Technician's Troubleshooting Guide for
Power Breezer Mach 4
Technician's
Troubleshooting
Guide for
Power Breezer
Mach 4
SCOPE
This guide provides the Technicians with proper written instructions to ensure standard methodology
for the analysis and repair of the Power Breezer Mach 4.
REVISION HISTORY
Rev. No.
Date
1
08.01.2019
2
01.31.2022
Copyright © 2022 Maxify Solutions, Inc. All Rights Reserved. Power Breezer is licensed under U.S. Patent No. 6,789,787
Author
George Douglas
L. Sperring
Comment
Original Document
Copyright Update
| Page 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Power Breezer Mach 4
Summary of Contents for Power Breezer Mach 4
- Page 1 Power Breezer Mach 4. REVISION HISTORY Rev. No. Date Author Comment 08.01.2019 George Douglas Original Document 01.31.2022 L. Sperring Copyright Update Copyright © 2022 Maxify Solutions, Inc. All Rights Reserved. Power Breezer is licensed under U.S. Patent No. 6,789,787 | Page 1...
- Page 2 ● Always unplug the Cooling Unit by pulling on the plug and never on the cord. ● Do not insert fingers or other objects inside the fan head, doing so may cause bodily injury. Copyright © 2022 Maxify Solutions, Inc. All Rights Reserved. Power Breezer is licensed under U.S. Patent No. 6,789,787 | Page 2...
- Page 3 ● When operating Cooling Unit, use common sense. Stay clear of moving parts and only use water that is safe for drinking. Copyright © 2022 Maxify Solutions, Inc. All Rights Reserved. Power Breezer is licensed under U.S. Patent No. 6,789,787 | Page 3...
-
Page 4: Table Of Contents
A. How to Access and Remove the E-Box B. How to Substitute a Control Panel C. Changing the Water Pump Copyright © 2022 Maxify Solutions, Inc. All Rights Reserved. Power Breezer is licensed under U.S. Patent No. 6,789,787 | Page 4... -
Page 5: Tools And Materials Needed
A tried and true way to “zero- in” on where the root cause is located is to try “substitution”. Substitution, is using known good parts and substitute them into the unit to identify the possible defect. Copyright © 2022 Maxify Solutions, Inc. All Rights Reserved. Power Breezer is licensed under U.S. Patent No. 6,789,787 | Page 5... -
Page 6: No Power
If the unit is still not working: contact Customer Service by email at customerservice@powerbreezer.com or by phone at 844-233-5673 End of this section Copyright © 2022 Maxify Solutions, Inc. All Rights Reserved. Power Breezer is licensed under U.S. Patent No. 6,789,787 | Page 6... -
Page 7: Fan Not Working
Control Panel. If this “click” is not heard when the power button (Red) is pressed on the Control Panel: Copyright © 2022 Maxify Solutions, Inc. All Rights Reserved. Power Breezer is licensed under U.S. Patent No. 6,789,787 | Page 7... - Page 8 If the problem is not resolved, contact Customer Service by email at customerservice@powerbreezer.com or by phone at 844-233-5673. End of this section Copyright © 2022 Maxify Solutions, Inc. All Rights Reserved. Power Breezer is licensed under U.S. Patent No. 6,789,787 | Page 8...
-
Page 9: Atomizer Not Misting
Place a towel inside the atomizer catch tray to avoid losing the screws down the drain Remove the 6 screws from the atomizer screen Copyright © 2022 Maxify Solutions, Inc. All Rights Reserved. Power Breezer is licensed under U.S. Patent No. 6,789,787 | Page 9... - Page 10 Clear the pipe of any debris Turning on the atomizer and allow the water to flow out, issue is now resolved Re-assemble atomizer Copyright © 2022 Maxify Solutions, Inc. All Rights Reserved. Power Breezer is licensed under U.S. Patent No. 6,789,787 | Page 10...
- Page 11 If the problem is not resolved, contact Customer Service by email at customerservice@powerbreezer.com or by phone at 844-233-5673. End of section Copyright © 2022 Maxify Solutions, Inc. All Rights Reserved. Power Breezer is licensed under U.S. Patent No. 6,789,787 | Page 11...
-
Page 12: Atomizer Not Spinning
If the correct Atomizer is being used, please contact Customer Service by email at customerservice@powerbreezer.com or by phone at 844-233-5673. End of section Copyright © 2022 Maxify Solutions, Inc. All Rights Reserved. Power Breezer is licensed under U.S. Patent No. 6,789,787 | Page 12... -
Page 13: Head Is Not Rotating
If the E-Box not wired correctly, fix the issue and re-test If the E-Box is wired correctly, go to step 4 Copyright © 2022 Maxify Solutions, Inc. All Rights Reserved. Power Breezer is licensed under U.S. Patent No. 6,789,787 | Page 13... - Page 14 If it is correct contact Customer Service by email at customerservice@powerbreezer.com or by phone at 844-233-5673. End of section Copyright © 2022 Maxify Solutions, Inc. All Rights Reserved. Power Breezer is licensed under U.S. Patent No. 6,789,787 | Page 14...
-
Page 15: Water Pump Not Working Properly
If the E-Box not wired correctly, fix the issue and re-test If the E-Box is wired correctly, go to step 3 Copyright © 2022 Maxify Solutions, Inc. All Rights Reserved. Power Breezer is licensed under U.S. Patent No. 6,789,787 | Page 15... - Page 16 If the problem is not resolved, contact Customer Service by email at customerservice@powerbreezer.com or by phone at 844-233-5673. End of section Copyright © 2022 Maxify Solutions, Inc. All Rights Reserved. Power Breezer is licensed under U.S. Patent No. 6,789,787 | Page 16...
-
Page 17: Appendix
E-Box to slide off. Drawing 140-700-750 shows what the inside of the E-Box should look like and 140-700-750 - wiring diagram, this drawing will show you how it is electronically wired. Copyright © 2022 Maxify Solutions, Inc. All Rights Reserved. Power Breezer is licensed under U.S. Patent No. 6,789,787 | Page 17... -
Page 18: How To Substitute A Control Panel
F. Test the Control Panel by a. Turning on the unit b. Turning on the Atomizer c. Turning on the Rotation Copyright © 2022 Maxify Solutions, Inc. All Rights Reserved. Power Breezer is licensed under U.S. Patent No. 6,789,787 | Page 18... - Page 19 Technician’s Troubleshooting Guide for Power Breezer Mach 4 d. Vary the Speed of the Fan Copyright © 2022 Maxify Solutions, Inc. All Rights Reserved. Power Breezer is licensed under U.S. Patent No. 6,789,787 | Page 19...
-
Page 20: Changing The Water Pump
D. Remove anything attached to the cable E. Locate the Control Panel on the Power Breezer and lift the tray that the Control Panel is seated in; this will expose the DC Pump Cable. Pull the DC Pump Cable up from the E-Box. - Page 21 Black Wire go to Circuit Breaker L in #1 White Wire go to AC Block, Neutral Green Wire go to AC Block, AC Ground Copyright © 2022 Maxify Solutions, Inc. All Rights Reserved. Power Breezer is licensed under U.S. Patent No. 6,789,787 | Page 21...
- Page 22 Red Wire go to DC Block , +12 from Control Panel Black Wire go to DC Block , - 12 Copyright © 2022 Maxify Solutions, Inc. All Rights Reserved. Power Breezer is licensed under U.S. Patent No. 6,789,787 | Page 22...
