- Page 1 FUEL LEVEL SENSOR Fantom FLS – 3304-11-10 FLS – 3304-11-15 FLS – 3304-11-20 FLS – 3304-11-25 FLS – 3304-11-30 Setup and operation Manual Firmware version 1.3.36 Configuration program version 3.6 Document edition from 20.01.2022 Tambov 2022...
-
Page 2: Table Of Contents
MIELTA Fantom CONTENTS Description ....................3 Specification ....................3 2.1 Power supply ..................4 2.2 Measurer part ..................4 2.3 Radio communication ................4 2.4 Active protection .................. 5 Installation and connection ................5 Sensor setup ....................8 4.1 Calibration .................... 9 4.2 Anti-aliasing .................. -
Page 3: Description
MIELTA Fantom 1. Description Wireless Fuel level sensor (FLS) Fantom MIELTA is designed to measure the level of light oil hydrocarbons (diesel, fuel, gasoline, kerosene and etc.) in various purposes containers. Sensor can be installed both on stationary objects and on automobile and railway transport. -
Page 4: Power Supply
2.7 А*h., which is designed for the entire service life in accordance with the manufacturer's recommendations for setting the frequency of measurement and sending data. After a malfunction, the battery can be replaced in the Mielta production laboratory, for this you need to contact the technical support service. -
Page 5: Active Protection
Bluetooth version 4.2 or later, as well as the program-Configurator for mobile devices Mielta Device Manager (Mielta DM) for the relevant operating system (Android, iOS). The program is available for free in the Google Play and App Store. - Page 6 MIELTA Fantom Priority direction of radiation of the antenna Picture 1. The installation dimensions of the FLS. Picture 2. Sensor connecting dimension. The surface for mounting the sensor must be horizontal and selected with regard to the availability and ease of installation. The central hole has a Ø20 mm. diameter (Pic. 2). The mounting holes diameter is chosen based on the material of the fuel tank and the attachment method.
- Page 7 MIELTA Fantom Mounting procedure: 1. Select a location for installation, clean it of contamination. 2. Mark the holes according to the template, drill and remove the sawdust. 3. Measure the depth of the fuel tank from the bottom to the mounting surface.
-
Page 8: Sensor Setup
(30-50 points per meter) to compensate nonlinearity. 4 Sensor setup To configure the sensor, use The Mielta Device Manager Configurator program, it is available for free in the Google Play and App Store app stores. For full operation, you must confirm all the permissions requested by the program. -
Page 9: Calibration
MIELTA Fantom “Settings” tab shows list of settings (Pic. 7). The Main settings include calibration of the fuel level sensor, parameters os the sensor and settings of the date and time. 4.1 Calibration The “empty tank” and “full tank” calibration values set the measurement range in conventional units which measures within the specified range of output values. -
Page 10: Measurement And Transmission
MIELTA Fantom Picture 8. Main settings 4.3 Measurement and transmission The values of the measurement period and the transmission period (advertising) directly affect the speed of the sensor's response to changes in the level and its power consumption. These parameters should be in the range from 1 to 10. -
Page 11: Data Transmission Format And Power
An increased transmission power also leads to increased power consumption. FLS Fantom supports two formats: Option 0 (by default) – format Mielta; Option 1 - similar sensor from other manufacturers. 5. Transportation and storage The fuel level sensor should be stored in warehouse conditions at a temperature of 20°C to + 50°C аnd a relative humidity of not more than 85°C.
