Nikon Optos Table User Manual

Optos Table
User Guide
1
2
3
4
5
6
No. Part Description
Table top Location for equipment.
1
Table control Used for adjusting the height of the table. The table control switches are
2
switches duplicated on each side of the table.
Table column The height of the table column is adjusted using the table control switches.
3
Power mains Provides power for the table and is located at the back of the table column.
4
cable
Table base The wide table base provides wheelchair access.
5
Wheels Four lockable wheels.
6
Monitor Support An adjustable support arm for a monitor. A monitor is not supplied with the
7
Arm table.
Table height Buttons on the table control switches used for controlling the table height
8
adjustment adjustment.
Green power LEDs on the table control switches that indicates when power is supplied to
9
LED the table.
Copyright 2017, Optos plc. All rights reserved.
Optos plc. products are protected by patents and patent applications listed at optos.com/patents.
The information contained within this document is subject to change without notice. The latest version of this
information can be found at optos.com.
Copyright
This document may only be used for your personal, non-commercial use. This document and all its contents (including
without limitation, all text, formats, graphics and logos) are the property of Optos plc. and are protected from
unauthorized copying and dissemination by the Copyright, Designs and Patents Act 1988 (as amended), by various
intellectual property laws and by international conventions.
Part Number: G-109971/4GCA
Print Date: July 2017

Warnings and cautions

EN
The table must be operated within the safety parameters and instructions defined in this Optos Table
User Guide .
If you have any questions regarding the correct use of the table, please contact your Optos
representative before attempting to operate the table.
Please keep this document in a safe place for future reference.
Read the warnings and cautions before using the table.
Operational safety
7
2
8
9
8
Ensure the patient or operator's arm is
is adjusted.
Do NOT tilt the table. Ensure the table is used on a flat and even surface.
You MUST ensure that there are no obstructions when adjusting the height of the table.
If the table continues to move without a button being pressed, move the patient away
WARNING
from the table.
If the table continues to move after you have pressed a button, stop the table by
pressing the button that moves the table in the opposite direction. Try either button. If
this does NOT
If you suspect the table is faulty, contact your Optos representative.
In a medical environment, the Optos Table should be installed by Optos trained
personnel or by your site biomedical team.
CAUTION

General safety

No modification of this equipment is allowed.
Using the table with an ophthalmoscope:
Refer to your device instructions for use.
l
The ophthalmoscope
l
WARNING
The front of the ophthalmoscope
l
The patient
l
The patient
l
The table is NOT
The table weighs 53 kg (117 lbs). Do not attempt to lift the table.
CAUTION
Ensure all wheels are unlocked before moving the table.

EMC safety

In order to provide reasonable interference protection against radio communication
services, this device has been tested and complies with 47 CFR Part 15, Sub Part B of
the FCC (U.S.A.) rules and IEC/EN 60601-1-2 standard requirements at the premises
of a typical user, and the CISPR11 standard emission limits (CISPR11 Group 1 Class
B).
Although compliant with all applicable international EMC standards, the equipment
generates, uses and can radiate radio frequency energy. The equipment may cause
radio frequency interference to other medical and non-medical devices and radio
communications nearby.
CAUTION
There is no guarantee that interference will
If this table is found to cause interference (which may be determined by turning the
equipment
ON
correct the problem by one or more of the following measures:
Relocate the affected device or devices.
l
Increase the separation between the equipment and the affected device.
l
Consult your Optos representative for further suggestions.
l
NOT trapped or impacted when the table height
work, remove the plug from the mains socket.
be positioned in the middle of the table width.
MUST
MUST be inline with the front of the table.
be unattended at the table.
MUST NOT
MUST NOT touch the table controls.
designed to support a person.
NOT occur in a particular installation.
and ), the user or qualified service personnel should attempt to
OFF
Unauthorized changes or modifications will invalidate the warranty of this table.
The manufacturer is responsible for any interference caused by using:
NOT
Interconnect cables NOT supplied by Optos.
l
Unauthorized changes or modifications to the table.
l
Do NOT use devices which intentionally transmit RF signals (cellular phones,
transceivers or radio controlled devices) in the vicinity of the table, as it may cause
performance outside the published specifications.
CAUTION
The use of accessories and cables other than those specified may result in degraded
electromagnetic compatibility of the system.
Operation is subject to the following two conditions:
This table may NOT cause harmful interference.
l
This table accept any interference received, including interference that may
MUST
l
cause undesired operation.

Electrical safety

Electrical Shock Protection - Class 1 Equipment
Type B - relates to the allowable maximum leakage current which can flow from the
applied part. The limits for this are defined in IEC/EN 60601.
The table MUST be plugged directly into a wall socket. Do
or extension cable.
To prevent electric shock:
Only use cables supplied by Optos.
l
WARNING
Mains supply must be earthed.
l
The table may only be serviced by Optos trained personnel.
l
If the mains cable is damaged do not use the table and contact your Optos
representative.
Do NOT connect any peripherals to the table. Only use peripherals supplied with the
table. Independently sourced peripherals may
NOT
Ordinary equipment, without protection against ingress of water.
You must regularly inspect the table. If there is any damage please contact your Optos
representative.
CAUTION
Ensure the mains socket is easily accessible.

Technical specifications

The following information provides technical details about the Optos Table.
Table safety details
Feature description Compliance
Type of protection against electrical shock Class 1
Degree of protection against electrical shock Type B applied part
Degree of electrical connection between Equipment designed as non-electrical connection
equipment and user to the user
Degree of mobility Mobile
Mode of operation Non-continuous
Duty cycle 2 min ON ( I ), 10 min OFF ( O )
Table column speed Approx. 17 mm/s
Supply connection 100-240Vac, 50-60Hz
Electrical Protection 2 x (5x20) T6.3AL 250V Fuses
Power Consumption 90VA
NOT plug into a power block
be compatible.
