAr on FND ) on door back. - Page 12 19 NoksanSandan 261Ro 60Gil Gangseo-gu Busan, Korea TEL (82 51) 831- 4400 FAX (82 51) 831- 4409 E mail : info@dsafe.co.kr www.dsafe.kr Printed in Korea, JULY 29, 2020...
