  • Page 1 Operating Instruction MASTERspace - Workplace ® Always be on the safe side.
  • Page 2 Sales: Manufacturer: KaVo Dental GmbH Kaltenbach & Voigt GmbH Bismarckring 39 Bismarckring 39 D-88400 Biberach D-88400 Biberach Tel. +49 7351 56-0 www.kavo.com Fax +49 7351 56-1488...

  • Page 3: Table Of Contents

    Operating Instruction MASTERspace - Workplace ® Contents Contents Contents ................................1 1 User instructions ............................3 1.1 User guide ..............................3 1.1.1 Abbreviations ............................3 1.1.2 Symbols ............................3 1.1.3 Target group .............................3 1.1.4 Meaning of the pictograms .......................4 1.2 Service ..............................5 1.3 Warranty provisions ..........................6 1.4 Transportation and storage ........................7 1.4.1 Currently valid packaging ordinance ....................7 1.4.2 Damage in transit ..........................7...
  • Page 4 Operating Instruction MASTERspace - Workplace ® Contents 2/41...

  • Page 5: User Instructions

    Operating Instruction MASTERspace - Workplace ® 1 User instructions 1.1 User guide 1 User instructions 1.1 User guide Requirement Read these instructions before the initial startup to prevent misuse and damage. 1.1.1 Abbreviations Short Explanation form Instructions for use Care instructions Assembly instructions Technician's instructions Safety check...

  • Page 6: Meaning Of The Pictograms

    Operating Instruction MASTERspace - Workplace ® 1 User instructions 1.1 User guide 1.1.4 Meaning of the pictograms Automatic mode, automatic procedure Close, screw in, fasten etc. Open, detach, loosen etc. More, higher Less, lower Continuous operation Time, time-based sequence Disconnect the mains plug 4/41...

  • Page 7: Service

    Operating Instruction MASTERspace - Workplace ® 1 User instructions 1.2 Service 1.2 Service Service hotline: +49 7351 56-1600 Service.Zahntechnik@kavo.com Please indicate the product serial number in all requests. Additional information can be obtained at: www.kavo.com 5/41...

  • Page 8: Warranty Provisions

    12 months from the date of purchase demonstrated by the purchaser. In case of justified complaints, KaVo will honor its warranty with a free replacement or repair.

  • Page 9: Transportation And Storage

    1.4.1 Currently valid packaging ordinance Note Only applicable for the Federal Republic of Germany. KaVo transport packaging must be disposed of and recycled by local disposal ser‐ vice providers and recycling companies in accordance with Dual System require‐ ments. For more information about disposal and recycling, and an up-to-date list of local disposal service providers and recycling companies, please visit the following In‐...
  • Page 10 1 User instructions 1.4 Transportation and storage Outside of Germany Note KaVo is not liable for damage arising from transportation. Immediately inspect the delivery after receipt! If external damage to the packaging is visible upon delivery, follow the procedure below: 1.

  • Page 11: Information On The Packaging: Storage And Transport

    Operating Instruction MASTERspace - Workplace ® 1 User instructions 1.4 Transportation and storage 1.4.3 Information on the packaging: Storage and transport Note Keep the packaging for returning the product for service or repairs . The symbols printed on the outside are for transportation and storage, and have the following meaning: Transport upright with the arrows pointing upwards Fragile - protect against knocks...

  • Page 12: Safety

    Operating Instruction MASTERspace - Workplace ® 2 Safety 2.1 Description of safety instructions 2 Safety 2.1 Description of safety instructions 2.1.1 Warning symbol Warning symbol 2.1.2 Structure The introduction describes the type and source of the hazard. This section describes the potential consequences of non-observance. ▶...

  • Page 13: Safety Instructions

    ▪ Protect themselves and third parties from danger. Authorised to repair and service the KaVo product: ▪ Technicians from the KaVo branches who are trained to deal with the product. ▪ the technicians of the KaVo franchised dealers specifically trained by KaVo.

  • Page 14: Purpose - Proper Use

    ® 2 Safety 2.3 Purpose – Proper use 2.3 Purpose – Proper use KaVo MASTERspace is a high-quality equipment program for dental laboratories. ® It offers a comprehensive range of accessories and technical equipment which allow laboratory workstations to be laid out as single or multiple workplaces.

  • Page 15: Product Description

    Operating Instruction MASTERspace - Workplace ® 3 Product description 3.1 Scope of delivery 3 Product description 3.1 Scope of delivery ▪ Installation support ▪ Base element ▪ Compensating element / side wall / ABSORmatic ® ▪ Side bezel ▪ Work surface ▪...

  • Page 16: Masterspace ® Work Surface

    Operating Instruction MASTERspace - Workplace ® 3 Product description 3.2 MASTERspace work surface ® 3.2 MASTERspace work surface ® 14/41...

  • Page 17: Technical Data

    Operating Instruction MASTERspace - Workplace ® 3 Product description 3.3 Technical data 3.3 Technical data Compressed air Minimum air pressure provided by cu‐ 5 bar stomer Max. air pressure provided by customer 6 bar Max. air consumption 50 l/min Gas pressure provided by customer 50 mbar Max.

  • Page 18: Rating Plates

    Operating Instruction MASTERspace - Workplace ® 3 Product description 3.4 Rating plates 3.4 Rating plates Type code 9XXY ▪ 9: Brief description of the TAP program ▪ XX: Table length in 10 cm (11 to 24) ▪ Y: Number of workplace rows (1 or 2) Rating plate, MASTERspace workplace, type 1222, 120 V (Mat.

  • Page 19: Installation And Connection Of Masterspace

    Operating Instruction MASTERspace - Workplace ® 4 Installation and connection of MASTERspace 4.1 Check the consignment for completeness ® 4 Installation and connection of MASTERspace ® 4.1 Check the consignment for completeness ▶ Check the workplace for completeness 17/41...

  • Page 20: Check The Mains Voltage And Mains Frequency

    Operating Instruction MASTERspace - Workplace ® 4 Installation and connection of MASTERspace 4.2 Check the mains voltage and mains frequency ® 4.2 Check the mains voltage and mains frequency ▶ Check that the rated voltage and rated frequency match the specifications on the rating plate (+/- 10 %).

  • Page 21: Select Location

    Operating Instruction MASTERspace - Workplace ® 4 Installation and connection of MASTERspace 4.3 Select location ® 4.3 Select location ▶ Choose an installation location with gas, compressed air and electrical connec‐ tions. ▶ Light up the room so that it is as bright as daylight. ▶...

  • Page 22: Installation And Connection Of The Workplace

    Operating Instruction MASTERspace - Workplace ® 4 Installation and connection of MASTERspace 4.4 Installation and connection of the workplace ® 4.4 Installation and connection of the workplace 20/41...
  • Page 23 Operating Instruction MASTERspace - Workplace ® 4 Installation and connection of MASTERspace 4.4 Installation and connection of the workplace ® 21/41...
  • Page 24 Operating Instruction MASTERspace - Workplace ® 4 Installation and connection of MASTERspace 4.4 Installation and connection of the workplace ® 22/41...
  • Page 25 Operating Instruction MASTERspace - Workplace ® 4 Installation and connection of MASTERspace 4.4 Installation and connection of the workplace ® 23/41...
  • Page 26 Operating Instruction MASTERspace - Workplace ® 4 Installation and connection of MASTERspace 4.4 Installation and connection of the workplace ® 24/41...
  • Page 27 Operating Instruction MASTERspace - Workplace ® 4 Installation and connection of MASTERspace 4.4 Installation and connection of the workplace ® 25/41...
  • Page 28 Operating Instruction MASTERspace - Workplace ® 4 Installation and connection of MASTERspace 4.4 Installation and connection of the workplace ® 26/41...
  • Page 29 Operating Instruction MASTERspace - Workplace ® 4 Installation and connection of MASTERspace 4.4 Installation and connection of the workplace ® 27/41...
  • Page 30 Operating Instruction MASTERspace - Workplace ® 4 Installation and connection of MASTERspace 4.4 Installation and connection of the workplace ® 28/41...
  • Page 31 Operating Instruction MASTERspace - Workplace ® 4 Installation and connection of MASTERspace 4.4 Installation and connection of the workplace ® 29/41...

  • Page 32: Check Mark The Symbols On The Attachment Characteristics Label

    Operating Instruction MASTERspace - Workplace ® 4 Installation and connection of MASTERspace 4.5 Check mark the symbols on the attachment ® characteristics label 4.5 Check mark the symbols on the attachment characteristics label ▶ Remove the cover on the right-hand side of the installation support. ①...

  • Page 33: Connect The Gas, Compressed Air And Electrical Supplies

    Operating Instruction MASTERspace - Workplace ® 4 Installation and connection of MASTERspace 4.6 Connect the gas, compressed air and electrical supplies ® 4.6 Connect the gas, compressed air and electrical supplies Note 16 A fuse protection must be provided on the customer side. For installation in rows or double installation no more than 3 workplaces must be connected via a single fuse (max.

  • Page 34: First Use

    Operating Instruction MASTERspace - Workplace ® 5 First use 5 First use ▶ When first taking the unit into operation, ask an authorised specialist to check the protective earth conductor and the insulation. 32/41...

  • Page 35: Operation

    Synthetic dental materials on the basis of MMA can react with Corian and form permanent compounds. KaVo recommends the use of a protective cover or board on the work surface when working with aggressive products. Note Higher temperatures can leave scorch marks on beech wood and Corian.

  • Page 36: Opening And Closing The Gas Tap

    Operating Instruction MASTERspace - Workplace ® 6 Operation 6.2 Opening and closing the gas tap 6.2 Opening and closing the gas tap Note Close the gas tap when you have finished working. DVGW ▶ Open the gas tap ③. To do this, press the gas tap down and rotate it anti-clock‐ wise.

  • Page 37: Maintenance

    Operating Instruction MASTERspace - Workplace ® 7 Maintenance 7.1 Cleaning the workplace 7 Maintenance Electrical power Life-threatening hazard ▶ The electrical part of the device may only be repaired and serviced by profes‐ DANGER sionals or persons trained the the plant who were made aware of the safety instructions.

  • Page 38: Caring For The Work Surface

    Operating Instruction MASTERspace - Workplace ® 7 Maintenance 7.2 Caring for the work surface 7.2 Caring for the work surface Care products ▪ Mat. no. 0.411.9080 for Techdent ▪ Mat. no. 0.411.9010 for beech wood ▶ Once or twice a week, thinly apply a care product to the cleaned and dried work surface with a cloth.

  • Page 39: Maintenance Of The Safety Hose For The Bunsen Burner

    Operating Instruction MASTERspace - Workplace ® 7 Maintenance 7.3 Maintenance of the safety hose for the bunsen burner 7.3 Maintenance of the safety hose for the bunsen burner Note Cracks can occur as a result of localised overheating, stresses/strains and ageing effects, as well as due to heat, light, acids and alkalines.

  • Page 40: Accessories

    Operating Instruction MASTERspace - Workplace ® 8 Accessories 8 Accessories ▪ AS board ▪ Tray ▪ Protective glass ▪ Tool carrier ▪ Workplace lamp ▪ Burner carrier ▪ Foot rest ▪ Model trays ▪ Work trays ▪ Push-in boards ▪ Drawer insert 38/41...

  • Page 41: Service Replacement Parts

    Operating Instruction MASTERspace - Workplace ® 9 Service replacement parts 9 Service replacement parts 39/41...

  • Page 42: Declaration Of Conformity

    Operating Instruction MASTERspace - Workplace ® 10 Declaration of conformity 10 Declaration of conformity 40/41...
