TABLE OF CONTENTS

1 Safety Precautions----------------------------------------------- 3
1.1. General Guidelines---------------------------------------- 3
1.1.1. Leakage Current Cold Check---------------------- 3
1.) --------------------------------------------------------- 3
2 Warning -------------------------------------------------------------- 4
2.2. About lead free solder (PbF)---------------------------- 5
3 Service Navigation ----------------------------------------------- 6
3.1. Service Hint ------------------------------------------------- 6
4 Specifications ----------------------------------------------------- 7
5 Service Mode ------------------------------------------------------ 9
5.1. How to enter into Service Mode ----------------------- 9
5.1.1. Contents of adjustment mode --------------------- 9
5.1.2. How to exit---------------------------------------------- 9
5.2. SRV-TOOL -------------------------------------------------10
5.2.1. How to access ----------------------------------------10
5.2.2. Display of SOS History -----------------------------10
Model No.
Chassis:
Destination:
PAGE
5.2.3. POWER ON TIME/COUNT ----------------------- 10
5.2.4. Exit ------------------------------------------------------ 10
5.2.5. Self Check Mode ------------------------------------ 11
5.2.6. Hotel Mode Adjustment ---------------------------- 11
5.2.7. Hotel Mode-------------------------------------------- 11
6 Troubleshooting Guide --------------------------------------- 12
6.1. Check of the IIC bus lines------------------------------ 12
6.1.1. How to access --------------------------------------- 12
6.1.2. Exit ------------------------------------------------------ 12
6.1.3. Screen display --------------------------------------- 12
6.2. Power LED Blinking timing chart --------------------- 13
6.3. No Power--------------------------------------------------- 13
7.1. AC Cord Dressing---------------------------------------- 14
7.2. Control Panel Assembly-------------------------------- 15
7.5. LCD Panel Assembly 1 --------------------------------- 18
7.6. LCD Panel Assembly 2 --------------------------------- 19
ORDER NO. MTV1101066CE
TH-L42E30R
LA18
IRAN
© Panasonic Corporation 2011. Unauthorized
copying and distribution is a violation of law.
LCD TV
PAGE
