Orava Crater 8 Instruction Manual

Portable bluetooth speaker
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Portable Bluetooth speaker
Instruction manual
EN
Crater 8
1
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Crater 8 and is the answer not in the manual?

Questions and answers

Related Manuals for Orava Crater 8

Summary of Contents for Orava Crater 8

  • Page 1 Portable Bluetooth speaker Instruction manual Crater 8...
  • Page 2 ORAVA electrical appliances are manufactured according to the state of the art and recognized safety rules. Nevertheless, improper and unprofessional use or use contrary to the intended use may result in injury or danger to the life of the user or third party.
  • Page 3 Warning! The degree of protection of the device is tested under specific technical conditions and does not mean that the device is intended to be used under permanent conditions of dust and water. General safety instructions and warnings • Before commissioning, we recommend that you carefully read the operating instructions and operate the equipment in accordance with the instructions.
  • Page 4 • The basic IPX0 protection class (when the device is not protected by its waterproof cover) is not marked on the product and in the technical parameters listed in the operating instructions. • If the protection class of the product is different from IPX0, this information is then displayed on the label of the appliance or in the technical data of the operating instructions.
  • Page 5 • Do not expose the appliance to indoor use by water or excessive moisture. Do not dispose of any containers with water or other liquids. • Do not install the appliance near heat sources or other heat generating devices. • Do not place objects on the device that can cause a dangerous situation (eg burning candles, etc.).
  • Page 6 Warning! • The loudspeaker system for a mobile phone is a device that when used, it may alter (reduce) the perception of ambient sounds. If you perform any activities that are accompanied by an increased risk to yourself or others in close vicinity, always check your surroundings to avoid injuring yourself or others.
  • Page 7 • Do not let the signal cables hang freely and do not allow them to be freely accessible and reachable by children. There is a risk of serious injury! There is a risk of electric shock! • The device contains parts of covers (eg ventilation grilles) that can be heated during normal operation.
  • Page 8 • ORAVA is not responsible for any incidental or consequential damages or other damages or disclosure of data and/or information that may occur during wireless transmission.
  • Page 9 • The Bluetooth word mark and logo are owned by Bluetooth SIG, Inc. and ® any use thereof by ORAVA retail 1, a.s. is subject to a license. • Other trademarks and trade names are the property of their respective owners.

  • Page 10: Power Supply

    Power supply Power from built-in rechargeable battery The device is powered by a built-in 3.7 V, 800 mAh rechargeable battery. Charge the battery before using it for the first time or whenever the battery is weak (the sound is weak, distorted, the message “Low battery” sounds, or the device turns off completely).

  • Page 11: Control Elements

    Control elements Button 1 (on/off/Bluetooth/FM/USB mode switch/TWS (True wireless stereo) mode on) Short press: switch TWS on/off Push and hold: Disconnect two TWS paired speakers Two short presses: delete TWS pairing from memory Button 7 Short press: play/pause/stop/answer/end call Push and hold: tunes and stores all available FM stations in memory LED indicator It lights up blue during operation and flashes blue during pairing.

  • Page 12: Sound Settings

    Button - Short press: toggle tracks backward / toggle FM stations backward / toggle call sound from speaker to phone and vice versa Push and hold: decrease volume Two short presses: switches back to the previous folder Button + Short press: switch tracks forward / switch FM stations forward / switch call sound from speaker to phone and vice versa Push and hold: increase the volume Two short presses: switch to the next folder forward...

  • Page 13: Radio Control

    Radio control Tuning and storing stations Turn on the device by pressing and holding button 1 for more than 3 seconds. The device turns on (LED blinks (or blinks) in blue. Press 1 briefly to select the radio source (FM) (“FM radio” (FM mode)). Press and hold 7 for about 3 seconds.
  • Page 14 Bluetooth playback from Bluetooth device Turn on the Bluetooth interface on your Bluetooth device (phone, tablet, etc.).See your device’s instruction manual for details. Turn on this unit by pressing and holding button 1 for more than 3 seconds. The device will switch to Bluetooth mode and be ready to pair (LED indicator will blink blue).
  • Page 15 Bluetooth devices. See your device’s instruction manual for details. When Crater 8 appears on the display of your Bluetooth device, select it and wait until the pairing confirmation with the Crater 8 is displayed on your Bluetooth device display. Device paired”. The devices are paired.
  • Page 16 If you receive a phone call while playing music via the Bluetooth interface, answer the call by briefly pressing the 7 button on this unit or the mobile answer button. The sound of the call will be reproduced by this speaker. End a call Press 7 briefly during a call to end the call.
  • Page 17 Cancel current Bluetooth pairing When the loudspeaker is paired with a Bluetooth device, and these devices are currently connected and you want to cancel this pairing, press and hold down 7 to connect another device. A “Device disconnected” message will be heard. You can then pair with another Bluetooth device.

  • Page 18: Tws Function

    TWS function (True Wireless Stereo) If you have two Crater 8 speakers, you can pair them with each other and reproduce real stereo sound from a connected and paired Bluetooth device via a Bluetooth interface with two speakers. Turn on the Bluetooth interface on your Bluetooth device (phone, tablet, etc.).
  • Page 19 See your device’s instruction manual for details. When Crater 8 appears on the display of your Bluetooth device, select it and wait until the pairing confirmation with the Crater 8 appears on the display of your Bluetooth device. and a “Device paired” message is heard from the left device.

  • Page 20: Usb Drive Playback

    USB drive playback Play MP3/WMA files The speaker can play MP3/WMA/WAV/APE/FLAC format in audio quality comparable to a CD. You can play files from a USB storage device with a capacity of up to 32 GB. You can play files using the buttons on the device. Connect a USB storage device to the USB port.
  • Page 21 Playback operations Playback Press 7 to start playback from the first track. Suspension Press 7 during playback. Playback pauses. Press 7 again while pausing. Playback resumes. Feedback: - Scroll to the beginning of the current (single press) or previous (repeat) tracks and play them automatically.

  • Page 22: More Details

    This system supports security standards that are compliant with Bluetooth standards to ensure secure connectivity when using Bluetooth wireless technology. However, depending on your settings, security may not be sufficient. Be cautious when using Bluetooth wireless technology. • Orava is not responsible for leakage of Bluetooth communications.

  • Page 23: Troubleshooting

    10 m. Bluetooth device finds more other Bluetooth devices when searching: Wait for the search to finish and select “Crater 8” for pairing. When using the phone, do not hold the mobile device too close to the...

  • Page 24: Maintenance

    Phoning The caller / recipient is not heard. - Make sure that both the Bluetooth mobile phone and the device are turned - Check the connection of the Bluetooth mobile phone and this speaker. - Check if the mobile phone’s Bluetooth output is set for this speaker. - Check if the speaker is set to a low volume level.

  • Page 25: Technical Specifications

    Technical specifications Generally Audio output power: 5 W (RMS), 4 Ohm Connectors - input: USB connector for microUSB USB (charge) Bluetooth: Bluetooth Standard 5 Profile: A2DP (Advanced Audio Distribution Profile) profile for wireless music transfer in stereo quality Profile: AVRCP (Advanced Audio Distribution Profile) profile for playback control band: 2.402 - 2.480 Ghz FM radio:...
  • Page 26 DECLARATION OF CONFORMITY Short text Declaration of Conformity: ORAVA retail 1, a.s. hereby declares that the Crater 8 complies with the essential requirements and other relevant conditions of Directive 2014/53/ EU of the European Parliament and of the Council. The full text of the Declaration of Conformity is available at: www.orava.eu...
