- Page 1 QUICK GUIDE EN Smart Wi-Fi Floodlight Camera Compatible with Amazon Alexa & Google Assistant...
- Page 3 What’s in the box Consult the checklist below for all components. Bracket Bracket screws Wire nuts Screwdriver Disc bracket Waterproof terminal User manual Screws Phillips screwdriver...
- Page 4 Introduction Lens Reset Light SD card slot PIR & Status light Description Power AC 100~240V Status light Red light solids on: the camera network is abnormal Blinking red light: awaiting WiFi connecting Blue light solids on: camera running correctly Blinking blue light: currently connecting Records sounds for your video Microphone SD card slot...
-
Page 5: Installation
Installation Bracket Screws Wire Nuts 100~240V AC Screws Bracket If the wires are placed in an outdoor environment, the included waterproof terminal is suggested to use. For the Europe Region NOTE: Different countries may have different colors for wiring. Please connect the wires of the same color together. - Page 6 Installation The Wall Fix the F1 to the bracket ** Note A. Fix the camera B. Adjust the angle C. Adjust the direction and fix the camera.
- Page 7 Connection Download Arenti is available for both iOS and Android OS. Search the name 'Arenti' in App Store or Android Market, or scan below QR-Code to download the App. Add device Log in the Arenti, select "Add Device", and add the smart camera to the App according to the screen tips(Make the smart camera close to the router when configuring).
- Page 8 Function Lighting Control You can turn the light on or off with time setting or PIR. Full-Duplex Audio You can see and hear the vistor in your App from the camera. When the camera detects someone stopping by, it sends an alarm message to your cell phone.
