- Page 1 Active 2.1-channel speaker system with USB/Bluetooth interface and SD/MMC slot Instruction manual Capella...
-
Page 2: Intended Use Of The Device
Orava electrical devices are manufactured according to the state of the art and recognized safety rules. Nevertheless, improper and unprofessional use or use contrary to the intended use may result in injury or danger to the life of the user or third party. - Page 3 1.1 General safety instructions • Before operating the unit, we recommend that you carefully read the instruction manual and operate the equipment in accordance with the instructions! • The safety instructions and warnings in this manual do not cover all the possible conditions and situations that may arise when using the device.
- Page 4 • Features of the operating environment: 1. Ambient temperature: +5 ÷ +40 ° C 2. Humidity: 5 ÷ 85% 3. Altitude: ≤ 2 000 m 4. Occurrence of water: intermittent condensation of water or occurrence of water vapor 5. Occurrence of foreign bodies: quantity and type of dust are insignificant 6.
- Page 5 • In order to provide increased safety against the risk of electric shock due to the use of electrical devices by laypersons, it is recommended to install the power supply circuit for sockets with a rated current not exceeding 20 A RCD with a rated operating current not exceeding 30 To ensure the safety and correctness of the electrical installation, consult a qualified electrician.
- Page 6 • Do not expose the device to water or moisture. The ingress of water into the device increases the risk of electric shock. If the power cord is wet or the water has penetrated the water, disconnect it immediately from the mains. If the device is plugged into a mains socket and if possible, turn off the power circuit before attempting unplug the power.
- Page 7 1.5 Cleaning, maintenance and repairs • Observe the normal user cleaning and maintenance of the device in the recommended way. Do not use solvents or harsh cleaners for cleaning. Pollution and visible stains from finger contact, respectively. The hands can be cleaned using detergent detergents specially designed to clean household devices.
- Page 8 2. Special safety instructions. Read carefully! The electrical device is designed and manufactured in such a way as to enable safe operation and use by persons without professional qualificati- ons. Despite all the precautions that have been taken by the manufacturer for safe use, operation and use, they carry certain residual risks and asso- ciated hazards.
- Page 9 • Clean these parts only with a slightly damp cloth and wipe dry or allow to dry. • Clean the device only when the device is turned off and unplugged. There is a risk of electric shock! There is a risk of electric short circuit! Inspection/Commissioning •...
- Page 10 Warning! • Do not expose the audio device and remote control to: - direct sunlight, heat producing equipment, - vibration and mechanical stress - excessive dust, - water and excess moisture, - insect, - an aggressive outdoor environment. • Do not place the audio device (and remote control): - to places where medical equipment is used.
- Page 11 Operation/Supervision • During using and operation, keep the device under supervision! • Ensure that all electrical cable connections are secure and properly connected. If the power cord is not firmly connected to the device, be careful not to disconnect it from the device while the plug is connected to the power cord socket.
- Page 12 Caution! • If you will not be using the device for an extended period of time, unplug the power cord from the wall socket. Dust deposits and humidity can cause electrical interference. There is a risk of electric shock! There is a risk of fire! •...
- Page 13 • ORAVA is not responsible for any incidental or consequential damages or other damages or disclosure of data and/or information that may occur during wireless transmission.
-
Page 14: Power Supply
• If you feel inconvenience when using Bluetooth , stop using the Bluetooth device immediately. ® • If any problem persists, contact your nearest ORAVA dealer. Licenses • The Bluetooth word mark and logo are owned by Bluetooth SIG, Inc. and any use thereof by ®... -
Page 15: Control Elements
Control elements Feature on device (back side) Feature on Device (Front - Top) - Page 16 Device Elements (Front side - Bottom) Back side ON/OFF switch (on/off) Mains cord AUX connectors (2x RCA - L / R) (external audio source) Satellite Speaker Connectors (2x RCA - L / R) Telescopic antenna Front - Top Power Indicator (POWER) Volume control (VOLUME) BALANCE adjustment knob Height Adjuster (TREBLE)
- Page 17 Remote Control (RC) 1 ST-BY button (to/from standby) INPUT button (AUX/USB/SD/BLUETOOTH/FM audio source switching) 3 MUTE button 4 EQ button (equalizer preset switching) 5 RESET button (reset equalizer mode) 6 VOL + (volume up) button 7 VOL - (Volume Down) button 8 Button .
-
Page 18: General Operations
General operations Display The display shows track numbers, media, volume settings, and so on. Sound settings 1 Turn on the device. 2 Turn VOLUME (press and hold PREV / FM- and NEXT / FM + or press VOL + / VOL - on) to adjust the volume during playback. -
Page 19: Connecting External Devices
Connecting external devices Connect the desired audio equipment to one of the connectors with the supplied optional audio cable as shown. -
Page 20: Radio Control
Radio control Tuning and storing stations 1 Turn on the unit and press INPUT on the unit or remote control to select the radio source (FM). You can also use the FM button on the remote control to directly select the FM sound source. - Page 21 3 On your Bluetooth device (phone, tablet, etc.), search for available Bluetooth devices. See your device’s instruction manual for details. When Capella appears on the display of your Bluetooth device, select it and wait until your Bluetooth device displays a pairing confirmation with your Capella.
- Page 22 Playback from USB device/SD card Play MP3/WMA files The player can play MP3 / WMA in audio quality comparable to a CD. You can play files from a USB device or SD card. You can play MP3 files using the buttons on the unit or on the remote control. 1 Connect a USB device to the USB port or insert an SD card into the SD card slot.
- Page 23 Playback operations Playing Press PLAY/PAUSE on the unit or u on the remote control to start playback from the first track. Pause During playback, press the PLAY/PAUSE button on the unit or u on the remote control. Playback pauses. Press the PLAY/PAUSE button on the unit or u on the remote control again while pausing.
-
Page 24: More Details
More details BLUETOOTH wireless technology Wireless BLUETOOTH technology is a short-range technology that allows wireless data communication between digital devices, such as wireless devices. PC and digital camera. The BLUETOOTH wireless technology works within a range of about 10 m. Connecting two devices is mutual, but some devices can be connected to multiple devices at the same time. -
Page 25: Maintenance
Notes • To use the BLUETOOTH function, the BLUETOOTH device connected must have the same profile as the system. • Even if the profiles are the same, the devices may work differently depending on their specifications. • Due to the features of the BLUETOOTH wireless technology, the sound reproduced by this system is slightly delayed from the sound of the BLUETOOTH device during a phone call or listening to music. -
Page 26: Technical Specifications
Technical specifications Output audio power: 60 W (RMS), 2 x 15 W + 1 x 30 W subowoofer Connectors - input: AUX - 2x RCA connector (for external audio device) USB connector (for USB devices, up to 32 GB) SD card slot up to 32 GB Bluetooth: Bluetooth Standard 4.2... - Page 27 DECLARATION OF CONFORMITY Short text Declaration of Conformity: ORAVA retail 1, a.s. hereby declares that the Capella complies with the essential requirements and other relevant conditions of Directive 2014/53/ EU of the European Parliament and of the Council. The full text of the Declaration of Conformity is available at: www.orava.eu...
