- Page 1 Ultrasonic Humidification System Model 5462 & Model 5472 OPERATING MANUAL 6/30/06 www.electrotechsystems.com...
-
Page 2: Table Of Contents
General Page 01 Description Set-Up Model 5462 Model 5462 Operation Model 5472 Model 5472 Set-Up 5.11 Using the Water Tank 5.12 Using the Tap Water System Operation 5.2.1 Features 5.22 Operating Precautions Maintenance and Cleaning (Models 5462 and 5472) Warranty... -
Page 3: General
20 cubic feet. DESCRIPTION The Model 5462 and Model 5472 operate in similar fashion. Applying power to the unit causes the submerged ultrasonic transducer to oscillate, producing a fine mist. An air-moving device forces the mist out of the humidifier, through a 1”... - Page 4 The threaded portion will go inside the chamber and be held in place with the ½” NPT nut. The barb will be outside the chamber. (If the humidifier is being used with an ETS Chamber, the barb is already installed.) 2.
-
Page 5: Model 5462
B. If no controller is being used, then plug the unit into a standard AC outlet of appropriate voltage. NOTE 230 VAC Model 5462 Systems : The 230 VAC version of the Model 5462 must be operated with the provided 230 VAC to 115 VAC step-down transformer ONLY!!! Plug the transformer into a 230 VAC outlet (or 230 VAC humidity controller output), then plug the humidifier into the 115 VAC side of the transformer. -
Page 6: Model 5462 Operation
If the problem persists, contact ETS. 3. Turn on the humidifier POWER switch. (If used with an ETS Automatic Humidity Controller, see “Humidifying” in the Controller manual.) The power indicator light will turn on immediately and the internal blower will begin moving. - Page 7 2. Always provide a vent on the chamber being humidified. A chamber without a vent will cause back-pressure, which could damage the humidifier. Also, if another pressurized source is being introduced in the chamber, the vent will allow both the humidifier and other source to operate properly.
-
Page 8: Model 5472
5.0 MODEL 5472 The Model 5472 Ultrasonic Humidifier, shown in Figures 5.0-1 and 2, is a premium version of the Model 5462 Ultrasonic Humidifiers. The Model 5472 has many features not found in the Model 5462. 5 Gallon Water Tank for... -
Page 9: Model 5472 Set-Up
Air Pump Deionized Water Input Output Tube Water Valve Water Level Protection Float Switch Ultrasonic Transducer Element Water Valve Float Switch Figure 5.0-2 SET-UP The Model 5472 Humidifier may be operated using a water tank or directly from a faucet without a tank. Use Distilled or Deionized water ONLY!! A water de-ionizing column is included, suitable for up to 100 psig. - Page 10 Simply loosen the cap on top of the tank to allow air to enter. Turn on the humidifier POWER switch. (If using with an ETS Automatic Humidity Controller, see “Humidifying” in the Controller manual.) The power indicator light will turn on immediately and the internal air pump will begin operating.
-
Page 11: Using The Tap Water System
4. Turn on the humidifier POWER switch. (If using with an ETS Automatic Humidity Controller, see “Humidifying” in the Controller manual.) The power indicator light will turn on immediately and the internal air pump will begin operating. When the basin is full, the automatic water level switch will activate the ultrasonic transducer. -
Page 12: Operation
1. The Model 5472 uses a small, linear air pump to force the mist into a chamber instead of the small blower fan used in the Model 5462. The pump can withstand substantially more backpressure than the blower fan. -
Page 13: Maintenance And Cleaning (Models 5462 And 5472)
With frequent cleaning, the electronics should operate reliably for many years. 6. Use distilled or deionized water only. MAINTENANCE & CLEANING (Model 5462 & 5472) 1. Always unplug the unit before cleaning. 2. Empty the unit of all water. - Page 14 4. Never leave water in the humidifier or water tank when the humidifier is not in service. Always empty all water and thoroughly dry all parts of the humidifier when it is to be stored or taken out of service for any period longer than one week.
-
Page 15: Warranty
ETS must be notified before any equipment is returned for repair. ETS will issue an RMA (Return Material Authorization) number for return of equipment. Equipment should be shipped prepaid and insured in the original packaging. If... - Page 16 WARNING WOODEN CRATES MUST NOT BE USED. PACKAGING OF DELICATE INSTRUMENTS WOODEN CRATES SUBSTANTIALLY INCREASES CONTENT’S SUSCEPTIBILITY TO SHOCK DAMAGE. DO NOT PLACE INSTRUMENTS ACCESSORIES INSIDE OTHER INSTRUMENTS OR CHAMBERS. ELECTRO-TECH SYSTEMS, INC. WILL NOT ASSUME RESPONSIBILITY FOR ADDITIONAL COST OF REPAIR DUE TO DAMAGE INCURRED DURING SHIPMENT AS A RESULT OF POOR PACKAGING.
