Furniture of America Luminar II CM3559PT Assembly Instructions

Table

ASSEMBLY RATING

The Assembly Rating is a 5-point system that

shows the degree of effort needed in

assembling a specific product (with 1 being

easy and 5 being difficult). For some

products, two persons are recommended.

EASY

Assembly Instructions

DIFFICULT

Tools Required for Assembly:

Allen Wrench

Phillips Screwdriver

2 PERSONS RECOMMENDED

Page 1 of 6

(Included)

(Not Included)

Table of Contents

Need help?

Do you have a question about the Luminar II CM3559PT and is the answer not in the manual?

Page 1 Assembly Instructions ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that Allen Wrench shows the degree of effort needed in (Included) assembling a specific product (with 1 being Phillips Screwdriver easy and 5 being difficult). For some (Not Included) products, two persons are recommended.
Page 2 Page 3 of 6...
Page 3 Before you begin, please read Page 3 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 1 pc #A x 8 pcs Table Top Bolt 5/16”x7/8” #B x 8 pcs #2 x 4 pcs Bolt 5/16”x7/8”...
Page 4 Turn right (clockwise) to tighten #A x 8 pcs #G x 4 pcs Align the bracket (#G) with the pre- drilled holes of the leg (#2). Secure the brackets (#G) using the Allen wrench (#F) to tighten the 4 bolts (#A) to lock them with the leg (#2).
Page 5 With the help of another person, carefully place the table top (#1) facing down on a protective surface. Align the assembled legs/shelf with the pre-drilled holes on the table top (#1). II. Prepare 8 bolt assemblies by inserting FIRST the lock washer (#E) onto the bolt (#B) and then the flat washer (#D) onto the SAME bolt (#B), in that order.
