Summary of Contents for Alva GCS05
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION • Please read these instructions carefully before using your Please read the instructions carefully cooker. before use. • The operator must understand all safety requirements as detailed in this manual before using the unit. Retain this manual for • The operator is responsible for the safety of all third parties future reference while the cooker is in use. • The manufacturer’s warranty may be voided by incorrect use of this product. • If you have any queries regarding these instructions, contact your local dealer for clarification before you use your cooker. • The unit must be thoroughly checked before use. • Failure to follow the manual’s instructions could result in damage or serious injury. • Ensure that the cooker is positioned on an even and secure surface before operating. • Ensure that all gas fittings are correctly and firmly fitted. - Page 3 INDEX INDEX FEATURES PART NAMES Notes marked with the following; CAUTION SETTING UP YOUR COOKER Contain important information FITTING AND CHANGING THE GAS CYLINDER LEAK TEST USING THE COOKER Notes marked with the following; CARE AND MAINTENANCE SPECIFICATIONS Contain cautions and TROUBLE SHOOTING GUIDE warnings. AFTER SALES SERVICE...
-
Page 4: Part Names
FEATURES • Manual ignition system • “Easy on the eye” body lines Thank you for your • Pot support purchase of this gas • One burner per pot station. cooker. Please read these instructions carefully PART NAMES before use and keep them in a safe place for future reference. 1. Top panel 2. Burner 3. Legs 4. Front panel 5. Gas control... - Page 5 • Make sure that there are no inflammables near the gas Curtain cooker. (Fig. 3) Paper Fig.3 • Only use a SANS 1156-2 or BS3212/2 approved gas hose. (Fig. 4) Rubber hose Vinyl plastic hose Fig.4 • After use, turn the ignition knobs back to the OFF position and make sure the burners are OFF. (Fig. 5) • When the stove is not in use, turn off the gas supply at the cylinder. • Avoid touching the top housing of the cooker as the surface can be very hot during opera- Fig.5 tion. • Only use in well ventilated areas. Always ensure that Ventilation fan the windows are not fully shut during the cooking session. Observe flame stability from time to time while in use.
- Page 6 Consult your gas dealer if the leak persists after tightening the joints. (Fig. 7) • Place the gas cylinder at least 0.5m away from the stove in an upright position. (Fig. 8) • Only use LPG gas. • For safety reasons, the control Fig.8 /ignition knobs are designed to operate in anti-clockwise rotation. • In the event of a burn back (i.e. where the gas burns back on to the jet), turn off the stove and light again. Should the problem persist, take the unit back to your dealer to be checked. • Turn the stove off at the switch controls • Disconnect the regulator and wait for the stove to cool down (± 30 minutes) • If on relighting, the problem reoccurs, get the unit checked by an authorised service dealer • Always check that the direct coupling seal is in place and in good condition. Always ensure that the hose does not show any signs of wear. If in doubt please consult your dealer. SETTING UP YOUR COOKER 1. Confirm that you have the right model for your type of gas supply. Note: This appliance is 2. When unpacking, make sure that all of the parts of the gas designed for use with...
- Page 7 7. Attach the high pressure cylinder connector to the gas valve outlet. Hand fasten in a clockwise direction to ensure a gas FOR YOUR SAFETY tight seal. IF YOU SMELL GAS 8. Perform the LEAK TEST. • Turn off the gas supply at the 9. Locate properly. Maintain a bottle. Wall safe installation proximity. See • Extinguish all Fig.10 naked flames. DO NOT operate Wall 100cm any electrical appliances. 15cm •...
-
Page 8: Using The Cooker
If bubbles appear, turn the cylinder valve OFF (clockwise) and disconnect the stove from the gas cylinder. • Tighten the connection and retry the leak test. • If you are unsure or if you cannot tighten the connection, place the cylinder outside in a cool, well-ventilated area and contact Alva on 086 100 ALVA (2582). Connections to be leak tested • A leak between the stove and Hose to High pressure cylinder connection Hose to appliance cylinder can lead to a high Hose to Cylinder Valve pressure fire, which is very dangerous and can result in Fig.11 extensive injury or even death. -
Page 9: Care And Maintenance
• To adjust the flame size, make slight adjustments to the setting of the control knob. 2. To turn the burners off: Turn the gas control knobs back to the OFF position. Make sure the burners are out and turn off the main gas DO NOT use pots cylinder valve as well. that are larger or over hang the body of this cooker. CARE AND MAINTENANCE • Before caring for, or cleaning your cooker, make sure that the main gas valve is in an “OFF or closed” position, and the stove control knobs are in the “OFF” position. If the stove is still hot, wait for it to cool down before cleaning. • Ensure that there are no signs of blockage (eg. debris, insects, etc) in either the burner portholes, the primary air inlet or the neck of the burners. Use compressed air or pipe cleaner wire to clear obstructions. Brush the burner surfaces afterwards lightly with cooking oil to prevent the formation of DO NOT use steel rust while storing. -
Page 10: Specifications
SPECIFICATIONS Model GCS05 Description 2 Burner high pressure cooker LP Gas only Ignition system Manual ignition Hose SANS 1156-2 or BS3212-2 Rated pressure (Pa) Cylinder Vapour Gas consumption at Max 195gr/hr Any modification to the stove may cause injury or property damage. Any modification to the stove will invalidate the guarantee on this appliance. TROUBLE SHOOTING GUIDE TROUBLE CAUSE REMEDY It does not ignite • Main gas valve • Open it is closed • Rubber hose is • Put it right or If you are still unable bent... -
Page 11: After Sales Service
Trouble Tokai, 7966 Shooting Guide . Tel: 021 442 1540 If you are still unable E-mail: info@stingray.co.za to correct the problem www.alva.co.za with the information @StingrayGroupSA in this guide, then www.facebook.com/AlvaGas you need to contact your nearest dealer or TOLL FREE NUMBER manufacturer. 086 100 ALVA (2582)
