- Page 1 Manual Storage tent PRO 6m PVC Series 07-08-2013...
-
Page 2: Safety Advice
Safety Advice Attention In some countries approval is needed to set up a marquee/tent larger than 75 m2. It is your responsibility to comply with local rules and regulations and to ensure that the marquee/tent is assembled correctly. In case of bad weather conditions, it is your responsibility to ensure the marquee/tent is safely secured and that the marquee/tent does not cause damage to others. -
Page 3: Part List
Part list 6x12 6x18 Back leg Back leg Crossbar Ceiling rail Ceiling rail Extension pipe Corner arch Center arch Connecting pipe Connecting pipe Extension pipe Door Pillar Door pillar Cross bar Fastening bar Foot base Connecting component 10x305mm 07-08-2013... - Page 4 80mm 8x300mm Spiral peg 10x400mm 1.75"Screw 2.5" Screw 4" Screw Wingnut Floor Bracket (set of 2 pcs) Bungee ball Spanner Bolt with nut Tie-down kit Steel clip Rope Rope 07-08-2013 Attention Please use gloves when assembling the metal frame portion of this unit. The metal components of this products have been treated,with a rust preventive coating that may feel oily to the touch.
- Page 5 After the whole frames are set up, they should be the same as the pictures below.
- Page 6 Please assemble the frame as below steps. They have similar assemble steps. Here we take 6x6 for example . Step 1 When assembling the tent, make sure that all the wingnuts are attached to the inside. Connect one center arch pipe(8) with the extension pipe Attached the corner arch(7) to the ends of the extension pipe(6).
- Page 7 Step 4 Start setting up one side rst. Connect the corner arches(7) to the legs (1 and 2). Secure the frame using the connecting pipes(9 and 10). Attach the diagonal pipes(3) to the back legs(1). Please refer to the complete frame pictures to attach the diagonal pipes.
- Page 8 Step 6 Assemble the pillar set like below picture . Step 7 Use ropes to attach the door and cover the the frame. To nd a proper way and strength to attach the cover to frame carefully. Please do not use too much strength to tear the eyelet out of frabric...
-
Page 9: Contact Information
Contact information Head office: Dancover A/S For more information Nordre Strandvej 119 G please visit: 3150 Hellebæk www.dancovershop.com Denmark National contact Denmark: Spain: denmark@dancover.com espana@dancover.com Italy: uk@dancover.com italia@dancover.com Germany: Switzerland: germany@dancover.com schweiz@dancover.com France: Austria: france@dancover.com austria@dancover.com Sweden: Norway: sverige@dancover.com norge@dancover.com...
