- Page 1 Dowel Collection Dowel Collection SKU: DBWMHPB1 SKU: DBWMHPB1 SMALL FOLDING PEG BOARD SMALL FOLDING PEG BOARD USER GUIDE USER GUIDE DANDELION RESPONSIBLY CREATING BETTER PRODUCTS FOR A BETTER WORLD...
- Page 2 Table of Contents Parts Diagram Parts Diagram Assembly Assembly Instructions Instructions Contact Us Contact Us USER GUIDE USER GUIDE...
- Page 3 B. Dowels x30 C. Small Shelf x3 A. Peg Board x1 D. Medium Shelf x4 F. Z-Bar (for wall) G. Mounting Hardware x5 E. Large Shelf x1 PARTS DIAGRAM PARTS DIAGRAM...
- Page 4 1. Using a level, measure and align bracket at the desired height for your unit on wall. Be sure to account for the distance from the on-unit Z-bar to the top of the unit when measuring. BEFORE drilling Z-bar into wall, ensure that the units will align for proper hanging by testing fit of bars together.
- Page 5 2. First, drill holes at marked locations on wall. Next, insert drywall anchor into drilled hole as needed for strength, then insert screw through the Z-bar. NOTE: Brackets MUST be tightly affixed to wall. ASSEMBLY ASSEMBLY INSTRUCTIONS INSTRUCTIONS...
- Page 6 3. Lift unit and slide onto wall by slotting on-unit brackets onto the wall-mounted brackets. Ensure that the bar on the unit locks properly and securely into the wall bracket. ASSEMBLY ASSEMBLY INSTRUCTIONS INSTRUCTIONS...
- Page 7 4. Once the peg board is hung at the desired location on the wall, ensure that it is stable and safely attached. ASSEMBLY ASSEMBLY INSTRUCTIONS INSTRUCTIONS...
- Page 8 5. Insert dowels into the pegboard at desired height(s). ASSEMBLY ASSEMBLY INSTRUCTIONS INSTRUCTIONS...
- Page 9 6. Press shelf down on pegs to secure in place. 7. Arrange shelves as desired. ASSEMBLY ASSEMBLY INSTRUCTIONS INSTRUCTIONS...
- Page 10 AND HELPING TO PROTECT AND HELPING TO PROTECT OUR PLANET. OUR PLANET. DANDELION Have a question? Get in touch with Have a question? Get in touch with our Dandelion representatives at: our Dandelion representatives at: 888-257-6639 888-257-6639 CONTACT US CONTACT US...
