Furniture of America Luminar CM3559SV Assembly Instructions

Assembly Instructions

CM3559SV

ASSEMBLY RATING

The Assembly Rating is a 5-point system that

shows the degree of effort needed in

Phillips Screwdriver

assembling a specific product (with 1 being

(Not Included)

easy and 5 being difficult). For some

products, two persons are recommended.

DIFFICULT

EASY

2 PERSONS RECOMMENDED

Page 1 of 5

Rev.14-02-24

Table of Contents

Do you have a question about the Luminar CM3559SV and is the answer not in the manual?

Page 1 Assembly Instructions CM3559SV ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Phillips Screwdriver assembling a specific product (with 1 being (Not Included) easy and 5 being difficult). For some products, two persons are recommended.
Page 2 Page 2 of 5...
Page 3 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List #1 x 1 pc #A x 8 pcs Server Shelf Support #2 x 1 pc Table Glass #3 x 2 pcs Glass Shelf...
Page 4 Due to the fragile nature of the glass, take caution when inserting the Step 1 table glass (#2) onto the top of the server (#1). Insert 4 shelf supports (#A) onto the desired holes for Step 2 each side of the server (#1). #A x 8 pcs Enlarged Page 4 of 5...
Page 5 Step 3 Tilt the glass shelf (#3) at an angle and gently have it rested and leveled on top of all 4 of the shelf supports. Repeat the process for the other side. To install the batteries (not included), remove Step 4 the screw that holds the battery cover by using a Phillips screwdriver.
